PostPosted: Wed Oct 24, 2007 8:30 am    Post subject: Barndoor heater tubes Reply with quote

this might sound like a dumb question but here it goes......does anyone know if there is a difference between early(BD), and later heater tubes front side diameter????...how about the forward and the rear chassis crossbrace hole diameter where the heater tube passes thru??????I have some clients that are telling me that the tube is too large, too small...etc...I have an NOS chassis crossbrace, and the diameter is 7cm........any help would be greatly appreciated.......
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Wed Oct 24, 2007 10:59 am    Post subject: Reply with quote

Hi,

Rear is 3" (7.7mm)hole in cross member and front is 2.75" (7cm)in crossmember. These are taken from panels made by someone else that i believe to be correct. When i fitted these exact panels to the 52 and they seemed to tally with the original heater tube i refitted(undamaged and for the most part not rusty) which was tapered from one end to the other too.
I dont know if later Bd had the non tapered version as in post 55 vans.
I will take try and take some measurements from the original heater tube if it helps.
I would be interested in the year question too as it may be me who has the wrong panels.

Thanks for the panels

Cheers

Mark
Back to top
View user's profile Send private message Gallery Classifieds Feedback
euroduncan
Samba Member


Joined: June 05, 2004
Posts: 15

euroduncan is offline

PostPosted: Thu Oct 25, 2007 4:18 am    Post subject: Reply with quote

The heater tube is tapered needing the dimensions you say. This is correct for 53,54. As I don't have an earlier bus I can't tell you about other years.
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
RockStock
Samba Member


Joined: November 26, 2004
Posts: 3229
Location: England
RockStock is offline

PostPosted: Thu Oct 25, 2007 5:08 am    Post subject: Reply with quote

the feet on later heater tubes are angled, aren't they
feet on earlier buses go straight down?
_________________
-StockRocks-
Back to top
View user's profile Send private message Send e-mail Instagram Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Thu Oct 25, 2007 6:50 am    Post subject: Reply with quote

RockStock wrote:
the feet on later heater tubes are angled, aren't they
feet on earlier buses go straight down?

Not sure which parts you mean by "feet", Do you mean the 2 welded on clips that hold the front flexy pipe on?
When i assembled my van i could not figure how they would have assembled originally as with the two clips on the tube it will not go through the front centre chassis hole and the chassis section cant be slid on from the other end as the tube is too fat, so may be clips added after?
So 52-54 is tapered (possibly 8cm to 7cm across its length), im not sure my 51 has any left to check, some one will know im sure. I assume it was a slight attempt to increase the air speed in the cab as it comes out the vents?
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Thu Oct 25, 2007 6:56 am    Post subject: Reply with quote

so where do we stand with the measurements????the heater tube hole in my NOS rear chassis crossbrace is 7cm, I assume this is the same for all years...the front would then be 6.5cm for 1950, 51, 52...and different for 53, 54, 55 ?????? does this sound right????? Confused Confused Confused Confused Confused
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Thu Oct 25, 2007 7:11 am    Post subject: Reply with quote

here is a picture/measurement of the hole for the heater tube on my NOS rear chassis cross brace...does anyone have a picture of the front????different year fronts????
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Thu Oct 25, 2007 7:13 am    Post subject: Reply with quote

forgot the god damned link Embarassed Embarassed Embarassed Embarassed Embarassed Embarassed
http://www.thesamba.com/vw/forum/album_page.php?pic_id=390447
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Thu Oct 25, 2007 7:17 am    Post subject: Reply with quote

Not sure exactly where we are with the measurements if you have an Nos rear at 7cm, but is it possible the Nos one could be a later one?? I really dont know.
Im saying that rear is 77mm and front is 70mm hole and between Duncan and myself we have heater tubes in a 52, 53 and 54 that reflect this size.
My 80mm mention in my last post was just an assumption based on the fact the tube sticks out past the chassis cross centre.
A few more people need to measure up to be sure i guess with Og heater tubes.

The front hole and heater tube diameter is 70mm just to confirm.

Cheers

mark
Back to top
View user's profile Send private message Gallery Classifieds Feedback
RockStock
Samba Member


Joined: November 26, 2004
Posts: 3229
Location: England
RockStock is offline

PostPosted: Thu Oct 25, 2007 8:23 am    Post subject: Reply with quote

RockStock wrote:
the feet on later heater tubes are angled, aren't they
feet on earlier buses go straight down?


sorry, i was missing the point - i was on about the the heater logs in the cargo area.
_________________
-StockRocks-
Back to top
View user's profile Send private message Send e-mail Instagram Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Sat Oct 27, 2007 5:00 am    Post subject: Reply with quote

Hi Gerson,

After looking at a picture of an nos bd rear cross member i have here, i think- and i could be wrong as i often can be but i think that rear cross member in your picture is not a Bd one. The hole size, cut out and a missing cut out point to it being possibly a later one.
On the picture i have the hole is defiantly around 1/2 cm either side nearer the edges.
Cheers

Mark
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Sat Oct 27, 2007 7:25 am    Post subject: Reply with quote

52panelvan, can you post a picture of it??thanks
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
Anchovy
Samba Member


Joined: August 05, 2000
Posts: 2627
Location: San Diego, CA
Anchovy is offline

PostPosted: Sat Oct 27, 2007 12:15 pm    Post subject: Reply with quote

Gerson wrote:
here is a picture/measurement of the hole for the heater tube on my NOS rear chassis cross brace...does anyone have a picture of the front????different year fronts????

Image may have been reduced in size. Click image to view fullscreen.





helping hand on the photo
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Sat Oct 27, 2007 1:11 pm    Post subject: Reply with quote

thanks a bunch Very Happy Very Happy Very Happy Very Happy
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Sat Oct 27, 2007 2:45 pm    Post subject: Reply with quote

Hi Gerson, i have sent you a pm

Mark
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Sat Nov 17, 2007 12:40 pm    Post subject: Reply with quote

Mark, you guys are right on the heater tube/chassis crossbrace issue....I just went through my pile of cut up BD parts, and I found a rear and a front crossbrace with pieces of the og heater tube still attached, the rear is 7.7cm, and the front is 7.0cm Very Happy Very Happy Very Happy Very Happy , you are correct, the NOS rear chassis crossbrace that I have is a post BD piece....I am glad this issue is solved, the correct parts will be included in Chris's next shipment.....now, on to the next BD parts mistery Very Happy Very Happy Very Happy Very Happy ....I tell you, this never ends, learn soemthing new every day.....
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Sat Nov 17, 2007 2:47 pm    Post subject: Reply with quote

Glad to of helped. The amount of changes 50-53, small differences in the frame and panels is amazing. May be there should be a thread just for these.

Cheers
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Gerson
Samba Member


Joined: January 23, 2004
Posts: 1826
Location: Jupiter Fl
Gerson is offline

PostPosted: Sat Nov 17, 2007 3:04 pm    Post subject: Reply with quote

I agree Very Happy Very Happy Very Happy Very Happy
_________________
that's not patina, that's fucking rust man!!!!

we (klassicfab) make the funky green panels...........
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
musclebus
Samba Member


Joined: February 23, 2006
Posts: 171
Location: UK, Dorset, BD Heaven and Hell
musclebus is offline

PostPosted: Sat Nov 17, 2007 7:27 pm    Post subject: Reply with quote

Gerson wrote:
the correct parts will be included in Chris's next shipment.....learn something new every day.....


cool news Cool .....and correct Very Happy

if only we had access to one of the original vw factory workers (Marks getting there though Twisted Evil Cool )
_________________
www.musclebus.co.uk
Check out our last remaining Klassicfab panels in stock
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
barndoormambo
Samba Member


Joined: April 25, 2005
Posts: 435
Location: East Coast, Homeland
barndoormambo is offline

PostPosted: Fri Apr 01, 2011 6:56 am    Post subject: Reply with quote

..does anyone have a pic of the OG 70mm flexi hose?
- & , besides modern substitutes, does anyone know whre i can find one? Confused
