 Posted: Wed May 17, 2006 4:24 pm Post subject: front beam bushings |
 |
|
| Anybody know where i can get new bushings for the front beam of a 1960 bus? |
|
| Back to top |
|
 |
diy570
Samba Member
Joined: September 19, 2003
Posts: 1062
Location: Maggie Valley, NC
|
| Posted: Wed May 17, 2006 4:53 pm Post subject: |
|
|
| wagens west had them for sale. 15 each or something |
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Wed May 17, 2006 5:32 pm Post subject: Re: front beam bushings |
|
|
| bullifecal wrote: |
| Anybody know where i can get new bushings for the front beam of a 1960 bus? |
Which bushings are you referring to? Link pin bushings or torsion arm bushings? |
|
| Back to top |
|
|
gatorwyatt
Samba Member
Joined: April 24, 2002
Posts: 1885
Location: Clearwater Fl.
|
| Posted: Wed May 17, 2006 7:24 pm Post subject: |
|
|
if you are reffering to the beam bushings the torsion arms ride on, i bought mine from isp west.they were not going in unless you press them in and they also needed to be fitted via hone. not hard or rocket science just lots of patience to get them to fit.
good luck.
_________________
www.blastserv.com
wanted:
Nothing! |
|
| Back to top |
|
|
bullifecal
Samba Member
Joined: April 24, 2005
Posts: 119
Location: south
|
| Posted: Wed May 17, 2006 7:52 pm Post subject: bush |
|
|
| I'm referring to the big bushings inside the beam. Thanks for the help |
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Wed May 17, 2006 10:45 pm Post subject: |
|
|
I used a drift and a big hammer to drive in the bushings. This was the hardest part of the job. |
|
| Back to top |
|
|
gatorwyatt
Samba Member
Joined: April 24, 2002
Posts: 1885
Location: Clearwater Fl.
|
| Posted: Thu May 18, 2006 4:01 am Post subject: |
|
|
remember they are made out of bakeolite or something ,very brittle.dont fuck em up
_________________
www.blastserv.com
wanted:
Nothing! |
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Thu May 18, 2006 8:13 am Post subject: |
|
|
| gatorwyatt wrote: |
| remember they are made out of bakeolite or something ,very brittle.dont fuck em up |
The workshop manual calls for this drift along with a big hammer. I'll use a press when I do the set for the yellow '56 Westy but when I did the '56 I didn't pull the beam. |
|
| Back to top |
|
|
busracer
Samba Member
Joined: January 24, 2002
Posts: 725
|
| Posted: Thu May 18, 2006 8:26 am Post subject: |
|
|
| ive got that drift but no reamer. me wanty reamer. |
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Thu May 18, 2006 8:37 am Post subject: |
|
|
| busracer wrote: |
| ive got that drift but no reamer. me wanty reamer. |
They turn up on eBay every few months or so and usually fetch between $100-$300 depending on who's looking at them. |
|
| Back to top |
|
|
Saggs
Samba Member
Joined: December 23, 2003
Posts: 669
Location: Lincolnton, NC
|
| Posted: Thu May 18, 2006 12:39 pm Post subject: |
|
|
I've got the same type of bushings in my 56 oval. How did you get the old ones out? I was thinking to cut throuhh them w/ a sawzall and remove them in 2-3 pieces. I tried a slide hammer w/ no luck
_________________
"One man can make a difference...Jesus did." |
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Thu May 18, 2006 12:42 pm Post subject: |
|
|
| Saggs wrote: |
| I've got the same type of bushings in my 56 oval. How did you get the old ones out? I was thinking to cut throuhh them w/ a sawzall and remove them in 2-3 pieces. I tried a slide hammer w/ no luck :cry: |
The bushings are slightly smaller in size in an oval. The "Tools of local manufacture" book has instructions on how to make a tool to remove these. It's basicly a drift similar to the drum race drifts but mounted on the end of a 4' pole. Don't forget to pull out your grease fittings. The workshop manual also shows a "puller" for the bushings but that would be a bit more challenging to make.
As the old saying goes, "if they ain't broke don't fix it". Measure you're bushings and if they're within spec., leave them there..... |
|
| Back to top |
|
|
|
