| Author |
Message |
denis4x4
Samba Member
Joined: September 04, 2024
Posts: 33
Location: Durango CO
|
 Posted: Fri Nov 07, 2025 8:24 am Post subject: Changing DB bodies on short chassis |
 |
|
I have a Mini-T manual and it appears that the chassis shortening procedure is different than the standard Manx-style chassis chop. Can anyone confirm that? The reason I'm asking, is I'm considering a different body for my project. |
|
| Back to top |
|
 |
MrGoodtunes
Samba Member
Joined: May 14, 2012
Posts: 1056
Location: South Florida
|
| Posted: Fri Nov 07, 2025 9:22 am Post subject: Re: Changing DB bodies on short chassis |
|
|
(1) What does your Mini-T manual show as being its wheelbase?
(2) What does your buggy (it's not a Mini-T) wheelbase actually measure?
Note that the Manx (and many clones) use 80" wheelbase (front axle to rear axle). |
|
| Back to top |
|
|
denis4x4
Samba Member
Joined: September 04, 2024
Posts: 33
Location: Durango CO
|
| Posted: Fri Nov 07, 2025 11:44 am Post subject: Re: Changing DB bodies on short chassis |
|
|
| WB is 79-3/4". I know it's not a Berry Mini-T...not sure of the manufacturer. Built my first DB in 1965 and several Kellisons in the early 70's. |
|
| Back to top |
|
|
denis4x4
Samba Member
Joined: September 04, 2024
Posts: 33
Location: Durango CO
|
| Posted: Fri Nov 07, 2025 12:06 pm Post subject: Re: Changing DB bodies on short chassis |
|
|
|
|
| Back to top |
|
|
EVfun
Samba Member
Joined: April 01, 2012
Posts: 6351
Location: Seattle
|
| Posted: Fri Nov 07, 2025 1:13 pm Post subject: Re: Changing DB bodies on short chassis |
|
|
That shows how the Mini-T style shortening is different. You can see the pedal assembly and the shifter have been moved back in the tunnel. With a Manx style body those are left in their original location.
I used a Manx style frame to mount a Mini-T body by using an aftermarket pedal assembly and a deeply angled shifter handle. Putting a Manx style body on a Mini-T style chassis I think would require a good bit of welding.
_________________
| Wildthings wrote: |
| As a general rule, cheap parts are the most expensive parts you can buy. |
|
|
| Back to top |
|
|
|
