Trouble adjusting front brakes; 63 bug
Forum Index -> Beetle - 1958-1967 Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
crowther
Samba Member


Joined: May 07, 2009
Posts: 63
Location: Central Virginia
crowther is offline

PostPosted: Tue Mar 23, 2010 5:28 pm    Post subject: Trouble adjusting front brakes; 63 bug Reply with quote

I just bled the brakes to see if that would correct the squishy pedal and uneven braking (pulling to left). It greatly improved the pedal feel but still pulled, so I began the adjusting process. Worn adjusters probably made the job a bit more frustrating, but I followed standard procedure. Did each adjuster (2 per cylinder), tightening till slight drag, then back off a couple clicks, for each shoe. Thought I had it right, but now pulls to the right. It was late so I quit there.

This could go on and on. Is there a trick to getting better adjustment w/o doing it over and over? Last time I did brake work ona car the drum brakes had self-adjusters and I was spoiled.
_________________
Paul
63 Bug, just because
57 MGA for the sunny days
82 911SC daily driver
12 MiniCooper ALL4
04 F150 for big jobs
2 car garage for all of this
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Eric&Barb
Samba Member


Joined: September 19, 2004
Posts: 20892
Location: Olympia Wash Rinse & Repeat
Eric&Barb is offline

PostPosted: Tue Mar 23, 2010 6:44 pm    Post subject: Reply with quote

No. You just have to adjust them correctly, or get someone else to do it for you.
_________________
In Stereo, Where Available!
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Egorspyle65
Samba Member


Joined: March 06, 2009
Posts: 249
Location: Easley SC
Egorspyle65 is offline

PostPosted: Tue Mar 23, 2010 7:31 pm    Post subject: Reply with quote

Ive always been told you have to adjust drum brakes till they have a very slight drag. Its always worked for me. Was told this by a very reputable VW shop nearby.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
drscope
Samba Member


Joined: February 19, 2007
Posts: 15273
Location: Baltimore, Maryland USA
drscope is offline

PostPosted: Tue Mar 23, 2010 7:50 pm    Post subject: Reply with quote

Adjust until you have a slight drag and then back it off ONE click - not a couple clicks.

Pulling can also be caused by oil, grease or brake fluid leaking into the drum. This may also explain your squishy pedal.

you may want to pull the drums off and take a look inside.

And if you don't know how old your rubber flex lines are, it might be time to replace them. They can also make for some strange brake habits when they start to go bad.
_________________
Mother Nature is a Mean Evil Bitch!
Back to top
View user's profile Send private message Gallery Classifieds Feedback
vdubmyk
Samba Member


Joined: October 24, 2008
Posts: 456
Location: Corona, CA
vdubmyk is offline

PostPosted: Tue Mar 23, 2010 8:47 pm    Post subject: Reply with quote

always adjust first and then bleed the system. If your brake hoses are collapsed it will definitely pull one way. They might "look" ok but they fail internally. If they look old, peace of mind will say replace them. One way to tell of a collapsed line is to raise the wheels off the ground and have a buddy hold the pedal down while you try to spin the wheel. If you cannot spin the wheel then you have good pressure and have him/her release the pedal, as you are trying to spin it. It should release right away, if it takes a second or two, your lines are probably restricted and need replacing. This is good for all four wheels. When I worked at a VW shop, that is how we checked them.
_________________
64 stock bug, 12V (converted 6v unit), 40 hp, all documents even sales contract and dealer window sticker!
Back to top
View user's profile Send private message Gallery Classifieds Feedback
79SuperVert Premium Member
Samba Member


Joined: May 31, 2002
Posts: 9757
Location: Elizabeth, NJ & La Isla Del Encanto
79SuperVert is offline

PostPosted: Wed Mar 24, 2010 8:18 am    Post subject: Reply with quote

What worked for me was first adjusting them first until they don't move at all, then pumping a lot, bleeding, and then adjusting for a slight drag.
_________________
Central Jersey VW Society

Wanted: Art Collins VW (Savannah, Georgia) items - license plate surrounds and other items. Also ivory "AM", "FM" and "SW" buttons for a US Blaupunkt Frankfurt.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Itawayoflife
Samba Member


Joined: February 20, 2006
Posts: 1181
Location: Buena Park,CA
Itawayoflife is offline

PostPosted: Wed Mar 24, 2010 10:58 am    Post subject: Reply with quote

I think everybody has their own method. I adjust the pads until they can't go anymore, pump the brakes a couple of times and then back them off 1 or 2 clicks or until I get one full rotation when I spin the wheel.
_________________
The quest continues...
Back to top
View user's profile Send private message Yahoo Messenger Gallery Classifieds Feedback
