Engine building dilema
Forum Index -> Performance/Engines/Transmissions Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
rracj13
Samba Member


Joined: November 17, 2005
Posts: 16

rracj13 is offline

PostPosted: Tue Dec 06, 2005 9:21 pm    Post subject: Engine building dilema Reply with quote

So I tore apart my engine the other day with the hopes of cleaning it up, replacing the bearings, and changing out the pistons and cylinders with new ones. But when I took out the crank, I saw that the one main journal in the middle of the case had a pretty deep groove wore in it from the bearing and I noticed that one of the rods had a lot of play in it. When I took the rod off the crank the bearing was completely chewed up. This left some pretty decent damage to the crank. So what are some of my options? I don't have access to any machine shops and I don't have the funds for a new case. What would be the life expectancy of the engine if I just replaced the bearings and put it back together as it is? Well I look forward to your expertise and maybe a good reality check here.
Image may have been reduced in size. Click image to view fullscreen.
Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
vicsvw
Samba Member


Joined: February 27, 2003
Posts: 1001

vicsvw is offline

PostPosted: Tue Dec 06, 2005 9:54 pm    Post subject: Rebuild? Reply with quote

Don't wast your time or any money. Fix it right or forget it. You need a line bore, Crank, & Bearings. You need to check the P&C See->Piston & Cylinders "How to Ck if they need replacing" <> http://www.1800vw.bizhosting.com/pistonringck.htm Ck cam & Lifters & oil Pump. See ->Cost to Rebuild <> http://www.1800vw.bizhosting.com/rebuildprices.htm
Back to top
View user's profile Send private message Visit poster's website Classifieds Feedback
Jake Raby
Samba Member


Joined: August 23, 2003
Posts: 7428
Location: Aircooled Heaven USA
Jake Raby is offline

PostPosted: Tue Dec 06, 2005 10:31 pm    Post subject: Reply with quote

Now that is one hurting engine!

Toss it all away and start from scratch.
_________________
Jake Raby
Raby Engine Development
www.rabyenginedevelopment.com
"I've never given anyone Hell, I just told them the truth and they thought it was Hell"
Back to top
View user's profile Send private message Visit poster's website Facebook Gallery Classifieds Feedback
60sunroof
Samba Member


Joined: November 16, 2003
Posts: 345
Location: INDY
60sunroof is offline

PostPosted: Wed Dec 07, 2005 6:45 am    Post subject: Reply with quote

first what state or city are you in?

If you are in L.A there are tons of options.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
rracj13
Samba Member


Joined: November 17, 2005
Posts: 16

rracj13 is offline

PostPosted: Wed Dec 07, 2005 8:25 pm    Post subject: Reply with quote

No, i'm nowhere near L.A. I'm living in Central Pennsylvania.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
demian
Samba Member


Joined: July 29, 2005
Posts: 5

demian is offline

PostPosted: Wed Dec 07, 2005 9:14 pm    Post subject: Reply with quote

Get in touch with the folks at Valley VW there in PA somewhere. Full service machine shop and they are very friendly and knowledgable.
www.vw-store.com
good luck
Demian
Back to top
View user's profile Send private message Gallery Classifieds Feedback
RIS
Samba Member


Joined: December 18, 2003
Posts: 3041
Location: Youngstown, Ohio
RIS is offline

PostPosted: Thu Dec 08, 2005 1:20 am    Post subject: Reply with quote

Yes, contact Dennis at Valley VW. Very knowledgeable and quick turn-around. You're crank can be reground, case will most likely need an alignbore, new bearings of course. Take a close look at your oiling system and any other suspect parts to find out why this happened, don't just slap it back together.
_________________
Richard Sedoris - VW Performance & Machine - Youngstown, OH
http://rismachine.tumblr.com/
YouTube: https://m.youtube.com/channel/UCfTBCG4I61iVm_ROc8OAuOQ
Instagram: @rismachine
Back to top
View user's profile Send private message Visit poster's website Instagram Gallery Classifieds Feedback
ice baller61
Samba Member


Joined: October 10, 2003
Posts: 499
Location: 562 downey
ice baller61 is offline

PostPosted: Thu Dec 08, 2005 6:18 am    Post subject: Reply with quote

Just wondering, what kind of noise was the motor making and what made you tare her down?
_________________
bumping sounds and boosting pounds
Back to top
View user's profile Send private message Yahoo Messenger Gallery Classifieds Feedback
rracj13
Samba Member


Joined: November 17, 2005
Posts: 16

rracj13 is offline

PostPosted: Thu Dec 08, 2005 2:06 pm    Post subject: Reply with quote

It has been awhile since I last ran it, and I can't recall hearing any odd noises. I tore the engine out because I was getting gas in my oil from a leaky fuel pump. I did not run it at all after I discovered the gas in the oil. Just drained the oil and tore it out. I had never tore down the engine before and I didn't get much information off the guy I bought the car from, but I'm assuming the the engine had all of the original miles on it. Which could possibly be well over 100k.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
vdub
Samba Member


Joined: September 07, 2003
Posts: 442
Location: Valley Springs, Ca.
vdub is offline

PostPosted: Thu Dec 08, 2005 2:54 pm    Post subject: Reply with quote

The gas in the oil is what spun the bearings.

rracj13 wrote:
It has been awhile since I last ran it, and I can't recall hearing any odd noises. I tore the engine out because I was getting gas in my oil from a leaky fuel pump. I did not run it at all after I discovered the gas in the oil. Just drained the oil and tore it out. I had never tore down the engine before and I didn't get much information off the guy I bought the car from, but I'm assuming the the engine had all of the original miles on it. Which could possibly be well over 100k.
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
rracj13
Samba Member


Joined: November 17, 2005
Posts: 16

rracj13 is offline

PostPosted: Sat Jan 14, 2006 4:10 am    Post subject: Reply with quote

So after a couple of weeks of tearing apart a couple of old cases looking for some usable parts, and coming up very empty handed, I took a trip to the VW Store.
Image may have been reduced in size. Click image to view fullscreen.

Problem solved, thanks for the help.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
DurocShark
Samba Member


Joined: April 05, 2004
Posts: 6604
Location: Crappy town in a crappy state. But the beach is nearby, so I have that going for me.
DurocShark is offline

PostPosted: Sat Jan 14, 2006 6:54 am    Post subject: Reply with quote

rracj13 wrote:
So after a couple of weeks of tearing apart a couple of old cases looking for some usable parts, and coming up very empty handed, I took a trip to the VW Store.
Image may have been reduced in size. Click image to view fullscreen.

Problem solved, thanks for the help.


Is that case painted?
_________________
No boom today. Boom tomorrow. There's always a boom tomorrow.
Back to top
View user's profile Send private message Send e-mail Visit poster's website AIM Address Gallery Classifieds Feedback
rracj13
Samba Member


Joined: November 17, 2005
Posts: 16

rracj13 is offline

PostPosted: Sat Jan 14, 2006 12:25 pm    Post subject: Reply with quote

Yes
Back to top
View user's profile Send private message Gallery Classifieds Feedback
fredybear
Samba Member


Joined: March 02, 2004
Posts: 484

fredybear is offline

PostPosted: Sat Jan 14, 2006 12:52 pm    Post subject: Reply with quote

Im gonna Puke.......
Back to top
View user's profile Send private message Gallery Classifieds Feedback
John M.
Samba Member


Joined: July 22, 2005
Posts: 3833
Location: Boulder, CO
John M. is offline

PostPosted: Sat Jan 14, 2006 1:24 pm    Post subject: Reply with quote

DurocShark wrote:

Is that case painted?


Duh. That adds about 10hp right there...
_________________

Current: 1972 Beetle - 96V EV
Previous:
1966 Beetle - Sea Blue - 1300SP
1966 Beetle - Sea Blue - 1600SP
1974 Beetle - African Red - 1914CC

Back to top
View user's profile Send private message Gallery Classifieds Feedback
Max Welton
Samba Member


Joined: May 19, 2003
Posts: 10391

Max Welton is offline

PostPosted: Sat Jan 14, 2006 2:29 pm    Post subject: Reply with quote

It looks like the cylinder registers have been painted. That will add a layer of soft paint under the cylinder. This could prevent the cylinders from seating properly. This will change the deck height by the initial thickness of the paint. If that paint compresses, deck height will be reduced as will stud torque.

The inside of the oil pump bore has been painted. Normally, the pump is an interferrence fit in that bore. When the pump is inserted, that paint will be scraped off and wind up inside the case.

Good luck.

Max
_________________
1967 Type-3 Fastback
https://shoptalkforums.com/viewtopic.php?f=24&t=151582
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
DurocShark
Samba Member


Joined: April 05, 2004
Posts: 6604
Location: Crappy town in a crappy state. But the beach is nearby, so I have that going for me.
DurocShark is offline

PostPosted: Sat Jan 14, 2006 3:27 pm    Post subject: Reply with quote

John M. wrote:
DurocShark wrote:

Is that case painted?


Duh. That adds about 10hp right there...


I was thinking more like 25... degrees.
_________________
No boom today. Boom tomorrow. There's always a boom tomorrow.
