 Posted: Wed Feb 14, 2024 3:48 pm Post subject: Porsche Phone dial questions |
 |
|
I have a 68 ghia and a set of late phone dial rims, 15/7" 52mm offset. I am going to be installing disks on all for corners. I am not concerned with the fitment on the front as I plan to run a narrowed beam. My concern is the rear. will the rims fit with out body mods? I have seen many ghias with phone dials but I know there are a couple different variety's and off sets that were available.
_________________
So Many Hobbies,
So little time!! |
|
| Back to top |
|
 |
Mike Fisher
Samba Member
Joined: January 30, 2006
Posts: 18052
Location: Eugene, OR
|
| Posted: Wed Feb 14, 2024 5:03 pm Post subject: Re: Porsche Phone dial questions |
|
|
I don't think they will fit.
Mount some cheap used tires to test fit them.
I have 185x60 & 205x70 on 5.5"x15" 730P www.Mobelwagen.com wheels.
_________________
69 FI/AT square Daily Driver
66 sunroof,67,70,71,71,71AT,72,72AT,73 Parts
two 57 oval ragtops sold
'68 Karmann Ghia sold
Society is like stew. If you don't keep it stirred up you end up with a lot of scum on the top! - Russ_Wolfe/Edward Abbey |
|
| Back to top |
|
|
NJ John
Samba Member
Joined: September 21, 2007
Posts: 3024
Location: HdG, MD & NJ
|
| Posted: Thu Feb 15, 2024 8:16 am Post subject: Re: Porsche Phone dial questions |
|
|
There are 15x6” phone dials. Also, some ghia owners have narrowed rear control arms. Then you could stuff that 15x7 in there.
_________________
1973 standard, yellow, lowered, 3” narrowed front, 1600 blo-thru turbo w/single dell 15.4@86, so far
11.41 et buggy. Long gone
Let’s go O’s! Let’s go O’s!
https://www.youtube.com/@AirSpooledGarage |
|
| Back to top |
|
|
Car32
Samba Member
Joined: June 19, 2020
Posts: 40
Location: Colorado
|
| Posted: Thu Jun 20, 2024 4:05 pm Post subject: Re: Porsche Phone dial questions |
|
|
I know you posted this four months ago but, if you're still seeking answers, here's one:
I run 15x6 Phone Dials on my 1971 Ghia. The offset is 52 mm.
On the front, I needed a 10mm spacer to keep the tires (195-50) from rubbing on the inside.
On the rear, I likewise added a 10mm spacer but that was for vanity's sake since I wanted to run the center caps and they interfered with the axle nuts without the spacers.
For what it's worth, I have 2-1/2" drop spindles on a standard-height and standard-width beam and I had to grind the inside of my Phone Dials about 3/'16" around the inner lips to keep them from rubbing the fronts of the ball joints. Even now, if I have the wheel turned while hitting a bump, the inner part of the wheel rim rubs the ball joint, just barely.
In the rear, I trimmed the upper frame horns so the tires wouldn't rub. I'm dropped about 2-1/2" back there, like the front.
_________________
First Car = 1970 Westfallen Typ II
Second Car = 1966 Baja
Nth Car = 2006 Cayman S
1971 Karmann Ghia Coupe |
|
| Back to top |
|
|
Bruce
Samba Member
Joined: May 16, 2003
Posts: 17658
Location: Left coast, Canada
|
| Posted: Thu Jun 20, 2024 8:26 pm Post subject: Re: Porsche Phone dial questions |
|
|
| curtw_944 wrote: |
I have a 68 ghia and a set of late phone dial rims, 15/7" 52mm offset.
I am not concerned with the fitment on the front as I plan to run a narrowed beam. |
A narrowed beam with that offset wheel is a mistake. You won't be able to turn very much, and a U-turn will be impossible.
Those wheels will absolutely not fit the rear. The best bet is to sell your wheels and find some 6x15s.
