 Posted: Sun May 11, 2025 3:23 am Post subject: 65 wiper pivot size question |
 |
|
The pivots on my car are missing the circlips at the top that retain the shaft located to the sleeve. I happen to be in the US and thought I’d pop into an Ace Hardware and see if they have some thing that works. Can someone tell me the dia I should look for?
Thanks,
Byas
_________________
1971 1302LS Convertible (RHD) owned since '74
Click to view image
1965 Karmann Ghia Coupe - under restoration
1966 Fiat 1500 Cabrio (with 1600 Twin cam)
1952 Citroen TA 11BL |
|
| Back to top |
|
 |
runamoc
Samba Member
Joined: June 19, 2006
Posts: 6027
Location: 37.5N 77.1W
|
| Posted: Mon May 12, 2025 8:20 am Post subject: Re: 65 wiper pivot size question |
|
|
| Quote: |
| dia I should look for? |
Take it with you to Ace and size it up there.
_________________
Daily driver: '69 Baja owned 45 yrs - Plan B: '72 Ghia
Yard Art: 2 Sandrails
Outback: '69 Ghia - '68,'69,'70,'72 Beetle - '84 Scirocco, GTI - Pair of '02 Golfs- '80 Rabbit Diesel
VW Wiring = It's just wires |
|
| Back to top |
|
|
bnam
Samba Member
Joined: July 02, 2006
Posts: 3436
Location: El Dorado Hills CA/ Bangalore, India
|
| Posted: Mon May 12, 2025 11:42 am Post subject: Re: 65 wiper pivot size question |
|
|
Wiper pivot is in India with the car.
_________________
1971 1302LS Convertible (RHD) owned since '74
Click to view image
1965 Karmann Ghia Coupe - under restoration
1966 Fiat 1500 Cabrio (with 1600 Twin cam)
1952 Citroen TA 11BL |
|
| Back to top |
|
|
Rome
Samba Member
Joined: June 02, 2004
Posts: 10430
Location: Pearl River, NY
|
| Posted: Tue May 13, 2025 12:07 am Post subject: Re: 65 wiper pivot size question |
|
|
| I checked 2 old 6 V single-speed wiper assemblies I have in the basement. Shaft diameter ranges from 5.9 to 6.1 mm (0.23" - 0.24"). A circlip for 1/4" (0.25") might be slightly too big, and bending a clip made of spring steel is probably useless. You could buy a few 1/4" to try bending once you're home, but also buy a pair of 1 size smaller, since its unlikely that ACE would have metric sized circlips. |
|
