| View previous topic :: View next topic |
| Author |
Message |
Ed ke6bnl
Samba Member
Joined: May 16, 2010
Posts: 51
Location: Agua dulce, Ca.
|
 Posted: Thu Dec 30, 2010 1:00 am Post subject: |
 |
|
| Adrenaline Junky wrote: | Hi Ed,
I used this radiator from summit http://www.summitracing.com/parts/SUM-380325
It fit well and the hoses lined up nicely. Found some off the shelf hoses at autozone with the exact size ends that fit like a glove.
I bent up a coat hanger and took it to AZ to find the hoses. I was stoked that I found "exactly" what I needed. The wife coulldn't understand why I was so excited about rubber hoses.... |
thanks for advice, I looked it up and it looks nice like the rest of your project.
For your engine mount did you just use the mounting points below the belts alone or did you catch any points on the side of the block??
I fill fortunate to be able to work off some of the things you did, even with that said many things will fall in place in a differant pattern. My boy is really trying to get me to spend the extra for the rear coil overs so we wont have to do a redo. I will keep my eyes open for some used good ones, I don't have the money to put out like he did for that build. keep up the good work ED |
|
| Back to top |
|
 |
Ed ke6bnl
Samba Member
Joined: May 16, 2010
Posts: 51
Location: Agua dulce, Ca.
|
| Posted: Thu Dec 30, 2010 1:09 am Post subject: |
|
|
| Adrenaline Junky wrote: | Hi Ed,
I used this radiator from summit http://www.summitracing.com/parts/SUM-380325
It fit well and the hoses lined up nicely. Found some off the shelf hoses at autozone with the exact size ends that fit like a glove.
I bent up a coat hanger and took it to AZ to find the hoses. I was stoked that I found "exactly" what I needed. The wife coulldn't understand why I was so excited about rubber hoses.... |
This is what we are starting with and not much will be used other then the roll cage, frame and body, engine, adaptor, and wiring, not sure even about the pressure plate it seems to chatter and lot and is 1700 lbs which is the low end for the one they sell at kennedy, do you know what pressure plate you used and pressure.
I even have a new wide eye one piece front end and will take all the remaining good parts and put on another bug I have to resell.
Ed in So. California |
|
| Back to top |
|
|
Adrenaline Junky
Samba Member
Joined: April 11, 2006
Posts: 256
Location: Roseville, CA
|
| Posted: Mon Jan 03, 2011 11:33 pm Post subject: |
|
|
Hey Ed,
Yes for now I only have the 2 mounting points in the rear. Once I get it running I'll see how it performs under a load and add others if needed. The clutch and presure plate I used are Kennedys 2 stage pressure plate and 6 puck clutch.
Been busy with the holidays and some house projects. In the mean time have been stock piling parts for the next flurry of work to begin soon.
Hope that helps. |
|
| Back to top |
|
|
Ed ke6bnl
Samba Member
Joined: May 16, 2010
Posts: 51
Location: Agua dulce, Ca.
|
| Posted: Tue Jan 04, 2011 12:58 am Post subject: |
|
|
| Adrenaline Junky wrote: | Hey Ed,
Yes for now I only have the 2 mounting points in the rear. Once I get it running I'll see how it performs under a load and add others if needed. The clutch and presure plate I used are Kennedys 2 stage pressure plate and 6 puck clutch.
Been busy with the holidays and some house projects. In the mean time have been stock piling parts for the next flurry of work to begin soon.
Hope that helps. |
I have many projects pending and my boy can't wait to start cutting into this buggy's front end and getting our beam mounted. I did get a fuel filter from a 2005 mustang 14micron for this engine, since I do not see one and want to put in a prefilter from the tank as well, got a updated timing chain tension to put in as time permits, the engine make a racket when I got if from a defective or cloged tensioner, I put in 8 oz of seafoam and 10 min later it was purring but want to change the tensioner any how to the new version.. Will be a slow process unless I sell one of my vehicles first. We built my boys in 6 months of fridays nights on occasion and long Saturadays. and 6 months before that we didn't know what a swing axle was compared to a "IRS" type. We are still learning did have some professional advice on the shock and beam set up and the the care performed perfect on its first trip. One thing I would mention is that our shocks pressure and spring rate and valving was set up for a baja type bug and with the shock angle and not to set it to sit in a certain possition relative to the ground.
 |
|
| Back to top |
|
|
Wheel_Works
Samba Member
Joined: August 05, 2009
Posts: 307
Location: Michigan
|
| Posted: Tue Jan 04, 2011 10:24 am Post subject: |
|
|
Very Nice build.
Working on getting things together for a Ecotec build also. Cut my front end off Sunday night. Looking @ Carbon Fiber Race cut hood right now. I live in Michigan so gonna leave the Heater block in place and Put a Heater Core inside the car. Mines the one on the left
[/url |
|
| Back to top |
|
|
Adrenaline Junky
Samba Member
Joined: April 11, 2006
Posts: 256
Location: Roseville, CA
|
| Posted: Wed Jan 12, 2011 11:23 pm Post subject: |
|
|
Ed ke6bnl that's about where I'm at. i have a pile of Gauges, lights, switches, hundreds of feet of wire. Finishing up some front end fabrication for battery, bumper, lights and them I'm on the the wiring.
Cool Bajas guys!! |
|
| Back to top |
|
|
Ed ke6bnl
Samba Member
Joined: May 16, 2010
Posts: 51
Location: Agua dulce, Ca.
|
| Posted: Thu Jan 13, 2011 12:53 am Post subject: |
|
|
| Adrenaline Junky wrote: | Ed ke6bnl that's about where I'm at. i have a pile of Gauges, lights, switches, hundreds of feet of wire. Finishing up some front end fabrication for battery, bumper, lights and them I'm on the the wiring.
Cool Bajas guys!! |
It is all complete and has been out a few of times, performs excellant, the one weak link the spindles gave out on the last day. and have since been upgrades, and some fine tuning of the weber carb. and best of all everthing worked with wiring on the first try. I laid out the wiring and my boy with his elevator work and wiring experience wired it all up in the evenings. the next thing to do is this week end to install the driver codriver radio system and install the Cat D3 air cleaner. this week getting my extra bug ready for sale so I can get started on the ecotec bug. He is trying to talk me into the same type of build with the coil over and all. But do have lots of good parts for torsion bar suspension with bilstein reservoir shocks etc. to sell of to help pay for the build. |
|
| Back to top |
|
|
Adrenaline Junky
Samba Member
Joined: April 11, 2006
Posts: 256
Location: Roseville, CA
|
| Posted: Tue Jan 25, 2011 11:31 pm Post subject: |
|
|
Got a few hours in the garage last weekend to fill in some of the holes on the front of this thing, add a couple supports and fab up a battery box.
Damn look at all that surface rust on the cage  What's the best way to clean it up before paint? |
|
| Back to top |
|
|
pafree
Samba Member
Joined: August 16, 2005
Posts: 2181
Location: dayton, the one in texas
|
| Posted: Wed Jan 26, 2011 7:24 am Post subject: |
|
|
| Adrenaline Junky wrote: |
Damn look at all that surface rust on the cage What's the best way to clean it up before paint? |
as long as you are not using epoxy paint then a ospho treatment will work.
_________________
1972 vw hunting truggy
sand it, fill it, paint it, throw some mud on it and then baja it. |
|
| Back to top |
|
|
Tompkins
Samba Member
Joined: January 17, 2011
Posts: 192
Location: Beeville Tx
|
| Posted: Wed Jan 26, 2011 10:04 am Post subject: |
|
|
| This build is crazy! It's going to look amazing. |
|
| Back to top |
|
|
Wheel_Works
Samba Member
Joined: August 05, 2009
Posts: 307
Location: Michigan
|
| Posted: Sun Jan 30, 2011 6:02 pm Post subject: |
|
|
I bought my Ecotec today. The guy I bought it from insist I put the mounts on the side of the block. He says that he had problems cause of torque mounting where you did on the rear lower.
Very nice build. I'm glad you decided to share this one. I see alot of good info here. |
|
| Back to top |
|
|
Wheel_Works
Samba Member
Joined: August 05, 2009
Posts: 307
Location: Michigan
|
| Posted: Mon Feb 07, 2011 2:56 pm Post subject: |
|
|
| Any more progress yet? How big of a hole did you have to cut in the firewall/package tray area to get the motor to clear? |
|
| Back to top |
|
|
burleymotorsports
Samba Member
Joined: July 17, 2005
Posts: 120
Location: santa barbara ca.
|
| Posted: Tue Feb 08, 2011 10:31 pm Post subject: |
|
|
cool build, you have a very nice car, gives me energy to finish mine. here's a stupid question, whats ospho treatment ? my project has surface rust on the cage too. Thanks Burley
_________________
www.burleysmotorsports.com world class custom Syncro parts |
|
| Back to top |
|
|
carlos_magnum
Samba Member
Joined: April 21, 2009
Posts: 475
|
| Posted: Wed Feb 09, 2011 11:43 pm Post subject: |
|
|
| That's a fun project. Can't wait to see more progress of it. |
|
| Back to top |
|
|
BSGMotorsports
Samba Member
Joined: February 11, 2011
Posts: 1
Location: Arizona
|
| Posted: Sat Feb 12, 2011 3:43 am Post subject: well i found some rough blueprints.... |
|
|
 this is an amazing build. im glad you are posting these pics and info along the way. i have been searching TheSamba for months now looking at baja projects. i just started on mine. when i was 12 years old my parents bought me a baja for Xmas to play with. and had lots of years of fun with it. now shes gonna get a makeover big time and your posts have given me a lot of insight and ideas for my build....!!!! thanks AJ  |
|
| Back to top |
|
|
Adrenaline Junky
Samba Member
Joined: April 11, 2006
Posts: 256
Location: Roseville, CA
|
| Posted: Wed Feb 16, 2011 10:38 pm Post subject: |
|
|
I finally got around to mounting my offroad lights. Picked up a pair of Lightforce 240 Blitz. They seem like a real nice light for the price online. Took forever for me to decide on how to mount them. Went through 3 revisions until I thought it looked right. Nice thing about metal is if you don't like it, cut it off and weld it on different.
The first rev I thought having the lights up that high looked goofy and I didn't leave enough clearance for the hood.
The second rev just didn't seem to flow right either and the lights now stuck out past the front bumper.
So I cut it all off and came up with this design. Enough room for the hood, a little light protection from the bumper, and just seemed to flow well.... At least I think so...
I tried a pair of Hella 500FF for the main head light. After mounting them I realized I could have fit the Hella 700FF in that hole. Swapped them out and new ones on the way  |
|
| Back to top |
|
|
Adrenaline Junky
Samba Member
Joined: April 11, 2006
Posts: 256
Location: Roseville, CA
|
| Posted: Tue Mar 08, 2011 10:43 pm Post subject: |
|
|
Can't believe this thing has taken 4 years. At least I'm still moving forward. Slow and steady or what ever that saying is.....
Got my new Hella 700FF mounted. They fit so much better. Finally got the skid plates on. That was painful on the wallet. Price of scrap aluminum is through the roof.
Picked this fiberglass dash up from vwinovations. Ralph made me a nice thick one. This alone took half a day to get it to fit through the front window and wrap around the cage. Now I have a ton of realestate for gauges and switches
 |
|
| Back to top |
|
|
Buggy Disaster
Samba Member
Joined: November 21, 2010
Posts: 297
Location: Kennesaw GA
|
| Posted: Wed Mar 09, 2011 3:40 pm Post subject: |
|
|
Nice Buld! Thats a very nice setup with your lights.
Question..
What all have you done to your front beam to accommodate that much ground clearance. What size front tires also? |
|
| Back to top |
|
|
Stingray250
Samba Member
Joined: February 17, 2011
Posts: 204
Location: Texas
|
| Posted: Wed Mar 09, 2011 8:10 pm Post subject: |
|
|
Sweet lookin build... you have any spec's on where the center of gravity might be on this rig and overall vehicle weight? I'd be curious to know how much this "beast" weighs with all that cage and cross over, cross over, cross bracin!!!!
 |
|
| Back to top |
|
|
thesatelliteguy
Samba Member
Joined: January 06, 2007
Posts: 1230
Location: Santa Rosa CA
|
| Posted: Wed Mar 09, 2011 9:22 pm Post subject: |
|
|
I just went through your build quickly, just picture browsing. Man you have a nice ride! Your pretty close to having it done. Man, you got to get on that.
So i was wondering, did you do all that cage with only that bender?
_________________
Toyotas are so bumpy it makes me sick, literally.
My build Page http://www.thesamba.com/vw/forum/viewtopic.php?t=383878 |
|
| Back to top |
|
|
|
