PostPosted: Thu Apr 08, 2010 10:32 am    Post subject: Park brake cables for Lowered BD Reply with quote

I've searched on this, but with no concrete answer.

Anyone know which park brake cables to use on a BD (54') running a type 1 straight axle?

I'm using 356 brakes, but the cable works the same on a bug, so the end after the sheath (going into the drum) should be fine.

Any thoughts on using 55-59' type 2 calbes? My thought is that the park brake handle is in roughly the same spot on Barndoor and Wolfsburg bus.

It looks like the original cable part # is 211 609 275 A (3205mm long)

The 55'-59' is Part #211 609 701 B and (3168mm ling)

Thanks in advance,

Ken
_________________
C-1
Back to top
View user's profile Send private message Send e-mail Visit poster's website Facebook Gallery Classifieds Feedback
BeaterBarndoor
Samba Member


Joined: December 15, 2000
Posts: 773
Location: North Carolina
BeaterBarndoor is offline

PostPosted: Thu Apr 08, 2010 11:41 am    Post subject: Reply with quote

its been 8 or 9 years but im pretty sure that when i put my 53 together,i just used what was in place which I believe to be the original cables. Im pretty sure that i am running the whole stock BD set up even the cable end housings(look like beetle) right into the backing plates,no adaptors .
_________________
www.thebustransfer.com

Whaaaaat?
Back to top
View user's profile Send private message Visit poster's website AIM Address Gallery Classifieds Feedback
Scotty
Samba Member


Joined: July 02, 2003
Posts: 1476
Location: Northampton - Uk
Scotty is offline

PostPosted: Thu Apr 08, 2010 12:56 pm    Post subject: Reply with quote

Yep, I used og cables on my 52 with straight axle and type 3 brakes. The only thing I had to do was elongate the slot in the bar that goes between the brake shoes, to allow the arm to move forward a little
_________________
EverettB wrote:

I'd be curious to know the length of his tip.


http://scottys-stuff.blogspot.com/
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Long-roofs
Samba Member


Joined: March 20, 2002
Posts: 2090
Location: Millwood, Wa
Long-roofs is offline

PostPosted: Tue Apr 13, 2010 1:13 pm    Post subject: Reply with quote

I used the original cables on my '55, '70 T1 rear backing plates, no problems, even added 36hp carb. return springs to the cables inside the backing plate to help with release.
_________________
---
Some days, too many people know me
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Concept1
Samba Member


Joined: September 07, 2004
Posts: 333
Location: Calgary, Canada
Concept1 is offline

PostPosted: Tue Apr 13, 2010 9:20 pm    Post subject: Reply with quote

Thanks guys. My original cables were totally wasted, but I'll see what I can come up with.
_________________
C-1
Back to top
View user's profile Send private message Send e-mail Visit poster's website Facebook Gallery Classifieds Feedback
Kais Collection Premium Member
vintage treasures


Joined: February 18, 2005
Posts: 1565
Location: Rotterdam, The Netherlands
Kais Collection is offline

PostPosted: Wed Apr 14, 2010 2:04 am    Post subject: Reply with quote

Concept1 wrote:
Thanks guys. My original cables were totally wasted, but I'll see what I can come up with.

Is this what you need?

Image may have been reduced in size. Click image to view fullscreen.


I have some laying around, NOS.
but I thought they were part# 211 609 271A?
_________________
Insta: @kaiscollectionvt
Fb: @KaisCollectionVT
Please check my ads: https://www.thesamba.com/vw/classifieds/search.php?username=Kais+Collection

Kai's Collection - vintage treasures

Oct '53 Kombi
Back to top
View user's profile Send private message Send e-mail Facebook Instagram Gallery Classifieds Feedback
djfordmanjack
Samba Member


Joined: June 15, 2009
Posts: 1419
Location: Graz, Austria, Europe
djfordmanjack is offline

PostPosted: Thu Apr 22, 2010 10:31 am    Post subject: Reply with quote

On a split bug I had trouble to fit later rear and cables to the front parking brake lever. What I did is fabricate some adapter cables ( basically eytensions). You can get any dimension at the sailing surplus, I cut the cables fitting length, then had female/ male M6 connectors rolled-pressed on the ends. make sure to get the correct total length and tighten the junction with loctite. quite cheap, about 50/ pair incl rolling.
_________________
Hotrods, Fords, Veedubs and Triumph Twins ! ______Barndoor + Kohlruss Coachbuilt DLX afficionado
'51 Brezel project, Azurblau L36
'52 BD Coachbuild project
'54 Oval Sunroof project with my son, L275 Lichtbeige
'55 Wolfsburg panel project, Taubenblau L31 all original paint
'56 Oval, Polarsilber L324 og paint og chrome og everything
Back to top
View user's profile Send private message Gallery Classifieds Feedback
krusher
Samba Member


Joined: September 24, 2002
Posts: 7644
Location: europe
krusher is offline

PostPosted: Thu Apr 22, 2010 11:52 am    Post subject: Reply with quote

I have 356 A brakes and as far as i can remember I just used the stock BD cables Very Happy
