Info on porsche wheels write up.
Page: 1, 2  Next
Forum Index -> Bay Window Bus Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic

what wheels should you run?
stock
52%
 52%  [ 19 ]
porsche with adapters
16%
 16%  [ 6 ]
porsche with re drilled rotors and drums
25%
 25%  [ 9 ]
other
5%
 5%  [ 2 ]
Total Votes : 36

Author Message
ratfalia
Samba Member


Joined: February 16, 2010
Posts: 31
Location: Cullowhee nc
ratfalia is offline

PostPosted: Mon Apr 26, 2010 10:34 pm    Post subject: Info on porsche wheels write up. Reply with quote

Hey guys i wanna start a thread coming up fully explaining all the information you need on converting your bay 112 lug pattern to use porsche's 130 lug pattern


so far i have these threads showing what you need

differences between earlier and newer bay lug patterns
early buses (68-71) use 5x205, and 5x112 for the lates (72-79)


Having 944/924 phone dial wheels
this thread says that you will basically have to use adapters and have to pull the rear fenders out some
http://www.thesamba.com/vw/forum/viewtopic.php?t=381675&highlight=porsche+wheels

a place you can buy the adapters (also if you can find adapters for cheaper ex. ebay)
http://www.urotuning.com/shop/wheel-adapters-hr-5x112-to-5x130-15mm-thick-p-374.html

http://cgi.ebay.com/ebaymotors/ws/eBayISAPI.dll?Vi...0425100122



Fuch wheels

talking about the diffrence between real and Wide 5 Fuch knock offs
let me know if you have links for this
Cip1 sells 5x112 fuch knock-offs for later buses with the 5x112.

great write up on how to re drill for 5x130 how to tap and die your own rotors for 5x130
http://www.thesamba.com/vw/forum/viewtopic.php?t=333929&highlight=porsche+wheels


porsche twists great write up here using adapters on all 4 wheels but said no rub. i am personally gonna run this set up ill let you guys know how it goes.
http://www.volkszone.co.uk/VZi/showthread.php?t=455131

if there are any ones else im sure there are feel free to add in here. just wanted to get every cleared up on some stuff and send them to the right places.

hope you will enjoy

thanks
Marshall
Back to top
View user's profile Send private message Gallery Classifieds Feedback
ratfalia
Samba Member


Joined: February 16, 2010
Posts: 31
Location: Cullowhee nc
ratfalia is offline

PostPosted: Mon Apr 26, 2010 10:37 pm    Post subject: FUCHS STYLE REPLICA WHEELS clip1 Reply with quote

http://www2.cip1.com/searchresults.asp?cat=1931
Back to top
View user's profile Send private message Gallery Classifieds Feedback
ratfalia
Samba Member


Joined: February 16, 2010
Posts: 31
Location: Cullowhee nc
ratfalia is offline

PostPosted: Tue Apr 27, 2010 6:16 pm    Post subject: Reply with quote

also for got to say feel free to post pics of your set up. the more the better Smile
Back to top
View user's profile Send private message Gallery Classifieds Feedback
chabanais
Samba Member


Joined: July 27, 2002
Posts: 4866

chabanais is offline

PostPosted: Tue Apr 27, 2010 6:24 pm    Post subject: Reply with quote

Sounds good. I'd say adapters are bad and Chinese-made imitation Porsche wheels are worse.

Learning about running a different bolt pattern and what fits would be cool.
_________________
"I spud therefore I yam."
Back to top
View user's profile Send private message Gallery Classifieds Feedback
ratfalia
Samba Member


Joined: February 16, 2010
Posts: 31
Location: Cullowhee nc
ratfalia is offline

PostPosted: Tue Apr 27, 2010 6:50 pm    Post subject: Reply with quote

ive also heard that some people use 944 hubs but really cant find to much information for a direct bolt on. but that would be something you are talking about. I know some people do that when they switch to 944 rear brakes.

any body out there have done this? or have a link to doing so?
Back to top
View user's profile Send private message Gallery Classifieds Feedback
fatmatt650
Samba Member


Joined: November 18, 2008
Posts: 136
Location: Pacifica, Ca
fatmatt650 is offline

PostPosted: Tue Apr 27, 2010 8:50 pm    Post subject: Reply with quote

Thanks for the info. I have a 72 hightop that needs new tires and I want to go 15's for added stability. I bought a set of mercedes wheels that were advertised as a "direct fit" but are totally not and I can't find the correct hardware anywhere. The guy who sold them to me is a stand up sorta dude and said he'd take them back if I can't use them so I'm thinking of going this route w/ the 15x6 AE fuchs I picked up at bugorama a couple years ago. I've got machine shop access and rudimentary skills. Where does one find the "Drill guide cut on water jet" mentioned in the link? Could I do w/o this w/ careful measuring? How difficult is it to be exact enough for this project?
_________________
62 Single Cab
67 Baja Squareback
72 Highroof
86 Scirocco
"So much to do...so little time."
Back to top
View user's profile Send private message AIM Address Gallery Classifieds Feedback
drumming123
Samba Member


Joined: April 04, 2004
Posts: 722
Location: Merced California
drumming123 is offline

PostPosted: Tue Apr 27, 2010 9:00 pm    Post subject: Reply with quote

fatmatt650 wrote:
Thanks for the info. I have a 72 hightop that needs new tires and I want to go 15's for added stability. I bought a set of mercedes wheels that were advertised as a "direct fit" but are totally not and I can't find the correct hardware anywhere. The guy who sold them to me is a stand up sorta dude and said he'd take them back if I can't use them so I'm thinking of going this route w/ the 15x6 AE fuchs I picked up at bugorama a couple years ago. I've got machine shop access and rudimentary skills. Where does one find the "Drill guide cut on water jet" mentioned in the link? Could I do w/o this w/ careful measuring? How difficult is it to be exact enough for this project?


HEY! IS THIS YOUR BUS!?
Image may have been reduced in size. Click image to view fullscreen.

Me and my gal went for a road trip down highway one, and were eating at Camelot Fish & Chips and then went to safe way, on our way out to the freeway, I seen this hightop parked right across the street, so I went over and parked next to it and snapped a photo. I waited outside for a few minutes hoping I'd get a chance to talk, but you never came. Anyway, if thats you, then nice bus Cool
Back to top
View user's profile Send private message Gallery Classifieds Feedback
fatmatt650
Samba Member


Joined: November 18, 2008
Posts: 136
Location: Pacifica, Ca
fatmatt650 is offline

PostPosted: Tue Apr 27, 2010 9:34 pm    Post subject: Reply with quote

Sweet dude! Yeah, It was parked at the tire shop for the day getting new shocks and the wheels from my '71 swapped onto it for an upcoming camping trip (they had the vanco tires on it) as well as having the tire shop guys work on fitting the mercedes rims. Sick bus, I was hoping to find a '71 myself when I was shopping for mine but this one just had my name on it. What is that high top? I've never seen one like it before? By the way, I'm drinking Smithwick's right now, Camelot is the only other place I've ever seen that stuff until Safeway started carrying it recently.
_________________
62 Single Cab
67 Baja Squareback
72 Highroof
86 Scirocco
"So much to do...so little time."
Back to top
View user's profile Send private message AIM Address Gallery Classifieds Feedback
fatmatt650
Samba Member


Joined: November 18, 2008
Posts: 136
Location: Pacifica, Ca
fatmatt650 is offline

PostPosted: Tue Apr 27, 2010 9:38 pm    Post subject: Reply with quote

"Suppose you're thinking about a plate of shrimp" - LOL
http://www.thesamba.com/vw/forum/viewtopic.php?t=410613&start=80
_________________
62 Single Cab
67 Baja Squareback
72 Highroof
86 Scirocco
"So much to do...so little time."
Back to top
View user's profile Send private message AIM Address Gallery Classifieds Feedback
rcrjacob
Samba Member


Joined: June 23, 2008
Posts: 174
Location: Vacaville, CA
rcrjacob is offline

PostPosted: Wed Apr 28, 2010 9:15 am    Post subject: Reply with quote

I have 944 spindles for the front. Will run 944 vented rotor and wilwood 4 piston calipers. Rear setup is from oldspeed. 944 rear discs with drum in a disc ebrake. Redrilled rear hubs and 944 vented rotors. Stock 944 calipers. I allready have the hubs and brackets for the calipers on the front, and have the complete setup minus rotors for the rear. I can't wait to put them on.
Will be running 18x8 Turbo twist wheels with 245/40/18 tires.
Back to top
View user's profile Send private message Yahoo Messenger Facebook Twitter Gallery Classifieds Feedback
W1K1
Samba Member


Joined: March 04, 2004
Posts: 3767
Location: Southern AB
W1K1 is offline

PostPosted: Wed Apr 28, 2010 9:27 am    Post subject: Reply with quote

Lanner does all sorts of conversions and billet hubs
http://www.vdubengineering.com/products/porscheconversions.htm

Quote:
ive also heard that some people use 944 hubs but really cant find to much information for a direct bolt on. but that would be something you are talking about. I know some people do that when they switch to 944 rear brakes.

_________________
http://www.thesamba.com/vw/archives/manuals/jim_martin_engine_build.php

1973 super
1965 squareback 1500E
Back to top
View user's profile Send private message Gallery Classifieds Feedback
rcrjacob
Samba Member


Joined: June 23, 2008
Posts: 174
Location: Vacaville, CA
rcrjacob is offline

PostPosted: Wed Apr 28, 2010 9:33 am    Post subject: Reply with quote

Lanner did my front setup.
Back to top
View user's profile Send private message Yahoo Messenger Facebook Twitter Gallery Classifieds Feedback
ratfalia
Samba Member


Joined: February 16, 2010
Posts: 31
Location: Cullowhee nc
ratfalia is offline

PostPosted: Wed Apr 28, 2010 1:28 pm    Post subject: Reply with quote

rcrjacob wrote:
I have 944 spindles for the front. Will run 944 vented rotor and wilwood 4 piston calipers. Rear setup is from oldspeed. 944 rear discs with drum in a disc ebrake. Redrilled rear hubs and 944 vented rotors. Stock 944 calipers. I allready have the hubs and brackets for the calipers on the front, and have the complete setup minus rotors for the rear. I can't wait to put them on.
Will be running 18x8 Turbo twist wheels with 245/40/18 tires.


thats gonna be dope deff get some pics up here so i can see them
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Airkewld
Samba Member


Joined: November 14, 2003
Posts: 3060
Location: 3673 South Bullard Ave, Suite 117-118, Goodyear, AZ 85338
Airkewld is offline

PostPosted: Thu Jun 13, 2013 8:40 am    Post subject: Reply with quote

I have a client with a 68 DOuble cab trying to run the 17" fuchs in the rear. What rear drum applications allow for the redrill in the rear to fit the 5x130mm bolt pattern? Thanks for any and all help you can provide.
_________________
TIME, we all need more of it. Purchase #PRObuilt Products from Airkewld and free up time for family and friends. - https://www.airkewld.com/PRO-Built-s/2452.htm
Back to top
View user's profile Send private message Send e-mail Visit poster's website Facebook Twitter Instagram Gallery Classifieds Feedback
williamM
Samba Member


Joined: August 07, 2008
Posts: 4324
Location: southwest Arizona
williamM is offline

PostPosted: Thu Jun 13, 2013 9:06 am    Post subject: had these for a year Reply with quote

I haven't had a chance to pull these yet but wanted to know if anybody recognizes this set up??[img]
Image may have been reduced in size. Click image to view fullscreen.
[img]
_________________
some days I get up and just sit and think. Some days I just sit.

opinion untempered by fact is ignorance.

Don't step in any!
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
babysnakes
Samba Member


Joined: August 19, 2008
Posts: 6469

babysnakes is offline

PostPosted: Thu Jun 13, 2013 3:55 pm    Post subject: Reply with quote

Airkewld wrote:
What rear drum applications allow for the redrill in the rear to fit the 5x130mm bolt pattern?


Uhmm. They used drums for 3 years. I thought you just drilled and rolled, could be wrong though. I thought you would know. Confused
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Airkewld
Samba Member


Joined: November 14, 2003
Posts: 3060
Location: 3673 South Bullard Ave, Suite 117-118, Goodyear, AZ 85338
Airkewld is offline

PostPosted: Thu Jun 13, 2013 4:19 pm    Post subject: Reply with quote

babysnakes wrote:
Airkewld wrote:
What rear drum applications allow for the redrill in the rear to fit the 5x130mm bolt pattern?


Uhmm. They used drums for 3 years. I thought you just drilled and rolled, could be wrong though. I thought you would know. Confused


These drums have a fluted snout that does not make them applicable for drilling.
_________________
TIME, we all need more of it. Purchase #PRObuilt Products from Airkewld and free up time for family and friends. - https://www.airkewld.com/PRO-Built-s/2452.htm
Back to top
View user's profile Send private message Send e-mail Visit poster's website Facebook Twitter Instagram Gallery Classifieds Feedback
VWsArent4Hippies
Samba Member


Joined: April 13, 2005
Posts: 2971
Location: The Bull City
VWsArent4Hippies is offline

PostPosted: Thu Jun 13, 2013 4:31 pm    Post subject: Reply with quote

Airkewld wrote:
I have a client with a 68 DOuble cab trying to run the 17" fuchs in the rear. What rear drum applications allow for the redrill in the rear to fit the 5x130mm bolt pattern? Thanks for any and all help you can provide.


There isn't one. Even if he converted to late 5x112 drums, in my opinion there isn't enough meat on the drum where you'd have to drill, to drill safely. Have him call Russell at Old Speed and get set up with a 5x130 disc conversion
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
babysnakes
Samba Member


Joined: August 19, 2008
Posts: 6469

babysnakes is offline

PostPosted: Thu Jun 13, 2013 5:11 pm    Post subject: Reply with quote

VWsArent4Hippies wrote:
get set up with a 5x130 disc conversion


This is the direction I'm going with my '69.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Dogo
Samba Member


Joined: May 21, 2009
Posts: 244
Location: Canada
Dogo is offline

PostPosted: Fri Aug 09, 2013 5:59 pm    Post subject: Reply with quote

VWsArent4Hippies wrote:
Airkewld wrote:
I have a client with a 68 DOuble cab trying to run the 17" fuchs in the rear. What rear drum applications allow for the redrill in the rear to fit the 5x130mm bolt pattern? Thanks for any and all help you can provide.


There isn't one. Even if he converted to late 5x112 drums, in my opinion there isn't enough meat on the drum where you'd have to drill, to drill safely. Have him call Russell at Old Speed and get set up with a 5x130 disc conversion


Is something like this what you guys talking about?

http://transporterhaus.com/index.php?option=com_content&task=view&id=134&Itemid=171
Back to top
View user's profile Send private message Gallery Classifieds Feedback
