Ok what gives? Engine locked up

[Bashr52]

So my dad drove his 72 to a local car show 2 weeks ago. He made it there and back no problems. When he got home it was running great like always, he pulled into the garage and shut it off. Last week he rolled it out, and tried to start it. The solenoid just kicked and nothing. So we pulled the starter, found a faulty/intermittent solenoid and replaced.We also made sure the battey was fully charged. Same deal. Today I installed an autostick shift starter we had bought for it a while back, and no change. So after checking all the wiring/grounds and battery connections, I pulled his pulley guard and put a wrench on the pulley nut. That sucker is locked up tight! Pulled the valve covers and everything is tight and clean. So wtf would make a good engine just lock up after sitting almost a week? Oil pressure and everything was good when he drove it home and parked it. I did pull the plugs to see if it would help or mabie was hydro locked (we have been smelling some gas). No difference.

[mharney]

That's messed up.

- in gear
- obstruction in bellhousing
- pulley welded to case
- distributor drive damage (rotating while distributor is out)
- starter now jammed on flywheel gear
- water got in and froze rings
- damage from excessive endplay
- obstruction in cylinder

Put it in gear and roll it backwards a little to see if you can back it up and free it.. if you can then carefully rotate it back forward and see if you can tell where it locks up.. what is the pulley position?

[Bashr52]

It is not in gear, and unless something in the trans broke and is jammed thats not it. I may try removing the started again and see if something frees up. endplay is tight, motor has mabie 100-150 miles on it. I did take a long ass crescent wrench and put it on it. I got it to turn but it is extremely tight. I guess we will have to drop it if I can't find anything and see whats up.

[Bill271]

Youve seized a main bearing, prob the snout or the thrust if theres no end play DONT TURN IT ANYMORE you will destroy tthe dowel holes

[The Noof]

I put money on thrust bearing seizure.

[Bill271]

50/50 illtake that bet

[Terry Cloyd]

I would pull the plugs and remove the gen belt. Use a 12" crescent wrench on the front pully and see if you can turn the motor over. Make sure your not in gear.

[Bashr52]

I dont get how it seized juast sitting though, like I said he drove it in, turned it off, and now its locked up. We did seize the #1 just after rebuild due to a plugged oil gallery, but that stopped the motor dead on the run stand, and after we re-cleaned everything, all has been well.

[VSarge]

Usually that means it was about to seize when he parked it. Been there, done it, got the t-shirt and used it for an oil rag.

Sarge
_________________
_________________
VW trike -- FrankenMutt
1971 1600
Swing Arm frame
Stock 4 spd tranny - no reverse gate (crap!)
1966/67 rear brakes wheel cylinders from front of 1966 Bug
1934 Chevy headlight
Custom leading link front end
Ford Ranger rims
P225/60R15 rear tires
GoldWIng front tire
Body is fiberglass nose from semi
One ugly exhaust, heavily rusted, set up for heat??? On a trike??

[A.J.Sims]

Did you install a new pulley on the motor? If so check if it seized onto the case!
Do you start the car with the clutch pressed in? If so that will starve the thrust shims of oil during start up and can cause the rear main to seize.
_________________
Have tech questions? Need real help? Give us a call.
www.Lowbugget.com
982 North Batavia A4, Orange Ca 92867.
68 drag bug 1915cc 10.50's @130mph
66 fastback 2387cc turbo street car
67 baja 2054cc turbo.

[gilbequick]

[hpw]

[boleador]

[A.J.Sims]

So you’re told to do it so it must be OK? That’s one way!!!
_________________
Have tech questions? Need real help? Give us a call.
www.Lowbugget.com
982 North Batavia A4, Orange Ca 92867.
68 drag bug 1915cc 10.50's @130mph
66 fastback 2387cc turbo street car
67 baja 2054cc turbo.

[dog_jr911]

i was taught tho push the clutch pedal down when starting the car, a precaution in case it was in gear.

so it pushes the whole crank back, thus cutting oil flow?
_________________
AKA Chris™
ROCKIN a ESP LTD F2E

[A.J.Sims]

Bingo!!! Nothing like a “performance” stage 1 or 2 pressure plate applying over 170 to 250lbs of force to your one and only thrust bearing. Now that stock p/p was applying less than 90lb’s but most of us have a stage 1 or 2 and some a stage 3 P/P on our combos. I know that when you have a Toyota or other new cars with a stick you must depress the clutch pedal in order to start the thing but not you’re VW! Now I’m not saying this is the problem but it’s a good habit to brake, mostly on new motors that do not have that many miles on them.
_________________
Have tech questions? Need real help? Give us a call.
www.Lowbugget.com
982 North Batavia A4, Orange Ca 92867.
68 drag bug 1915cc 10.50's @130mph
66 fastback 2387cc turbo street car
67 baja 2054cc turbo.

[Iowa Mark]

Pull your plugs and check for hydrolock. Oil smell like gas?

[bugninva]

[Ruffturn]

[shok]
