| Author |
Message |
tr97
Samba Member
Joined: June 01, 2008
Posts: 1
Location: ohio
|
 Posted: Sun Jun 01, 2008 3:33 pm Post subject: 1972 Super Beetle seats |
 |
|
HOW DO I REMOVE THE SEATS FROM A 1972 SUPER BEETLE
THANKS |
|
| Back to top |
|
 |
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79240
Location: Sneaking up behind you
|
| Posted: Sun Jun 01, 2008 3:34 pm Post subject: |
|
|
CAPS OFF please.
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
BrockGrimes
Samba Member
Joined: September 18, 2006
Posts: 1015
Location: Clovis, NM
|
|
| Back to top |
|
|
keifernet
Samba Search & Rescue
Joined: May 11, 2002
Posts: 19395
Location: Samba Center for Behavioral Science
|
|
| Back to top |
|
|
realbugfanatic
Samba Member
Joined: May 03, 2006
Posts: 484
Location: SW Michigan
|
| Posted: Mon Jun 02, 2008 6:09 am Post subject: |
|
|
I believe they drop out the bottom like the engine. >kidding<
Correct me if I'm wrong, but I believe a '72 is somewhat similar to a '73: Get on your knees beside the car & look under the seat, see that safety catch at the front center? Hold that open with a screwdriver & you'll see how to slide it out. Makes sense once you can see it. |
|
| Back to top |
|
|
ts88
Samba Member
Joined: March 11, 2008
Posts: 269
Location: Eugene, Oregon
|
| Posted: Mon Jun 02, 2008 6:17 am Post subject: |
|
|
They come out the front, There is a tab on the tunnel side rail (front) Push it down and slide the seat out. Good luck. Pat
_________________
I would rather be a Conservative nut job, than a Liberal with no nuts and no job
There is no sense in being stupid if you can't prove it.
"To call an illegal immigrant an "undocumented alien" is the same as calling a streetcorner drug dealer an "unlicensed pharmacist". |
|
| Back to top |
|
|
Scott H
Samba Luddite
Joined: August 15, 2003
Posts: 3026
Location: NorthCarolina,USA
|
| Posted: Mon Jun 02, 2008 6:22 am Post subject: |
|
|
Yet another confusing thread about seat removal ...
For a '72 there are no bolts and it is not like a '73.
They slide out toward the front. Remove the big extension spring underneath the seat first, then each seat has a spring tab on the right side that has to be depressed as you hold the adjustment lever up and push the seat forward. It helps to have three hands.
Take the right seat out first so that it's easier to access the spring tab for the left seat.
It's shown in the '72 owner's manual:
*edit - ts88 said it much simpler while my slow typing was happening.
_________________
Scott
| oc92 wrote: |
| I like the soul of an old car to be visible... |
|
|
| Back to top |
|
|
ts88
Samba Member
Joined: March 11, 2008
Posts: 269
Location: Eugene, Oregon
|
| Posted: Mon Jun 02, 2008 2:28 pm Post subject: |
|
|
Thanks Scott, but your post has a page right from the BOOK!!
_________________
I would rather be a Conservative nut job, than a Liberal with no nuts and no job
There is no sense in being stupid if you can't prove it.
"To call an illegal immigrant an "undocumented alien" is the same as calling a streetcorner drug dealer an "unlicensed pharmacist". |
|
| Back to top |
|
|
jamesdagg
Samba Member
Joined: August 18, 2007
Posts: 3364
Location: B.C.Canada
|
| Posted: Mon Jun 02, 2008 9:41 pm Post subject: |
|
|
If they are stuck get in the back and push with your feet while someone else holds the lever and tab. Tell the someone else to keep their head out of the path of the seat because it can release suddenly and shoot forward. (lost more wives that way)
jim
_________________
'72 FI Westy
'71 Super rear inside defrost vents no longer available |
|
| Back to top |
|
|
Raggamuffin
Samba Member
Joined: July 18, 2006
Posts: 789
Location: GA
|
| Posted: Tue Jun 03, 2008 4:36 am Post subject: |
|
|
| jamesdagg wrote: |
...keep their head out of the path of the seat because it can release suddenly and shoot forward. (lost more wives that way)
jim |
I love the helpful pointers on the Samba! "Honey, can you give me a hand with the car for just a sec..." |
|
| Back to top |
|
|
72supervw
Samba Member
Joined: April 21, 2007
Posts: 20
Location: east coast
|
| Posted: Wed Jun 04, 2008 2:10 pm Post subject: 1972 Super Beetle Seats |
|
|
What if the passenger's seat is all the way back and stuck. And I mean stuck. I don't see how there is enough room to even get a rubber mallet in there.
Speaking of manuals. My insurance co. said the Super Beetle is classified as a "high performance vehicle"  . They were not joking. I said if that was the case I wanted the "safety feature" discount for the "break a way" steering wheel and locking tensioners on the seat belt. The insurer was dying laughing at this point and said if I faxed them a copy of it from a manual, NOT the internet, they would. (I think they posted it on their wall.) UN B LIEVABLE. |
|
| Back to top |
|
|
Gary
Person of Interest
Joined: November 01, 2002
Posts: 17069
Location: 127.0.0.1
|
| Posted: Wed Jun 04, 2008 2:17 pm Post subject: Re: 1972 Super Beetle Seats |
|
|
| 72supervw wrote: |
What if the passenger's seat is all the way back and stuck. And I mean stuck. I don't see how there is enough room to even get a rubber mallet in there.
Speaking of manuals. My insurance co. said the Super Beetle is classified as a "high performance vehicle" . They were not joking. I said if that was the case I wanted the "safety feature" discount for the "break a way" steering wheel and locking tensioners on the seat belt. The insurer was dying laughing at this point and said if I faxed them a copy of it from a manual, NOT the internet, they would. (I think they posted it on their wall.) UN B LIEVABLE. |
Spray some PBlaster on the runners and let it soak for a while and then repeat. Squeeze yourself or a strong friend in the back seat while the other person holds the seat lever and PUSH (grunting and swearing will be required). Been there, done that, and own the t-shirt.
_________________
West Virginia State Board of Education v. Barnette, 319 U.S. 624 (1943) |
|
| Back to top |
|
|
Scott H
Samba Luddite
Joined: August 15, 2003
Posts: 3026
Location: NorthCarolina,USA
|
| Posted: Wed Jun 04, 2008 7:04 pm Post subject: Re: 1972 Super Beetle Seats |
|
|
| 72supervw wrote: |
| Speaking of manuals. My insurance co. said the Super Beetle is classified as a "high performance vehicle" . They were not joking. |
This is how you make it high performance:
_________________
Scott
| oc92 wrote: |
| I like the soul of an old car to be visible... |
|
|
| Back to top |
|
|
GreaseC
Samba Member
Joined: May 26, 2008
Posts: 78
Location: Washington St.
|
| Posted: Wed Jun 04, 2008 7:14 pm Post subject: |
|
|
Step 1- Grab your owners manual (or goto the tech/manual section of samba)
Step 2- Look it up
Step 3- Do as it says
Done |
|
| Back to top |
|
|
Baja Champ SE
Samba Member
Joined: June 09, 2007
Posts: 442
|
| Posted: Tue Jul 22, 2008 10:38 pm Post subject: |
|
|
Decided to bring this thread back rather than start my own.
72 Super, same seat design. I know how to take them out by sliding forward, depressing the tab, and pushing them forward until off the track.
Now my question deals with the spings underneath. The springs were disconnected when I bought the car. Finally, I've gotten around to wanting to reconnect them and I can't see anywhere to attach the springs on the seats themselves. I've reattachhed the springs on a 71 super and for the life of me cannot remember what they hooked on to.
Pictures are always nice. Thanks in advance because I know it's a simple fix...unlesss a PO hacked something.
_________________
-1972 Baja Champion SE Super Beetle "Frank the Freak"
SOLD
-1969 Deluxe Bus "Warhaul" aka "Project Whitestock"
Air Speed VW Club of So Cal
Member Since July 2007 |
|
| Back to top |
|
|
Baja Champ SE
Samba Member
Joined: June 09, 2007
Posts: 442
|
| Posted: Wed Jul 23, 2008 10:16 am Post subject: |
|
|
Anybody?
_________________
-1972 Baja Champion SE Super Beetle "Frank the Freak"
SOLD
-1969 Deluxe Bus "Warhaul" aka "Project Whitestock"
Air Speed VW Club of So Cal
Member Since July 2007 |
|
| Back to top |
|
|
redneckracing
Samba Member
Joined: July 21, 2008
Posts: 6
|
| Posted: Wed Jul 23, 2008 10:29 am Post subject: |
|
|
| Since this is a seat topic, anyone know where to find a rear seat for a 68 beetle? |
|
| Back to top |
|
|
Gary
Person of Interest
Joined: November 01, 2002
Posts: 17069
Location: 127.0.0.1
|
| Posted: Wed Jul 23, 2008 10:42 am Post subject: |
|
|
| MGBaja_Smurf wrote: |
Decided to bring this thread back rather than start my own.
72 Super, same seat design. I know how to take them out by sliding forward, depressing the tab, and pushing them forward until off the track.
Now my question deals with the spings underneath. The springs were disconnected when I bought the car. Finally, I've gotten around to wanting to reconnect them and I can't see anywhere to attach the springs on the seats themselves. I've reattachhed the springs on a 71 super and for the life of me cannot remember what they hooked on to.
Pictures are always nice. Thanks in advance because I know it's a simple fix...unlesss a PO hacked something. |
Study the pic Scott posted above. You should see a point on the floor as well as the seat where the spring connects. If you have trouble, drop me a PM and I'll snap some pics of my car as the interior has been stripped.
| redneckracing wrote: |
| Since this is a seat topic, anyone know where to find a rear seat for a 68 beetle? |
Sure. Post a "Wanted" ad in the classifieds.
_________________
West Virginia State Board of Education v. Barnette, 319 U.S. 624 (1943) |
|
| Back to top |
|
|
Baja Champ SE
Samba Member
Joined: June 09, 2007
Posts: 442
|
| Posted: Wed Jul 23, 2008 11:46 am Post subject: |
|
|
There's no tab with a hole on my seats. PO hack? There are small holes on the back of the seat frames.
_________________
-1972 Baja Champion SE Super Beetle "Frank the Freak"
SOLD
-1969 Deluxe Bus "Warhaul" aka "Project Whitestock"
Air Speed VW Club of So Cal
Member Since July 2007 |
|
| Back to top |
|
|
|
