Left to right:
Wolfsburg West repro - NOS Bosch - new Bosch 02170
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
 |
rdwood
Samba Member
Joined: January 24, 2006
Posts: 187
|
| Posted: Fri Apr 11, 2008 1:59 pm Post subject: |
|
|
| How often do condensers go bad? How can you tell? |
|
| Back to top |
|
|
tasb
The Distributor Distributor
Joined: April 27, 2002
Posts: 6675
Location: Pentwater, Michigan
|
| Posted: Sat Apr 12, 2008 7:30 pm Post subject: |
|
|
| Not all that often from my experience. Visuallly other than obvious can damage or insulation worn off the lead wire there is no way to tell. |
|
| Back to top |
|
|
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79254
Location: Sneaking up behind you
|
| Posted: Sat Apr 12, 2008 7:35 pm Post subject: |
|
|
I'm running a 40+ year old condenser on my Bosch 010 on my 2180.
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
virtanen
Samba Member
Joined: January 08, 2006
Posts: 1494
Location: Finland
|
| Posted: Sun Apr 13, 2008 3:09 am Post subject: |
|
|
| You can measure the capacity by suitable gauge. If it is zero, your capacitor is dead. |
|
| Back to top |
|
|
EverettB
Administrator
Joined: April 11, 2000
Posts: 71343
Location: Phoenix 602
|
|
| Back to top |
|
|
billmetric
Samba Member
Joined: March 16, 2006
Posts: 1062
Location: Columbus City USA
|
| Posted: Mon Apr 14, 2008 4:11 am Post subject: |
|
|
I have had a couple go bad, the cars ran like crap, they must have been partially shorted internaly, once they were switched out with new ones the cars ran fine again, they had no acceleration but idled ok, I think the best bet is to change them out at least every 10 years, once the points have been filed down as many times as possible its time for a new condensor
_________________
There is an idea of a Billmetric; some kind of abstraction. But there is no real me: only an entity, something illusory. And though I can hide my cold gaze, and you can shake my hand and feel flesh gripping yours and maybe you can even sense our lifestyles are probably comparable... I simply am not there... |
|
| Back to top |
|
|
Snort
Samba Member
Joined: April 02, 2005
Posts: 1964
Location: Seattle, WA
|
| Posted: Sat Jul 05, 2008 8:29 pm Post subject: |
|
|
My first ever condenser failure just occurred. The wire separated from the lead in. Symptoms were as previously mentioned. The engine idled fine, but misfired when under load. |
|
| Back to top |
|
|
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79254
Location: Sneaking up behind you
|
| Posted: Sat Jul 05, 2008 8:48 pm Post subject: |
|
|
| Snort wrote: |
| My first ever condenser failure just occurred. The wire separated from the lead in. Symptoms were as previously mentioned. The engine idled fine, but misfired when under load. |
Yup... that's the sign of a bad condenser.
Those yellow wire condensers are 40+ years old and you should not be surprised that it failed.
I'll have to make sure I carry a spare since I have a old condenser on my car.
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
perello
Samba Member
Joined: April 15, 2005
Posts: 878
Location: where social security comes for free
|
| Posted: Tue Jun 16, 2009 2:05 am Post subject: |
|
|
I've been always told that IF there is transfer of material at the points, from one electrode to the other, THAT is signal of a bad condenser?
I misunderstood something?
_________________
Aug '58 pressed bumper SO23
1974 German Thing
1978 Bug 1200 |
|
