Author |
Message |
wackert Samba Member
Joined: January 10, 2005 Posts: 147 Location: Chehalis,WA
|
Posted: Mon Jul 16, 2007 8:48 pm Post subject: aftermarket exhaust |
|
|
where can i find a hide away style aftermarket exhaust. im build a motor for my car which i dont really wanna use a stcok stle muffler would really like to find the hideaway after market. thanks for the help |
|
Back to top |
|
 |
Ian Epperson Samba Member

Joined: January 12, 2005 Posts: 2262 Location: Alameda, CA
|
Posted: Tue Jul 17, 2007 9:31 am Post subject: |
|
|
What do you mean by "hide a way"? More ground clearance? There's a few different styles. You could go with the split-style that has two mufflers, each tucked up by the heads:
http://www.thethingshop.com/detail.asp?PRODUCT_ID=181DH
This is NOT a performance system - joining cylinders 1&2 then 3&4 together does not yield a good extractor. The nice part is that it's up out of the way and exits the bumper holes. The bad part is it will slightly decrease performance and it's harder to set the valves. I have one of these that I'm getting rid of - it's pretty old and if anyone wants to come get it here in Sunnyvale, CA, they can have it.
You can go with a Monza system similar to this:
But I don't think it tucks as high as the split header. It's a better system for performance and for setting the valves though. The Thing version will exist the holes in the bumper properly.
(I couldn't find any good pictures or links to the Thing version and I know some in here use that... anyone want to chime in?)
You could probably also go with a Sidewinder exhaust:
http://www.thesamba.com/vw/classifieds/detail.php?id=264089
It won't exist the holes in the bumper, but it's up and out of the way. It's a good extractor exhaust - probably the best performing of those listed here. I've never seen one installed on a Thing, but I assume it'll be hard to set the valves on the right side. It's probably the most expensive of the three here as well.
Last edited by Ian Epperson on Tue Jul 17, 2007 10:28 am; edited 1 time in total |
|
Back to top |
|
 |
Fun 181 Zu Geil!

Joined: October 20, 2006 Posts: 1003 Location: Connecticut
|
Posted: Tue Jul 17, 2007 10:15 am Post subject: |
|
|
What Ian siad x2.
You will want a merged header system for better performance and easy access to your valves.The hideaway sytem from the Thing Shop won't give you that.
Here is the ACI ceramic coated exhaust:
It's not stock, but it isn't obtrusive either and has plenty of clearance. I love how the tail pipes go through the bumper as it is very unique. Other than being loud it's not a bad set up. _________________
Ian Epperson wrote: |
Holy poop, that's full of awesome! |
|
|
Back to top |
|
 |
wings_n_fins Samba Member

Joined: May 02, 2006 Posts: 166 Location: Mangilao, Guam USA
|
Posted: Tue Jul 17, 2007 11:34 am Post subject: |
|
|
I'm ordering a "Wild Boar" exhaust through Serrano's VW. That's the same deal as what's pictured above, right?
PS: Looks like I could eat out of your engine bay! _________________ DAVE
'73 Thing
'07 Harley Sportster
'09 Jeep Wrangler Unlimited |
|
Back to top |
|
 |
Fun 181 Zu Geil!

Joined: October 20, 2006 Posts: 1003 Location: Connecticut
|
Posted: Tue Jul 17, 2007 1:23 pm Post subject: |
|
|
I don't think what I have is called the "Wild Boar". I got my exhaust from ISP West via eBay.
They are calling it the "181 EURO 2 TIP MUFFLER EXHAUST SYSTEM". I got the matching ceramic coated heater boxes from someplace else (either CIP or Mid-America), but I think ISP sells the heater boxes too.
They claim that ceramic coating will be rust free, but I started getting rust stains pretty quickly. Just stains though mostly around the welds.
As far as eating out of the engine bay... after a long trip you could definately fry an egg or two in there!! And I can always weld a fork to the top of my dipstick!  _________________
Ian Epperson wrote: |
Holy poop, that's full of awesome! |
Last edited by Fun 181 on Fri Feb 27, 2009 5:43 pm; edited 1 time in total |
|
Back to top |
|
 |
chefopie Samba Member
Joined: May 23, 2007 Posts: 9 Location: Columbia, South Carolina
|
|
Back to top |
|
 |
Ian Epperson Samba Member

Joined: January 12, 2005 Posts: 2262 Location: Alameda, CA
|
Posted: Wed Jul 18, 2007 4:08 pm Post subject: Re: Tuck Aways is the best for me... |
|
|
Looks like an extractor exhaust.
...I like seeing them all on the same page  |
|
Back to top |
|
 |
sam_w Samba Member

Joined: March 07, 2002 Posts: 1479 Location: Petaluma, CA
|
Posted: Wed Jul 18, 2007 4:47 pm Post subject: |
|
|
Ian
I wish I knew about your muffler pack before I bought one in Tahoe last year. It is a pain to adjust the valves and I want to replace it.
That will happen when I switch engines. _________________ 63 singlecab
73 thingster
74 Thing |
|
Back to top |
|
 |
lukesky Samba Member

Joined: July 12, 2006 Posts: 246 Location: See The Rabbits, IA
|
Posted: Thu Jul 19, 2007 8:01 pm Post subject: |
|
|
I have the S&S system that exits through the bumper:
I have no idea how it affects performance, but it seems to allow for valve access. I'll find out for sure next week when I take my first shot at adjusting the valves myself. _________________ You get what you get, and you don't throw a fit.
-Gabi |
|
Back to top |
|
 |
Towel Rail Horizontally Opposed

Joined: April 15, 2005 Posts: 4622 Location: SE CR IA US NA PE
|
Posted: Thu Jul 19, 2007 8:30 pm Post subject: |
|
|
Here's the one I'm putting on my car. Ceramic-coated Bugpack 1 3/8" header + Hideaway muffler from aircooled.net.
_________________ 1974 Thing -- under the knife
1967 Beetle -- spring/summer/fall driver
1996 Subaru OBW (EJ22, 5-speed, AWD) -- winter car, 3-seasons "don't feel like biking today" car
049 > 070 > 053 > 009 |
|
Back to top |
|
 |
wackert Samba Member
Joined: January 10, 2005 Posts: 147 Location: Chehalis,WA
|
Posted: Thu Jul 19, 2007 8:45 pm Post subject: |
|
|
yeah the last one is waht i was lookin for somethin with a lil performance |
|
Back to top |
|
 |
wackert Samba Member
Joined: January 10, 2005 Posts: 147 Location: Chehalis,WA
|
Posted: Thu Jul 19, 2007 8:47 pm Post subject: |
|
|
is that for a merged system? |
|
Back to top |
|
 |
Ian Epperson Samba Member

Joined: January 12, 2005 Posts: 2262 Location: Alameda, CA
|
Posted: Thu Jul 19, 2007 9:18 pm Post subject: |
|
|
Keep in mind that many of these systems extend past the bumper. I once had the S&S system on mine, but got rid of it because I didn't like the thought that a tap from behind would ruin my engine or exhaust or both.
The Bugpack one will probably also extend past the bumper.
Of those listed here, the following probably offer the best performance as they all appear to be 4:1 extractor systems:
Sidewinder
EMPI
S&S
Bugpack
Note that the Bugpack, S&S, and EMPI all use the same header design. Of the lot, I think only the Sidewinder has a chance of not extending past the rear bumper. If I still had a type1, that's the one I'd go with. |
|
Back to top |
|
 |
wings_n_fins Samba Member

Joined: May 02, 2006 Posts: 166 Location: Mangilao, Guam USA
|
Posted: Thu Jul 19, 2007 10:46 pm Post subject: |
|
|
Would the bumper overrides from The Thing Shop be able to protect the exhaust & engine much from a "li'l love tap" from the rear?
--- EDIT ---
Okay, I lied: it doesn't look like The Thing Shop carries them anymore. Y'all know what I'm talking about, though.
_________________ DAVE
'73 Thing
'07 Harley Sportster
'09 Jeep Wrangler Unlimited |
|
Back to top |
|
 |
Towel Rail Horizontally Opposed

Joined: April 15, 2005 Posts: 4622 Location: SE CR IA US NA PE
|
Posted: Thu Jul 19, 2007 11:04 pm Post subject: |
|
|
Good point, Ian. There is that risk, but maybe since the pipes are already bent, they would deform before doing much damage to the engine?
I'm running a Beetle muffler with peashooters right now, and that's surely more of a hazard to my engine than any of the above! _________________ 1974 Thing -- under the knife
1967 Beetle -- spring/summer/fall driver
1996 Subaru OBW (EJ22, 5-speed, AWD) -- winter car, 3-seasons "don't feel like biking today" car
049 > 070 > 053 > 009 |
|
Back to top |
|
 |
Ian Epperson Samba Member

Joined: January 12, 2005 Posts: 2262 Location: Alameda, CA
|
Posted: Fri Jul 20, 2007 8:35 am Post subject: |
|
|
I used to have the same narrow bumper overriders shown in the pic above, and the S&S reached farther back than they did. Maybe the block style ones would do it. |
|
Back to top |
|
 |
Ian Epperson Samba Member

Joined: January 12, 2005 Posts: 2262 Location: Alameda, CA
|
Posted: Fri Jul 20, 2007 8:38 am Post subject: |
|
|
sam_w wrote: |
Ian
I wish I knew about your muffler pack before I bought one in Tahoe last year. It is a pain to adjust the valves and I want to replace it.
That will happen when I switch engines. |
Sam, that split header system makes it tough to adjust the valves - worse than the S&S system. |
|
Back to top |
|
 |
emersonbiggins Samba Member

Joined: February 18, 2003 Posts: 1695 Location: Nebraska
|
Posted: Fri Jul 20, 2007 2:03 pm Post subject: |
|
|
The muffler/ exhaust questions and threads should be made a sticky.
Seems like every couple of months we cover it all over again. |
|
Back to top |
|
 |
emersonbiggins Samba Member

Joined: February 18, 2003 Posts: 1695 Location: Nebraska
|
|
Back to top |
|
 |
Spezialist Banned
Joined: July 01, 2005 Posts: 1941
|
Posted: Sun Jul 22, 2007 10:47 am Post subject: |
|
|
Ian Epperson wrote: |
What do you mean by "hide a way"? More ground clearance? There's a few different styles. You could go with the split-style that has two mufflers, each tucked up by the heads:
http://www.thethingshop.com/detail.asp?PRODUCT_ID=181DH
This is NOT a performance system - joining cylinders 1&2 then 3&4 together does not yield a good extractor. The nice part is that it's up out of the way and exits the bumper holes. The bad part is it will slightly decrease performance and it's harder to set the valves. I have one of these that I'm getting rid of - it's pretty old and if anyone wants to come get it here in Sunnyvale, CA, they can have it. |
How bad could it be if the stock one is similar? Do you still have that exhaust? I have mucho friends in the area, that could come and get it for me?  _________________
 |
|
Back to top |
|
 |
|
