FryDubs 69 Cal Bug Build w/ Pics..........

FryDub

My last thread was a mess, broken picture links etc.. so I had it deleted and i'm starting over.
This was my buddy Daves car back in high school, we graduated in 1989.....Yep, i'm 40.. A little history on the car. Daves neighbor built the car around 84ish, had to sell it because he needed funds so Daves dad bought it for himself. Dave ended up with a crappy mid 70's bug when he turned 16 in 87 and that wasn't cutting it. With enough bitching he convinced his dad to give him this car. It was bad ass.....especially to a 16 yr old. Imagine being 16 and having your dad throw you the keys to a immaculate 69 VW with new paint, velour interior, chrome Mangels with Porsche caps, adjustable beam, a 2180 with dual 44 IDF's, built tranny and alot more. I was a little jealous to say the least. This car saw a lot of races and was the nicest and fastest VW around. We graduated and Dave blew up the engine so he gave the car back to his dad and Dave moved on. So his dad pulled the engine, covered the car and parked it in 91 or so. Daves dad had the long block built for a buggy and kind of forgot about the car. Over the years I kept on him about selling it and he never wanted to, he wanted Dave to have it but he was never really interested. Who wouldn't want their bad ass car from school? In 2007 he finally gave in and said "give me $1200.00 and it's yours".....so I bought it. It came with a 1835 and all the stuff from the 2180 including the Webers. I have been on and off on this thing since but now it's go time. Here is a little time line in pictures. Im pretty stoked about it.
When I picked it up in 07.
Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.

Interior

Back end.

Original mileage.
Image may have been reduced in size. Click image to view fullscreen.

Tore the interior out.
Image may have been reduced in size. Click image to view fullscreen.

New Carpet, old seats.
Image may have been reduced in size. Click image to view fullscreen.

Dash cleaned up, tach and stereo installed.
Image may have been reduced in size. Click image to view fullscreen.

Tried some early fenders, wasn't digging the idea.
Image may have been reduced in size. Click image to view fullscreen.

Found some 4.5 Mangels in 09 and put some 145's on it with new Porsche nipple caps. Toyed with 67 fenders and no bumpers but I want T-bars so off they come and back to the OG fenders.
Image may have been reduced in size. Click image to view fullscreen.

Thats where I left off 2 years ago. New job, family and a move put a hold on things fo a while. Next faze coming up.
_________________
"4 out of 5 voices in my head say Go For It"

FryDub · Posted: Thu Jan 13, 2011 11:30 pm Post subject:

Got the garage dialed in so I brought the car down. Put it on dollies which are awesome to roll it around on.
Image may have been reduced in size. Click image to view fullscreen.

Tore the tank out.
Image may have been reduced in size. Click image to view fullscreen.

Cleaned up some stuff, new M/C, and brake res lines.
Image may have been reduced in size. Click image to view fullscreen.

Throwing my CB drop spindles on it along with new ball joints and brakes. More to come.
_________________
"4 out of 5 voices in my head say Go For It"

FryDub · Posted: Mon Jan 24, 2011 10:12 pm Post subject:

Ive made a little progress. Got my brakes assembled.
Image may have been reduced in size. Click image to view fullscreen.

I pressed in my new clearanced ball joints, threw on my CB drop spindles along with new tie rod ends to go with my flip kit. Should be pretty nice to drive.
Image may have been reduced in size. Click image to view fullscreen.

Got the brakes on and all the new lines. I turned my drums and those are next.
Image may have been reduced in size. Click image to view fullscreen.

Thats all for now.
_________________
"4 out of 5 voices in my head say Go For It"

iaccy · Posted: Tue Jan 25, 2011 5:09 pm Post subject:

cool, I like the history behind it. Nice progress you're making on it too Smile

_________________
'67 Beetle (project) http://www.thesamba.com/vw/forum/viewtopic.php?p=3289202#3289202
OG '63 Beetle http://www.thesamba.com/vw/forum/viewtopic.php?t=444566

FryDub · Posted: Wed Mar 16, 2011 9:36 pm Post subject:

Got the seat rails done for my Beards.....seats are getting sent out for upholstery.
Image may have been reduced in size. Click image to view fullscreen.

Got the build out done for my door speakers. I'm not too hip on the kick panels and obviously you cant fit anything in the stock door locations and have the window cranks work so I did this. I built a frame behind the panel and took out the pocket. The build out is 1/2" MDF wrapped in black vinyl. I would have moved the speaker forward but it didnt look right because the build out had to be so big to cover the pocket. I'm happy with the way it turned out.
Image may have been reduced in size. Click image to view fullscreen.

Picking up the 4pt cage next week and will finish the rear package tray panel for speakers and cut outs for the cage and get the seats back in. Its getting there.
_________________
"4 out of 5 voices in my head say Go For It"

FryDub · Posted: Sun Jun 19, 2011 2:36 pm Post subject:

Making some progress.......
Got my ride height dialed in. Rear is 6 up on the inner and 6 down on the outer, front is 2 inch spindles with a adjustable beam. Those are 195-60/ 15's..........I'm going with 205/70's and that should be the exact look I want.
Image may have been reduced in size. Click image to view fullscreen.

Interior is done. Got my Beards recovered and the rear to match. Im pretty happy with the result.
Image may have been reduced in size. Click image to view fullscreen.

Got my rear speaker panel done, kind of a pain in the ass but worth it.
Image may have been reduced in size. Click image to view fullscreen.

That's it for now.
Fry
_________________
"4 out of 5 voices in my head say Go For It"

FryDub · Posted: Sun Jun 19, 2011 3:05 pm Post subject:

Almost forgot.........I threw a stocker single port 1500 together for it while I finish my 2110. Runs pretty good with the close ratio trans.....Kinda fun.
Image may have been reduced in size. Click image to view fullscreen.

Fry
_________________
"4 out of 5 voices in my head say Go For It"

Mooosman

FryDub · Posted: Sun Jun 19, 2011 3:45 pm Post subject:

Thanks for the props. I bought those caps about 3 years ago. I believe I got them here -----------------> http://www.socalautoparts.com/product_info.php?products_id=15446 They are ok quality, you have to keep them polished and waxed or they will rust super easy. Good luck.
Fry[/url][/list]
_________________
"4 out of 5 voices in my head say Go For It"

EdgeKid3 · Posted: Sun Jun 19, 2011 4:12 pm Post subject:

Car's looking awesome man! Where in SD are you??

FryDub · Posted: Mon Jun 20, 2011 8:01 am Post subject:
