Removing Front Torsion Bars - HELP
Page: Previous  1, 2
Forum Index -> Bay Window Bus Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
wclark4000
Samba Member


Joined: May 06, 2008
Posts: 7
Location: S.F. Bay Area
wclark4000 is offline

PostPosted: Thu Jan 29, 2015 11:21 am    Post subject: Dust caps Reply with quote

Greetings...

I can't seem to figure out how to remove the dust caps. I have cleared the muck and see the cap and a ring that was peened in three places, and I have frozen myself there in concern that if I just slip a chisel type instrument under the peening it will either work, or destroy an unobtainable part.

Any suggestions?

Bill
CA Central Valley
Halfway between Manteca and Modesto
Back to top
View user's profile Send private message Send e-mail Classifieds Feedback
jtauxe
Samba Member


Joined: September 30, 2004
Posts: 4667
Location: Los Alamos, New Mexico
jtauxe is offline

PostPosted: Mon Feb 09, 2015 3:30 pm    Post subject: Reply with quote

Does anyone know sources for the bushings and bearings for the torsion arms. The front end on Bluebird (a double cab) was not given proper maintenance by previous owners, and it is all dry and FUBAR in there.

So, are new bearings and bushings available?
_________________
John
"The bus came by and I got on. That's when it all began..." - Garcia/Weir/Kreutzman
http://vw.tauxe.net
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
crummytransporter
Samba Member


Joined: July 01, 2013
Posts: 7
Location: Athens, Ga
crummytransporter is offline

PostPosted: Tue May 19, 2015 3:46 pm    Post subject: Re: Dust caps Reply with quote

wclark4000 wrote:
Greetings...

I can't seem to figure out how to remove the dust caps. I have cleared the muck and see the cap and a ring that was peened in three places, and I have frozen myself there in concern that if I just slip a chisel type instrument under the peening it will either work, or destroy an unobtainable part.

Any suggestions?


Have this exact same question.
Back to top
View user's profile Send private message Classifieds Feedback
Tcash
Samba Member


Joined: July 20, 2011
Posts: 11689
Location: San Jose, California, USA
Tcash is offline

PostPosted: Tue May 19, 2015 7:35 pm    Post subject: Front torsion arm bushings Reply with quote

http://www.bus-boys.com/frontaxle68-79.html
https://www.vwheritage.com/shop/211405127/seal-axle-tube-1970/
http://www2.cip1.com/ProductDetails.asp?ProductCode=C24-211-401-321-A
http://www.justkampers.com/211-401-301-b-front-axle-needle-bearing-vw-t2-bays-1967-1979.html
http://www.thesamba.com/vw/forum/viewtopic.php?p=7099479#7099479
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/EarlyBay-4.html
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-002.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-003.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-004.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/EarlyBay-Main.html
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Daveinmn
Samba Member


Joined: February 24, 2015
Posts: 28
Location: Minneapolis
Daveinmn is offline

PostPosted: Sun Jun 21, 2015 12:15 pm    Post subject: Thanks Reply with quote

Just replaced all 4 torsion arms as the ball joints were shot. Could not have gone any better, you guys rock. Very Happy
Back to top
View user's profile Send private message Gallery Classifieds Feedback
khalimadeath
Samba Member


Joined: June 24, 2014
Posts: 685
Location: Reno, NV
khalimadeath is offline

PostPosted: Sun Jun 28, 2015 7:57 pm    Post subject: Reply with quote

So instead of posting a new thread I figured I would post in here for ideas. So I got it mostly apart, however I cannot get the lower arm out of the knuckle. Ive tried a 2 jaw puller pickle fork and BFG. Lots of penetrating oil.. So now what could I try? I busted my knuckle pretty good. ALSO I have new arms and do not have a bently. Do I need to mark the old ones before I pull them? How do I install the new ones properly? THANKS!

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
old DKP driver
Samba Member


Joined: March 30, 2005
Posts: 3802
Location: Los Gatos,Ca.
old DKP driver is offline

PostPosted: Sun Jun 28, 2015 8:29 pm    Post subject: ball joint stuck Reply with quote

Before you get hurt anymore Razz Pull the speedo cable out and then pull
the trailing arm out of the beam and you will have better luck getting that ball joint out .

No Bentley? do you have a vice mounted on a table? that will help too since
that ball joint is looking pretty damaged.

You also need a long pipe to lift the Upper arm off the rubber stop so it can be removed AFTER you remove the clip.

Leave the grub screws IN UNTIL THE RUBBER STOPS ARE OUT

as for the eccentrics they also will need to pressed off and NOT damaged so you can put them on the exchange arms. NO bOOK Scares me. how about You Shocked
_________________
V.W.owner since 1967
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
khalimadeath
Samba Member


Joined: June 24, 2014
Posts: 685
Location: Reno, NV
khalimadeath is offline

PostPosted: Mon Jun 29, 2015 8:35 am    Post subject: Re: ball joint stuck Reply with quote

old DKP driver wrote:
Before you get hurt anymore Razz Pull the speedo cable out and then pull
the trailing arm out of the beam and you will have better luck getting that ball joint out .

No Bentley? do you have a vice mounted on a table? that will help too since
that ball joint is looking pretty damaged.

You also need a long pipe to lift the Upper arm off the rubber stop so it can be removed AFTER you remove the clip.

Leave the grub screws IN UNTIL THE RUBBER STOPS ARE OUT

as for the eccentrics they also will need to pressed off and NOT damaged so you can put them on the exchange arms. NO bOOK Scares me. how about You Shocked


Wait what are the grub screws?

What are the eccentrics? The new arms I got i believed to be complete.

I was too cheap to buy the bently and hoped I could find all my answers on the interwebs. This bus is expensive lol
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Tcash
Samba Member


Joined: July 20, 2011
Posts: 11689
Location: San Jose, California, USA
Tcash is offline

PostPosted: Mon Jun 29, 2015 10:18 am    Post subject: Re: Front torsion arm bushings Reply with quote

http://www.jerseylooker.com/FicheDump/EarlyBaywindow/EarlyBay-4.html
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-002.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-003.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-004.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/EarlyBay-Main.html
Back to top
View user's profile Send private message Gallery Classifieds Feedback
lintbrush
Samba Member


Joined: October 10, 2013
Posts: 221
Location: SF Bay Area
lintbrush is offline

PostPosted: Mon Jun 29, 2015 12:40 pm    Post subject: Reply with quote

If you're too cheap to buy Bentley, you may be too cheap to buy this:
Image may have been reduced in size. Click image to view fullscreen.


But you can rent one. I use a ball joint puller, but since your boots are shot you could easily use this kind of puller to get that lower ball joint out and also your eccentrics stuck to your top ball joint.
_________________
1970 Westfalia Campmobile - SF Bay Area
https://www.instagram.com/campishome/
Back to top
View user's profile Send private message Instagram Gallery Classifieds Feedback
khalimadeath
Samba Member


Joined: June 24, 2014
Posts: 685
Location: Reno, NV
khalimadeath is offline

PostPosted: Mon Jun 29, 2015 6:36 pm    Post subject: Re: Front torsion arm bushings Reply with quote

Tcash wrote:
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/EarlyBay-4.html
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-002.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-003.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/4-004.jpg
http://www.jerseylooker.com/FicheDump/EarlyBaywindow/EarlyBay-Main.html


Bookmarked thanks, is the eccentric ring pressed on or removable with wrench? I have access to a press and tools from orileys. Im gonna take the knuckle off with the arm still in it so I can get a better angle on it.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
lintbrush
Samba Member


Joined: October 10, 2013
Posts: 221
Location: SF Bay Area
lintbrush is offline

PostPosted: Mon Jun 29, 2015 7:25 pm    Post subject: Reply with quote

They are just pressed on. My torsion arms came with new eccentrics. Mine came off pretty easy with the pitman arm puller I posted earlier.
Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.

_________________
1970 Westfalia Campmobile - SF Bay Area
https://www.instagram.com/campishome/
Back to top
View user's profile Send private message Instagram Gallery Classifieds Feedback
Tcash
Samba Member


Joined: July 20, 2011
Posts: 11689
Location: San Jose, California, USA
Tcash is offline

PostPosted: Mon Jun 29, 2015 7:32 pm    Post subject: Re: Front torsion arm bushings Reply with quote

khalimadeath wrote:


Bookmarked thanks, is the eccentric ring pressed on or removable with wrench? I have access to a press and tools from orileys. Im gonna take the knuckle off with the arm still in it so I can get a better angle on it.


Does not thread on but is Usually rusted on and requires a puller or press to remove.
Tcash
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Yarkle Premium Member
Samba Member


Joined: August 03, 2009
Posts: 1044
Location: the Hills of Western Maine
Yarkle is offline

PostPosted: Tue Jun 30, 2015 9:27 am    Post subject: Reply with quote

We did this two? maybe three weeks ago...Pretty much, before we did anything...we just sprayed kroil in each of the knuckles where the ball joint went in, then tapped the bottom of the ball boint with a hammer, for two or three days. when we started dissasembly, the top ones came out pretty easy, the bottoms I had to whack with the pickle fork a few times... do you have the right sized fork?

I find kroil works where other penetrating oils wont.
_________________
1973 VW Bus [o____o] Urklegrue thread:
http://www.thesamba.com/vw/forum/viewtopic.php?p=8272498#8272498 1.7 914? engine with weber progressive clone (soon to be 72 dual carb setup)
1969 VW Bus deluxe 221 -belongs to the boy
"Weld Busler" Bus rebuild thread: http://www.thesamba.com/vw/forum/viewtopic.php?t=630499 1600SP
Back to top
View user's profile Send private message Gallery Classifieds Feedback
khalimadeath
Samba Member


Joined: June 24, 2014
Posts: 685
Location: Reno, NV
khalimadeath is offline

PostPosted: Tue Jun 30, 2015 11:38 am    Post subject: Reply with quote

Yarkle wrote:
We did this two? maybe three weeks ago...Pretty much, before we did anything...we just sprayed kroil in each of the knuckles where the ball joint went in, then tapped the bottom of the ball boint with a hammer, for two or three days. when we started dissasembly, the top ones came out pretty easy, the bottoms I had to whack with the pickle fork a few times... do you have the right sized fork?

I find kroil works where other penetrating oils wont.


i am using Kroil, I have a small pickle fork and may need a bigger one.

Thanks for all the help and tips I am gong to work on it some more today. Im gonna check my new arms to see if the ring came on those.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Yarkle Premium Member
Samba Member


Joined: August 03, 2009
Posts: 1044
Location: the Hills of Western Maine
Yarkle is offline

PostPosted: Tue Jun 30, 2015 12:58 pm    Post subject: Reply with quote

Yep, if your pickle fork isnt tall enough in profile, it wont provide the leverage to pop the joint off. I think i ended up using both of the ones i had.
_________________
1973 VW Bus [o____o] Urklegrue thread:
http://www.thesamba.com/vw/forum/viewtopic.php?p=8272498#8272498 1.7 914? engine with weber progressive clone (soon to be 72 dual carb setup)
1969 VW Bus deluxe 221 -belongs to the boy
"Weld Busler" Bus rebuild thread: http://www.thesamba.com/vw/forum/viewtopic.php?t=630499 1600SP
Back to top
View user's profile Send private message Gallery Classifieds Feedback
