beating a dead horse, er, fridge
Forum Index -> Vanagon Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
grunwin
Samba Member


Joined: April 05, 2005
Posts: 107
Location: Portland, OR
grunwin is offline

PostPosted: Tue Feb 07, 2006 3:45 pm    Post subject: beating a dead horse, er, fridge Reply with quote

My refrigerator troubles came up as a digression in a recent post and I thought I would put them out there to the group at large. I know there is a glut of fridge posts but I don't recall any that address this specific problem:

When left plugged in to 120v over night my fridge doesn't cool at all. It cools on 12v when I drive. I have been able to light it on gas when hooked up to an LP tank with the fridge removed from the vehicle but have not been able to light it off gas when installed. I know the gas flows, the ignitor sparks, the air pump pumps, the outlet in the garage has juice, and there is power coming through the wires in the van. My next move is to remove it and see if the RV shop can figure out why the 120v won't work. Any ideas?
_________________
'87 Westy
'04 Golf 2.0
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Dogpilot
Samba Member


Joined: October 03, 2005
Posts: 4205
Location: Flagstaff, AZ
Dogpilot is offline

PostPosted: Tue Feb 07, 2006 4:38 pm    Post subject: Reply with quote

Check here for a bunch of fridge troubleshooting tips:

http://www.vanagonauts.com/[76.X]-Dometic-Fridge139.htm

Cheers,
james
_________________
Geology with a Syncro rocks!
86 Syncro Westy AKA "The Bughunter"
98 Disco I
08 Range Rover SC
08 VW Rabbit S
1951 O-1G
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Beaker
Samba Member


Joined: June 15, 2005
Posts: 133
Location: Waterloo, ON, Canada
Beaker is offline

PostPosted: Tue Feb 07, 2006 4:43 pm    Post subject: Reply with quote

I haven't had this specific problem, although mine takes a few tries to get it to light when on gas. I would guess that the problem lies in your switch (12V, Gas, 120V). You may want to pop that out and inspect/replace before tearing the whole fridge out. Also, if you have recently filled your tank, you may have some air in the line. To bleed the line, light the stove for a minute or two. Don't know if this helps.........
Back to top
View user's profile Send private message Gallery Classifieds Feedback
grunwin
Samba Member


Joined: April 05, 2005
Posts: 107
Location: Portland, OR
grunwin is offline

PostPosted: Tue Feb 07, 2006 6:07 pm    Post subject: Reply with quote

Thanks for the link, Dogpilot. I particularly like the section on the unhelpful/unknowledgable VW dealerships/Dometic service centers.

I'll look into popping that switch off; I haven't tried that. I have run the stove before attempting to light the fridge to no avail.

I bought this Westy last year with 27,000 original miles on it and, as far as I know, the fridge has never been lit. I don't think the LP tank had ever been filled, either (there was still blue plastic wrap from the factory on the heat shield for the range!). The tank is full now and the stove burners work fine. Nothing is apparently plugged. I blew air through everything I could and checked conductivity of all exposed wires. The weird part is that I'm pretty certain I did get it to cool on 110v before removing the unit from the van. Think [/quote][/code]
_________________
'87 Westy
'04 Golf 2.0
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Dogpilot
Samba Member


Joined: October 03, 2005
Posts: 4205
Location: Flagstaff, AZ
Dogpilot is offline

PostPosted: Tue Feb 07, 2006 7:00 pm    Post subject: Reply with quote

The other item you may want to check is the breaker switch next to the plug . I never could find out if it isolated the entire system or just the plug. I definatly had to run the stove for a while before I got my fridge to light the first time. Also, there is a small brass plug at the bottom of the fridge which is the water drain. I opened mine and forgot about it, and after driving around a bit a signifigant amount of fine rust powder had come out. So I held the vacuum nozzle there let the vacuum suck on it for a while. Then left it off for a while and drove for a week or two. a bit more came out and it lighted eaiser.

Good luck,
James
_________________
Geology with a Syncro rocks!
86 Syncro Westy AKA "The Bughunter"
98 Disco I
08 Range Rover SC
08 VW Rabbit S
1951 O-1G
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
mightyart
Samba Member


Joined: March 24, 2004
Posts: 6179
Location: Portland, Oregon
mightyart is offline

PostPosted: Tue Feb 07, 2006 7:07 pm    Post subject: Reply with quote

is it plugged in under the sink?
Image may have been reduced in size. Click image to view fullscreen.

_________________
My Art:
http://www.gordonflynn.com
Back to top
View user's profile Send private message Gallery Classifieds Feedback
grunwin
Samba Member


Joined: April 05, 2005
Posts: 107
Location: Portland, OR
grunwin is offline

PostPosted: Tue Feb 07, 2006 7:23 pm    Post subject: Reply with quote

I'm offended! Obviously the first thing I checked, right? Okay, so I ran out in the cold to check that plug knowing full well I wouldn't be able to sleep otherwise. Unfortunately, it was plugged in. Dag.

I removed the front plate of the fridge but did not see a way to access the toggle switch without removing the entire fridge. Barring any further ideas (no matter how obvious), that's the next step.
_________________
'87 Westy
'04 Golf 2.0
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Michael J
Samba Member


Joined: March 22, 2004
Posts: 75
Location: Northwestern Pennsylvania
Michael J is offline

PostPosted: Tue Feb 07, 2006 8:21 pm    Post subject: Reply with quote

grunwin wrote:
I'm offended! Obviously the first thing I checked, right? Okay, so I ran out in the cold to check that plug knowing full well I wouldn't be able to sleep otherwise. Unfortunately, it was plugged in. Dag.

I removed the front plate of the fridge but did not see a way to access the toggle switch without removing the entire fridge. Barring any further ideas (no matter how obvious), that's the next step.


Well, here are 2 obvious things to look at: Have you checked the 110v thermo-fuse? Did you verify that you have 110v power at the refrigerator's power outlet?

Michael J
My VW van and truck collection:
http://www.velocity.net/~vickrail/moshevw.htm
Back to top
View user's profile Send private message Visit poster's website Classifieds Feedback
DrDarby
Samba Member


Joined: May 12, 2004
Posts: 6505
Location: Northern Illinois
DrDarby is offline

PostPosted: Wed Feb 08, 2006 10:12 am    Post subject: Reply with quote

When I worked for VW in the 80's & 90s I developed a knack for lighting stubborn refrigerators. Pump the air valve like crazy, then hold the pilot button while pumping, then start pumping but push all the way to knick the igniter, do this like 10 times. Occasianally you'll get a backfire but keep doing it. After about 10 ignites, keep the pilot buttom pressed and watch through the little site hole. Normally it will light every time this way.
_________________
Midwest Autosavers, Inc. Cary, IL
Back to top
View user's profile Send private message Send e-mail Facebook Gallery Classifieds Feedback
[email protected]
Samba Member


Joined: April 12, 2003
Posts: 1839
Location: Englewood, FL
mdetro4660@aol.com is offline

PostPosted: Wed Feb 08, 2006 2:22 pm    Post subject: Reply with quote

I know this is another stupididly obvious one but when you are turning it to 120 volt on the 3 way are you also turning the temp know to full? I did this the other day after I had taken mine out for a cleaning and going through, I was about to rip it out again and start probing the 120 wires for faults and I thought I would read the instructions on the door and try one more time Very Happy

BTW I'm at pretty much at the same point with my Propane as you are-everything seems to function as should but I can't get it to fire either! I do think I may have damged the thermocoupler though and I bought a universal unit the other day. I hope I can make it fit Shocked

good luck.
_________________
Markus
Back to top
View user's profile Send private message Gallery Classifieds Feedback
sc-surfer
Samba Member


Joined: May 16, 2005
Posts: 865
Location: Santa Cruz, CA
sc-surfer is offline

PostPosted: Wed Feb 08, 2006 4:43 pm    Post subject: Reply with quote

For what it is worth, once you finally get it to fire up on gas, try to start it once a month or so. It seems to help. If I let mine sit to long, it gives me fits.

Also, I recomend DrDarby's methot. Usually works.

Good luck. A properly runnung Dometic is a wonderfull thing. When not running, the devil in a small box.
_________________
'89 Syncro Westy
Catalog of Vans at SDM 2010
Westfalia, Syncro & Tristar Reproduction decals here.
* * * Coming Soon: Washable seat covers for westy bench seat...keep the pets off the upholstery! * * *
Back to top
View user's profile Send private message Gallery Classifieds Feedback
r39o
Samba Polizei


Joined: May 18, 2005
Posts: 9548
Location: San Diego
r39o is offline

PostPosted: Wed Feb 08, 2006 7:01 pm    Post subject: Reply with quote

Factory service manual for the frig:
http://www.loam.org/vw/Vanagon/DometicRM182B/DometicRM182B.pdf
_________________
"Use the SEARCH, Luke" But first visit the Vanagon FAQ!
1990 Multivan EJ 22 running well...

Click to see my ads for Cup holders, Subaru clutch fix and CLK wheels (no wheels currently)
Back to top
View user's profile Send private message Gallery Classifieds Feedback
ron3865
Samba Member


Joined: December 15, 2011
Posts: 113
Location: usa
ron3865 is offline

PostPosted: Sat May 05, 2018 6:28 pm    Post subject: Reply with quote

Dogpilot wrote:
Check here for a bunch of fridge troubleshooting tips:

http://www.vanagonauts.com/[76.X]-Dometic-Fridge139.htm

Cheers,
james


That was the best, most informed article On the Vanagon Dometic fridge. It answered several questions on starting with propane and I think it solved my "flame going out while driving" problem.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
jimf909 Premium Member
Samba Member


Joined: April 03, 2014
Posts: 3477
Location: Seattle
jimf909 is offline

PostPosted: Sat May 05, 2018 9:52 pm    Post subject: Re: beating a dead horse, er, fridge Reply with quote

Nominated for bump-of-the-month in May! Very Happy
_________________
Current: 1990 Westy Camper - Bostig RG4, 2wd, manual trans w/Peloquin, NAHT high-top, Flash Silver, seam rust, bondo, etc., etc.

Past: 1985 Westy Camper - 1.9 wbx, 2wd, manual trans, Merian Brown, (sold after 17 years to Northwesty who converted it to a Syncro).
Back to top
View user's profile Send private message Gallery Classifieds Feedback
spitsnrovers
Samba Member


Joined: December 17, 2005
Posts: 804
Location: Calgary, Canada
spitsnrovers is offline

PostPosted: Sun May 06, 2018 5:39 am    Post subject: Re: beating a dead horse, er, fridge Reply with quote

Well nominated Applause .
To add to the confusion - page 9 of the Dometic manual, as well as the diagram on the fridge itself has a circuit diagram error Shocked

The double-pole double-throw switch for the 120V-12V (labeled simply SWITCH) shows the internal toggles incorrectly.

It shows one toggle going left, and one going right. The two toggles should both be going the same way. If you try circuit tracing using this incorrect diagram, it could drive you crazy Brick wall
