| Author |
Message |
Mr. Bubblehead
El Chupa Nibre
Joined: October 25, 2002
Posts: 2756
Location: 612 Wharf Avenue
|
 Posted: Mon Apr 10, 2006 8:24 am Post subject: Problems with fitting Porsche wheels on the rear. |
 |
|
I have a set of Porsche chrome wheels (from a 912) mounted on my SC. The fronts fit just fine, since I have the 944 disc brakes on it. The rears are mounted with wheel adapters; however, I cannot get the hubcaps on. I have measured and it looks like I will have to grind off about 1/4" - 1/2" of the axle stub and nut to get them to fit. Anyone have a better suggestion? If I do grind them down, I won't be able to use the cotter pin anymore. I can't use wheel spacers, because with the adapters there is only about 1/4" of clearance between the tire and fender lip.
_________________
OGST
Samba Member #4862 |
|
| Back to top |
|
 |
65 Deluxe
Samba Member
Joined: May 04, 2002
Posts: 590
|
| Posted: Mon Apr 10, 2006 11:52 am Post subject: |
|
|
| I have the same problem with my Phone Dials on the rear. I just go without the caps until I get the straight axle in. I know this doesn't help, but I couldn't find a better way on my bus and I too have only a quarter of and inch of space in the fender. I run Porsche turbo brakes in the front and adapters on the rear right now. |
|
| Back to top |
|
|
Mr. Bubblehead
El Chupa Nibre
Joined: October 25, 2002
Posts: 2756
Location: 612 Wharf Avenue
|
| Posted: Mon Apr 10, 2006 12:36 pm Post subject: |
|
|
| 65 Deluxe wrote: |
| I have the same problem with my Phone Dials on the rear. I just go without the caps until I get the straight axle in. I know this doesn't help, but I couldn't find a better way on my bus and I too have only a quarter of and inch of space in the fender. I run Porsche turbo brakes in the front and adapters on the rear right now. |
I noticed that the bus really "needs" the adapters in the rear, because the porsche brakes up front push the wheels out about 1.5" on each side.
Ghetto-style it is then, for now...blacked-out centers and chrome lugs until I fix it up right (straight-axle + narrowed beam + time to do it = $$$)
_________________
OGST
Samba Member #4862 |
|
| Back to top |
|
|
65 Deluxe
Samba Member
Joined: May 04, 2002
Posts: 590
|
| Posted: Mon Apr 10, 2006 1:27 pm Post subject: |
|
|
I also just put in a 4 inch narrowed beam and most of the wheel offset is to the rear with these wheels. I am not sure what the offset is though. 16x7 all the way around.
Last edited by 65 Deluxe on Mon Apr 10, 2006 1:59 pm; edited 1 time in total |
|
| Back to top |
|
|
krusher
Samba Member
Joined: September 24, 2002
Posts: 7661
Location: europe
|
| Posted: Mon Apr 10, 2006 1:53 pm Post subject: |
|
|
| Mr. Bubblehead wrote: |
| 65 Deluxe wrote: |
| I have the same problem with my Phone Dials on the rear. I just go without the caps until I get the straight axle in. I know this doesn't help, but I couldn't find a better way on my bus and I too have only a quarter of and inch of space in the fender. I run Porsche turbo brakes in the front and adapters on the rear right now. |
I noticed that the bus really "needs" the adapters in the rear, because the porsche brakes up front push the wheels out about 1.5" on each side.
Ghetto-style it is then, for now...blacked-out centers and chrome lugs until I fix it up right (straight-axle + narrowed beam + time to do it = $$$) |
1.5" out either side = 3" narrowed beam. |
|
| Back to top |
|
|
rizzag
Now Wut?
Joined: April 19, 2001
Posts: 3131
Location: Keizer, OR
|
| Posted: Mon Apr 10, 2006 2:29 pm Post subject: Re: Problems with fitting Porsche wheels on the rear. |
|
|
| Mr. Bubblehead wrote: |
| I have measured and it looks like I will have to grind off about 1/4" - 1/2" of the axle stub and nut to get them to fit.... If I do grind them down, I won't be able to use the cotter pin anymore.. |
if you cut 1/4 off you should still be about to use the cotter pins.
oh and any idea that means you cant use your cotter pins is NOT even an option.
_________________
flossin, tossin, dippin, and trippin |
|
| Back to top |
|
|
Mr. Bubblehead
El Chupa Nibre
Joined: October 25, 2002
Posts: 2756
Location: 612 Wharf Avenue
|
| Posted: Mon Apr 10, 2006 2:42 pm Post subject: Re: Problems with fitting Porsche wheels on the rear. |
|
|
| rizzag wrote: |
if you cut 1/4 off you should still be about to use the cotter pins.
oh and any idea that means you cant use your cotter pins is NOT even an option. |
Wurd. I am very good with mechanical stuff and I generally don't have to ask questions but when it comes to grinding off important shit I like to err on the side of caution.
_________________
OGST
Samba Member #4862 |
|
| Back to top |
|
|
mulk
Samba Member
Joined: November 19, 2003
Posts: 333
Location: Your rear-view mirror
|
| Posted: Mon Apr 10, 2006 3:46 pm Post subject: |
|
|
Cotter pin saved my bacon when I spun that left rear brake drum during OCTO.
Better to be safe than purty.........
_________________
Eric - Defender of Injustice
http://www.lasvegasvwclub.com/ |
|
| Back to top |
|
|
roberto
Samba Member
Joined: December 10, 2002
Posts: 834
Location: West Central Ohio
|
| Posted: Mon Apr 10, 2006 6:25 pm Post subject: |
|
|
Just cut the fender wells out!
J/K. I havn't thought about it with bus drums, but could you have the drums drilled 5x130 and 14mm studs pressed in?
or would the snout be to fat for that tight of a bolt pattern? |
|
| Back to top |
|
|
roberto
Samba Member
Joined: December 10, 2002
Posts: 834
Location: West Central Ohio
|
| Posted: Tue Apr 11, 2006 5:51 am Post subject: |
|
|
Hey Bubs, this might be your answer. you Have a str8 axle setup, right.
http://www2.cip1.com/ProductDetails.asp?ProductCode=C23%2D501%2D310
I know with my set up this would work and is what I would use If I did not get the rear disks with the fronts. the only conflict that I can see with these you might need some porsche style spacers (not adapters) to set things right perfect.
performance parts has some listed from 7mm-65mm H&R made in germany. I know I have seen others also. |
|
| Back to top |
|
|
Mr. Bubblehead
El Chupa Nibre
Joined: October 25, 2002
Posts: 2756
Location: 612 Wharf Avenue
|
| Posted: Tue Apr 11, 2006 6:21 am Post subject: |
|
|
| roberto wrote: |
...could you have the drums drilled 5x130 and 14mm studs pressed in?
or would the snout be to fat for that tight of a bolt pattern? |
That would make the problem worse, I would have to do even more grinding.
And no, I do not have a straight axle in the bus, it is still stock.
_________________
OGST
Samba Member #4862 |
|
| Back to top |
|
|
Area51
Samba Member
Joined: September 09, 2002
Posts: 255
Location: Area51 / The Netherlands
|
| Posted: Tue Apr 11, 2006 7:06 am Post subject: |
|
|
What you need is a thicker adapter (5x205 -> 5x130 wright?), and then
you must have the wheelcenters re-positioned to you're rims.
in other words, change the et size off you're rear wheels .. i think it's the
only option to mount you're hupcaps, without grinding. |
|
| Back to top |
|
|
|
