 Posted: Mon Jul 16, 2012 11:23 am Post subject: |
 |
|
| TEXABUS wrote: |
Shot of my cobbled up exhaust with Magnaflow muffler and AFR bung.
 |
how has that setup lasted over the years? the mufflers of these cheaper exhausts are always the first to go, and I to have thought about just getting a nice Magnaflow welded to it... |
|
| Back to top |
|
 |
dreadlocks
Samba Member
Joined: May 20, 2012
Posts: 128
Location: Denver, CO
|
| Posted: Mon Jul 16, 2012 8:07 pm Post subject: |
|
|
| soniq wrote: | looks great.
what all did you end up doing to it? |
It hadn't been tagged nearly a decade before I bought it, runs strong but was leaky (intake & oil) and kept having reliability issues. I re-dressed it with all new sensors, seals, gaskets, grommets, o-rings, hoses, clamps, ignition.. the only big change was swapping out the 009 ditsy and putting in a Bosh SVDA w/Pertronix... all thanks to BusDepot
alot more was done while the engine was out, here's the thread: http://www.thesamba.com/vw/forum/viewtopic.php?t=512873
_________________
2013 4dr Golf TDI w/Technology & Tow pkg
2001 GTI - 3.0L VR6 Turbo
1975 Westfalia - 2.0L Fuel Injected |
|
| Back to top |
|
|
Applesorange
Samba Member
Joined: July 25, 2011
Posts: 8
Location: Minneapolis, MN
|
| Posted: Mon Aug 06, 2012 9:40 am Post subject: I love Craigslist |
|
|
$500 for then engine and a '69 pop-top. Put 7,500 mi on the ending since October 2011, all weather, NO ISSUES! Gotta love it  |
|
| Back to top |
|
|
chrisradioman
Samba Member
Joined: September 20, 2007
Posts: 4085
Location: Swansea (Sunny Penllergaer) Wales UK
|
|
| Back to top |
|
|
chrisradioman
Samba Member
Joined: September 20, 2007
Posts: 4085
Location: Swansea (Sunny Penllergaer) Wales UK
|
|
| Back to top |
|
|
longstrangetrip
Samba Member
Joined: August 04, 2012
Posts: 52
Location: Portland, OR
|
| Posted: Sat Aug 25, 2012 11:41 am Post subject: |
|
|
Here's mine. 71 stock 1600DP, Empi 34"s, and a fancy shmancy lace paint job.
_________________
Come to terms with your ass, for it bears you -J. Muir |
|
| Back to top |
|
|
TequilaSunSet
Samba Member
Joined: May 30, 2012
Posts: 560
Location: Cali Cali
|
| Posted: Sat Aug 25, 2012 12:41 pm Post subject: |
|
|
 Not installed but I think it still counts?
Gutted 1700... throwing in a 1600DP that I will be adding dual Kad's... I hope.
_________________
67 VolksRod in progress
85 Vanagon 1.8t (soon)
Don't harsh my mellow... |
|
| Back to top |
|
|
panic_fan
Samba Member
Joined: April 21, 2008
Posts: 458
Location: Stockbridge GA
|
|
| Back to top |
|
|
kevinj73us
Samba Member
Joined: September 25, 2011
Posts: 74
Location: Laurel, MD
|
| Posted: Fri Nov 02, 2012 10:54 am Post subject: |
|
|
I thought my throttle return spring looked like a kludge, but I see a lot of photos of similar setups in this thread.
kj
_________________
1973 Station Wagon |
|
| Back to top |
|
|
notchboy
Samba Member
Joined: April 27, 2002
Posts: 11315
Location: Seattle WA
|
| Posted: Fri Nov 02, 2012 5:19 pm Post subject: |
|
|
Thats the way they are in a stock set up. I thought it odd for the same reasons too.
_________________
Jason "notchboy" Weigel
1963 Pearl White Sunroof Notch
1964 T34 S Convertible
1974 Westfalia Hardtop Campmobile
1977 Westfalia Camper pop-top
the1500club.com
TOOB Member #5 |
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 23877
Location: Surrey B.C. Canada, Land of the giant flying moose!
|
| Posted: Fri Nov 02, 2012 5:36 pm Post subject: |
|
|
That's correct for a plastic airfilter bus, there's even a little nylon grommet in the decklid hinge crossmember for the spring to hook into.
_________________
Rust NEVER sleeps and stock never goes out of style.
Wanted, 68-73 westy OG plaid curtains, singles OK. |
|
| Back to top |
|
|
Stuartzickefoose
Samba Post Whore
Joined: February 07, 2008
Posts: 5384
Location: Edmonds, WA.
|
| Posted: Fri Nov 02, 2012 7:23 pm Post subject: |
|
|
now i know where to hook dads up
_________________
MINE - 1978 Westfalia ~ Maisy ~ FI, Hydraulic Valves, Electronic Points, 2.0 (NEED A SET OF HEADS, PM ME IF YOU HAVE A SET)
DAD's - 1972 Westfalia ~ Sticky ~ 1.7(?) 914 motor, allison electronic ignition, electric fuel pump, dual webers w/o choke.
“Don't cry because it's over, smile because it happened.”
“Those who mind don't matter, and those who matter don't mind.” |
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 23877
Location: Surrey B.C. Canada, Land of the giant flying moose!
|
| Posted: Fri Nov 02, 2012 7:28 pm Post subject: |
|
|
| Stuartzickefoose wrote: | | now i know where to hook dads up |
Not if Dad's is a 72, they use a special coil bracket with an arm to hook the spring on, completely different linkage too.
_________________
Rust NEVER sleeps and stock never goes out of style.
Wanted, 68-73 westy OG plaid curtains, singles OK. |
|
| Back to top |
|
|
Stuartzickefoose
Samba Post Whore
Joined: February 07, 2008
Posts: 5384
Location: Edmonds, WA.
|
| Posted: Fri Nov 02, 2012 7:38 pm Post subject: |
|
|
| busdaddy wrote: | | Stuartzickefoose wrote: | | now i know where to hook dads up |
Not if Dad's is a 72, they use a special coil bracket with an arm to hook the spring on, completely different linkage too. |
we are missing that bracket then...its got a different motor in it  ill have to find one. i know exactly what your talkin about too, cause my 72 transporter had one on it.
_________________
MINE - 1978 Westfalia ~ Maisy ~ FI, Hydraulic Valves, Electronic Points, 2.0 (NEED A SET OF HEADS, PM ME IF YOU HAVE A SET)
DAD's - 1972 Westfalia ~ Sticky ~ 1.7(?) 914 motor, allison electronic ignition, electric fuel pump, dual webers w/o choke.
“Don't cry because it's over, smile because it happened.”
“Those who mind don't matter, and those who matter don't mind.” |
|
| Back to top |
|
|
billstickly1
Samba Member
Joined: August 03, 2009
Posts: 95
Location: Los Angeles
|
| Posted: Wed Nov 14, 2012 11:01 pm Post subject: |
|
|
Before:
After:
 |
|
| Back to top |
|
|
nathansnathan
Samba Member
Joined: April 14, 2008
Posts: 1222
Location: Laguna Beach, CA
|
|
| Back to top |
|
|
dwdelano
Samba Member
Joined: November 14, 2011
Posts: 26
Location: Williamsburg, VA
|
| Posted: Thu Dec 20, 2012 12:51 pm Post subject: Finally done rebuilding it, time to go back in! |
|
|
Pretty, huh?!
_________________
'73 Pop Top Camper
'72 Super Beetle |
|
| Back to top |
|
|
nathansnathan
Samba Member
Joined: April 14, 2008
Posts: 1222
Location: Laguna Beach, CA
|
| Posted: Thu Dec 20, 2012 1:44 pm Post subject: Re: Finally done rebuilding it, time to go back in! |
|
|
| dwdelano wrote: | | Pretty, huh?! |
Looks like you are missing some things, but it does look pretty so far.
Spark plug wire plastic and metal hold down bits, Timing/flywheel hole cover, for the heater tube grommet that is nla you can use a flex pipe coupler from the hardware store ( rubber things for joining plumbing pipes).
The carb linkage looks like it's ready to bind. I've made spacers to bring the linkage arm throw bolts (?) out so the rod ends can go straight and symmetrically down. It would be nice if someone would offer such a thing pre-made.
While I'm at it, you will be much happier if you regulate the fuel pressure, and I hope you will be securing the fuel lines, probably would be best to use other hose clamps, too.
I guess I would plug the holes behind the heater tube hole, too. I'm wondering if the straight barb by the coil on the fan housing has been sawed off?
Finally , it looks like you will saw through your firewall tin with your throttle cable. |
|
| Back to top |
|
|
dwdelano
Samba Member
Joined: November 14, 2011
Posts: 26
Location: Williamsburg, VA
|
| Posted: Thu Dec 20, 2012 2:11 pm Post subject: Re: Finally done rebuilding it, time to go back in! |
|
|
| nathansnathan wrote: | | dwdelano wrote: | | Pretty, huh?! |
Looks like you are missing some things, but it does look pretty so far.
Spark plug wire plastic and metal hold down bits, Timing/flywheel hole cover, for the heater tube grommet that is nla you can use a flex pipe coupler from the hardware store ( rubber things for joining plumbing pipes).
The carb linkage looks like it's ready to bind. I've made spacers to bring the linkage arm throw bolts (?) out so the rod ends can go straight and symmetrically down. It would be nice if someone would offer such a thing pre-made.
While I'm at it, you will be much happier if you regulate the fuel pressure, and I hope you will be securing the fuel lines, probably would be best to use other hose clamps, too.
I guess I would plug the holes behind the heater tube hole, too. I'm wondering if the straight barb by the coil on the fan housing has been sawed off?
Finally , it looks like you will saw through your firewall tin with your throttle cable. |
All taken care of after it went in  Except for the carb linkage spacers you mentioned....is there a pic of that anywhere on here that I could see what you're talking about? I found that it DID bind a bit before I tightened everything up, but once tight, the action seems to be quite good....but I can understand your point about getting those rods more vertical.
EDIT: Nevermind about the pic....I found a pic in your gallery where you can see the right one. Good idea.
_________________
'73 Pop Top Camper
'72 Super Beetle |
|
| Back to top |
|
|
nathansnathan
Samba Member
Joined: April 14, 2008
Posts: 1222
Location: Laguna Beach, CA
|
| Posted: Fri Dec 21, 2012 6:50 am Post subject: |
|
|
I made them out of aluminum. They have to be different lengths, at least for the Dellortos I'm running. You can see the hardware store heater tube plug action, too. It is just a bit messy in there with the fuel pump relay and the fan wires. For the firewall throttle cable you can see just a bit of the aluminum L brackets that I have holding up a marine sheeve I'm using to redirect.
 |
|
