Sheet metal availability question inside above heater channel an
Page: 1, 2  Next
Forum Index -> Beetle - 1958-1967 Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Thu Dec 06, 2018 11:45 am    Post subject: Sheet metal availability question inside above heater channel an Reply with quote

I have looked all over and this sheet metal does not seem to be available anywhere ?
Image may have been reduced in size. Click image to view fullscreen.

_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
mukluk
Samba Member


Joined: October 18, 2012
Posts: 2935
Location: Clyde, TX
mukluk is offline

PostPosted: Thu Dec 06, 2018 12:23 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Not just that section by itself, but you can trim off what you don't need.
http://www.wolfsburgwest.com/cart/DetailsList.cfm?ID=111801202
_________________
1960 Ragtop w/Semaphores "Inga"
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Thu Dec 06, 2018 1:23 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

mukluk wrote:
Not just that section by itself, but you can trim off what you don't need.
http://www.wolfsburgwest.com/cart/DetailsList.cfm?ID=111801202
Thanks sadly I looked at that piece several times and thought that it went below that section, thanks again
_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)


Last edited by Bigjacksauto on Thu Dec 06, 2018 7:26 pm; edited 2 times in total
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Eric&Barb
Samba Member


Joined: September 19, 2004
Posts: 19540
Location: Olympia Wash Rinse & Repeat
Eric&Barb is offline

PostPosted: Thu Dec 06, 2018 1:56 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Bigjacksauto wrote:
it won't below that section thanks again


???
_________________
In Stereo, Where Available!
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
carcrazed
Samba Member


Joined: November 15, 2007
Posts: 878
Location: Ohio
carcrazed is offline

PostPosted: Thu Dec 06, 2018 4:11 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Unless something has changed in the past couple of years, I couldn't find them either and had to make my own.
_________________
1965 Herbie Replica. 1776cc dual Kads.
1961 Beetle 33,000 Original Miles

"Just When you think you are getting ahead, you're always wrong."
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Hokie87
Samba Member


Joined: May 27, 2010
Posts: 261
Location: Richmond, VA
Hokie87 is offline

PostPosted: Thu Dec 06, 2018 4:37 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

I used the WW metal referenced above by mukluk. It has to be modified to allow the heater duct to pass through but fit well otherwise. A picture before welding of the left side but same idea.

Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
VW_Jimbo
Samba Member


Joined: May 22, 2016
Posts: 3044
Location: Huntington Beach, CA
VW_Jimbo is offline

PostPosted: Thu Dec 06, 2018 4:41 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

http://www.klokkerholmusa.com/52-79-rear-wheelhouse-rear-lower-splash-panel-section-passengers-side/

Straight from their website.
_________________
Jimbo
ASE Master Technician 1990 - 2001

1955 Bug with Semaphores (Sold), 1968 Bug (Sold), 1972 Squareback (Sold), 1973 Super Beetle (Freeway accident - totaled), 1979 Rabbit (Sold), 1970 Bug Cal style (Sold), current project is a 1970 Bug

There is never enough time to do it right the first time, but all the time necessary the second time!

Ricksurfin wrote:
First world fast guy problems. Sheesh. Lol
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Thu Dec 06, 2018 7:28 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

VW_Jimbo wrote:
http://www.klokkerholmusa.com/52-79-rear-wheelhouse-rear-lower-splash-panel-section-passengers-side/

Straight from their website.

I believe that part goes below the part I am looking for.
_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
56Cabrio
Samba Member


Joined: May 22, 2008
Posts: 1196
Location: San Fernando Valley, Ca
56Cabrio is offline

PostPosted: Thu Dec 06, 2018 7:29 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Mika makes them also.
https://www.thesamba.com/vw/classifieds/detail.php?id=1462779

http://restorationpanels.com/product/rear-cross-member-reinforcement-panels-855-up/
_________________
(WTB) San Fernando Vokes Motors plate frame & San Fernando Mission VW plate frame

F#ck Cancer !
https://shop.stjude.org/GiftCatalog/donation.do?cID=14262&pID=24671


Stop dead photo links! Post your photos to The Samba Gallery
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Keith
Samba Member


Joined: August 15, 2005
Posts: 3551
Location: Brodheadsville, PA
Keith is offline

PostPosted: Fri Dec 07, 2018 10:29 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Bigjacksauto wrote:
VW_Jimbo wrote:
http://www.klokkerholmusa.com/52-79-rear-wheelhouse-rear-lower-splash-panel-section-passengers-side/

Straight from their website.

I believe that part goes below the part I am looking for.


This is the part you are looking for on their site. klokkerholm replacement panels are garbage, so if you can find this part from someone else, that would be your best bet. Use the entire part or cut off what you need.

The picture shows it upside down and from the back view.

http://www.klokkerholmusa.com/65-79-rear-cross-member-drivers-side/

http://www.klokkerholmusa.com/65-79-rear-cross-member-passengers-side/
_________________
Formerly known in the forums as "OVALTEEN"

"I firmly believe that some villagers from Botswana could probably build a better road than PennDot."- Splitty

"If you do anything to your car someone will hate on you for it. People absolutely love to complain and find fault with others. Don't let it bother you. Just live and have fun."- Lind
Back to top
View user's profile Send private message Gallery Classifieds Feedback
TryToBeOriginal
Samba Member


Joined: July 23, 2012
Posts: 224
Location: Pflugerville, Texas
TryToBeOriginal is offline

PostPosted: Fri Dec 07, 2018 6:34 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

the part you have circled in your post is definitely the cross member but if you need the part that goes over top of the cross member you need this:

http://www.wolfsburgwest.com/cart/DetailsList.cfm?ID=113813111BH

somewhere around here was an amazing exploded diagram of how all these parts meet up. I'll have to see if I can find it.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Hokie87
Samba Member


Joined: May 27, 2010
Posts: 261
Location: Richmond, VA
Hokie87 is offline

PostPosted: Sat Dec 08, 2018 5:24 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

TryToBeOriginal wrote:
somewhere around here was an amazing exploded diagram of how all these parts meet up. I'll have to see if I can find it.


Is this the diagram?
Image may have been reduced in size. Click image to view fullscreen.


This discussion is also helpful:
https://www.thesamba.com/vw/forum/viewtopic.php?t=...mp;start=0
Back to top
View user's profile Send private message Gallery Classifieds Feedback
TryToBeOriginal
Samba Member


Joined: July 23, 2012
Posts: 224
Location: Pflugerville, Texas
TryToBeOriginal is offline

PostPosted: Sat Dec 08, 2018 3:14 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Hokie87 wrote:
TryToBeOriginal wrote:
somewhere around here was an amazing exploded diagram of how all these parts meet up. I'll have to see if I can find it.


Is this the diagram?
Image may have been reduced in size. Click image to view fullscreen.


This discussion is also helpful:
https://www.thesamba.com/vw/forum/viewtopic.php?t=...mp;start=0


Yup that's the one! I Remember the original thread that was in and the guy restoring the beetle but couldn't remember the name of the thread... It's a shame that beetle sold.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
KnightLife75
Samba Member


Joined: October 19, 2018
Posts: 12
Location: TX
KnightLife75 is offline

PostPosted: Sun Dec 09, 2018 7:53 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

So is the green piece in the pic a separate piece from the cross member? Or is that crossmember repair piece?
Back to top
View user's profile Send private message Gallery Classifieds Feedback
thomas.
Samba Member


Joined: July 31, 2010
Posts: 1051
Location: South West (Pa.)
thomas. is offline

PostPosted: Sun Dec 09, 2018 10:03 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

It's this piece in my included link. It attaches to the outside. When you purchase the crossmember it's already attached. When I did mine I bought the end cap , took the old one off and welded the new one on. It probably added an extra 4 hours of hassle to try and save a few bucks and I was sorry I didn't just buy the cross member. Photo below of when I did mine.

http://www.wolfsburgwest.com/cart/DetailsList.cfm?ID=111805091CC

i
Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message AIM Address Gallery Classifieds Feedback
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Sun Dec 09, 2018 6:02 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Great info, thanks everyone. Time to place another order. Shocked
_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Tue Dec 18, 2018 5:50 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

My son and are in the process of replacing the crossmember now.
Picture below is not from ours but gives an idea on the gap

First question where the chassis mounting bolt goes through the top crossmember piece then down through the splash panel inner crossmember piece there is approximately 5/16" of an inche gap between both panels.we are considering drilling the tack welds and moving the inner plate a little so that it will be almost flush. What we are finding is that if we bolt down as is the upper piece distorts as it is pulled down . Any one else run into that.only other idea is to weld in some metal between the two?

Second question
How is the heat tube connected as it goes through the crossmwmber.
Any tricks to getting it out before we tackle that?

Third question any torque spec on the 3 bolts on crossmember replacement?

Image may have been reduced in size. Click image to view fullscreen.

_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Hokie87
Samba Member


Joined: May 27, 2010
Posts: 261
Location: Richmond, VA
Hokie87 is offline

PostPosted: Tue Dec 18, 2018 10:57 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Bigjacksauto wrote:
My son and are in the process of replacing the crossmember now.
Picture below is not from ours but gives an idea on the gap

Image may have been reduced in size. Click image to view fullscreen.


First question where the chassis mounting bolt goes through the top crossmember piece then down through the splash panel inner crossmember piece there is approximately 5/16" of an inche gap between both panels.we are considering drilling the tack welds and moving the inner plate a little so that it will be almost flush. What we are finding is that if we bolt down as is the upper piece distorts as it is pulled down . Any one else run into that.only other idea is to weld in some metal between the two?


This is the same car after mounting back on the chassis. I didn't notice it at the time but it appears there may be some minor distortion. Test fit and tighten the bolt before you paint.
Image may have been reduced in size. Click image to view fullscreen.


Bigjacksauto wrote:
Second question
How is the heat tube connected as it goes through the crossmwmber.
Any tricks to getting it out before we tackle that?


Heater channel goes to -- not through -- the cross member.
Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Tue Dec 18, 2018 12:45 pm    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

That looks great.
Definentley testing over and over before fully installing.
I will maybe just shim up inside gap a little
_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Bigjacksauto
Samba Member


Joined: June 18, 2018
Posts: 135
Location: Syracuse NY
Bigjacksauto is offline

PostPosted: Wed Dec 19, 2018 7:58 am    Post subject: Re: Sheet metal availability question inside above heater channel an Reply with quote

Hokie87 wrote:
Bigjacksauto wrote:
My son and are in the process of replacing the crossmember now.
Picture below is not from ours but gives an idea on the gap

Image may have been reduced in size. Click image to view fullscreen.


First question where the chassis mounting bolt goes through the top crossmember piece then down through the splash panel inner crossmember piece there is approximately 5/16" of an inche gap between both panels.we are considering drilling the tack welds and moving the inner plate a little so that it will be almost flush. What we are finding is that if we bolt down as is the upper piece distorts as it is pulled down . Any one else run into that.only other idea is to weld in some metal between the two?


This is the same car after mounting back on the chassis. I didn't notice it at the time but it appears there may be some minor distortion. Test fit and tighten the bolt before you paint.
Image may have been reduced in size. Click image to view fullscreen.


Bigjacksauto wrote:
Second question
How is the heat tube connected as it goes through the crossmwmber.
Any tricks to getting it out before we tackle that?


Heater channel goes to -- not through -- the cross member.
Image may have been reduced in size. Click image to view fullscreen.

Hokie it looks like the metal compressed down about a 1/4" or so,does that sound about right? Also did you torque it to a certain spec?
_________________
1939 Studebaker Champion
1968 Beetle "Herbie" replica Father Son Project
1960 Beetle deluxe / Flint/Pebble Grey og 1200cc 36hp

(o\_!_/o)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Display posts from previous:
Reply to topic    Forum Index -> Beetle - 1958-1967 All times are Mountain Standard Time/Pacific Daylight Savings Time
Page: 1, 2  Next
Page 1 of 2


Jump to:
You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot vote in polls in this forum

About | Help! | Advertise | Donate | Premium Membership | Privacy/Terms of Use | Contact Us | Site Map
Copyright © 1996-2018, Everett Barnes. All Rights Reserved.
Not affiliated with or sponsored by Volkswagen of America | Forum powered by phpBB
