wider beam?

[thext94]

I know it's possible to widen a bj beam by welding in tubes to make it longer, but am I better off buying a widened lp beam off of chirco or something? I haven't seen anybody selling widen bj beams, is that because it's just better to go lp if you're widening anyway? Also my beam is tied into the cage, but I also still have the frame head. Where does the frame head need to be notched to fit the lp beam?

(yes it's dirty, sorry it's an old pic )

Thanks,
Tyler

[thesatelliteguy]

Ive never heard of any one notching the frame head to fit a different type beam in their car. I guess it could be done, but i dont think its the best idea. Though you do have it tied into your cage and that will make it a bit stronger.

On a different though, if you notch it, you will have to notch for the lower beam, other wise you have to replace the cage that ties into the beam. So you go ahead and notch the frame head for the lower beam, but this just raised the beam up, which lowers the car down.

So i think you might as well remove the cage tubes that tie into the beam, remove the frame head, weld in a LP beam head and get new tubing made. I know its a lot of work, but its better for the long run.

Or just settle with a widened BJ beam.
_________________
Toyotas are so bumpy it makes me sick, literally.

My build Page http://www.thesamba.com/vw/forum/viewtopic.php?t=383878

[retterath]

Using a LP beam requires notching for the top tube. The bottom stays the same.
But since you'll have to rehash the the cage anyway, might as well eliminate the frame head all together.
And might as well push it forward 8 inches.
And might as well go with +4 arms, and coil overs, and . . .

[thext94]

[retterath]

No. It won't.
LP tubes are closer together.

If you only want wider, just widen what you've got.

[shred625]

There is a guy on the classifieds that sells a widened link beam that fits int he ball-joint framehead. I dont know how good they are but it is an option.
_________________
“It takes a big man to cry, but it takes a bigger man to laugh at that man.”
~ Jack Handey

[tanner_122]

tyler theres a guy that sells metal bj to lp addapters in the classifieds here
i bought a set
over spring break im throwing a 6 over beam on my car with the addapters and tieing it into the cage the addapters also push the beam 1.75" forward
_________________
91 jeep Cherokee "TANK"

[58Dub]

The adapter would probably be the easiest way to do it...then pickup a couple LP beams and get makin
_________________
58 Beetle (now just a pile of parts in the corner)
60 Beetle (2221 turbo under construction)
70 Beetle Baja project

[thext94]

[tanner_122]

[thext94]

[dirtkeeper]

Thinkin out loud here

when you widen the front beam how does it affect the handling?

i imagine its more stable

but will it effect the steering if the fronts wider than the rear



since the torsion springs are cut in the middle if the arms react differently...seems they would because the torsion would not transfer some enrgy from side to side...

and where you place the adjusters or grub screws could change how long torsion is. i would assume the longer the better ride.

i've thought about adding a couple inches to the bj one i'm putting together
