Official Bay Window engine pics thread

Krautski · Samba Member Joined: March 28, 2009 Posts: 656

Image may have been reduced in size. Click image to view fullscreen.

_________________
DCI |all up in your heat exchangers|

I read threads backwards and ignore your words.

slammed73hightop · Posted: Sun Sep 25, 2011 2:42 pm Post subject:

here's a vid of my engine finally in and started! i just need to do acouple adjustments and then it'll be ready to drive! (its loud cause of the stinger)

http://s40.photobucket.com/albums/e217/BengH/?action=view&current=ItsAlive.mp4
_________________
project drop'd 73 hightop
stock 1.7L type IV engine
duel Weber 34mmICT's
__________________________________
73 poptop westy project

Rob R · Posted: Sun Sep 25, 2011 4:16 pm Post subject:

My motor isn't assembled yet but I made a degree wheel that bolts to the case to degree my cam. There is a mark on the fan that aligns with the split in the case when number 1 is at tdc.
Image may have been reduced in size. Click image to view fullscreen.

rcrjacob · Posted: Mon Sep 26, 2011 8:21 pm Post subject:

That's awesome! More pics of the wheel??
_________________
1974 7 Passenger - it's a mess

My M-Plate Decode:

http://www.vw-mplate.com/mcode.php?lang=EN&id=3447

Rob R · Posted: Tue Sep 27, 2011 2:39 pm Post subject:

Here are a few more pictures
Image may have been reduced in size. Click image to view fullscreen.

karstans · Posted: Mon Oct 31, 2011 5:00 am Post subject:

My new Stan Pobjoy race engineering engine .. the thing hammers !

Image may have been reduced in size. Click image to view fullscreen.

[/img]

Brionp · Samba Member Joined: March 18, 2009 Posts: 394

Chris Blackwell · Posted: Wed Nov 02, 2011 7:33 pm Post subject: Engine Bay restoration

Before my son and I rebuilt the engine bay.
Image may have been reduced in size. Click image to view fullscreen.

During

and after

_________________
71 Bultaco
59 Chevy Apache
69 Transporter
67 Beetle

Micropassatman · Posted: Fri Nov 04, 2011 1:24 am Post subject:

Before

New Parts

Stripped and etched

Image may have been reduced in size. Click image to view fullscreen.

busdaddy · Posted: Fri Nov 04, 2011 7:42 am Post subject:

Looks good, any secret fortifications hiding in that engine to give it the balls to push that 6 rib?
_________________
Rust NEVER sleeps and stock never goes out of style.

Wanted, 68-73 westy OG plaid curtains, singles OK.

Amskeptic · Posted: Fri Nov 04, 2011 8:56 am Post subject:

ccpalmer · Posted: Fri Nov 04, 2011 9:38 am Post subject:

edit delete..
_________________
'71 Westy

'77 Bay/rusty shed on wheels
--
Chris Palmer
Cocobolo Co., LLC
ccpalmer.com

Micropassatman · Posted: Fri Nov 04, 2011 10:40 am Post subject:

Micropassatman · Posted: Fri Nov 04, 2011 5:58 pm Post subject:

If you're wondering why there isn't any rear tin on the engine? It's because I bought new tin that hasn't got ANY holes and I'm gearing up to install the heatriser cutouts.

Image may have been reduced in size. Click image to view fullscreen.

ccpalmer · Posted: Fri Nov 04, 2011 6:52 pm Post subject:

Micropassatman · Posted: Fri Nov 04, 2011 7:31 pm Post subject:

Looks good; in the spirit of stock why not get a stock oil bath air cleaner to go with that baby?

And I'm no expert, but what Busdaddy was getting at is that many say a 6-rib tranny has to high of gearing for a T1 powerplant... maybe instead of an oil bath some dual carbs are in order...

And what dizzy is that? It's so short! (no offense intended!)

Also - is that a single port engine? The center intake manifold section looks like a dual port type but the ends look to be singleport...[/quote]

Thank you! Indeed it IS a singleport. Yes, that IS a D/P center with S/P end-castings. It allows me tu use my 34 pict 3/4 if I choose to. Which I won't because I'm putting ICT's on it as soon as I can afford the CSP inkage...
As far as the 091 goes? My engine loves it. So do I, especially on the freeway!

I just bought the S/P manis from CB Performance. The dizzy is a VW 205T.

Image may have been reduced in size. Click image to view fullscreen.

ccpalmer · Posted: Fri Nov 04, 2011 8:37 pm Post subject:

Cool; I'd never seen single port end castings.

Micropassatman · Posted: Fri Nov 04, 2011 11:13 pm Post subject:

Brionp · Samba Member Joined: March 18, 2009 Posts: 394

flabay · Posted: Wed Nov 09, 2011 6:47 pm Post subject:

Still needs some tidy work but has been going stong for about 10k now.[/url]
_________________
<<<R.I.P. 74' Euro Weekender
New Old Bus:
78' Champagne Edition Passenger AKA "The Turd"
Still can't figure out how to install this Charcoal Can right with my 40mm dual solex carbs. PM me please.
Click to view image
