 Posted: Mon Nov 09, 2015 3:27 pm Post subject: Distributor is stuck |
 |
|
I have loosen the bolt that holds the distibutor in place in order to set timing but it won't turn.
Need advice how to solve this problem.
|
|
| Back to top |
|
 |
crownline
Samba Member
Joined: September 10, 2010
Posts: 613
Location: Northwoods of WI
|
| Posted: Mon Nov 09, 2015 4:27 pm Post subject: |
|
|
See if you can use a screwdriver in-between the bolt to gently pry apart clamp.
_________________
1972 Bus 1700 cc Single Carb. But not a progressive.
Barelymuvin
Wish I still had the ones I got rid of.
"It"s got some dings and dents and neither of us is going to SEMA."(Update, I went to SEMA in 2019 but the Bus stayed home)
[url=http://www.vw-mplate.com/mplate-8446.png]Click to view image[/URL] |
|
| Back to top |
|
|
Tcash
Samba Member
Joined: July 20, 2011
Posts: 12843
Location: San Jose, California, USA
|
| Posted: Mon Nov 09, 2015 4:51 pm Post subject: |
|
|
Spray wd-40 under the clamp, so it wicks down the distributor shaft. On that shaft is a rubber seal that dries out and gets stuck.
Good luck
Tcash |
|
| Back to top |
|
|
Tom Powell
Samba Member
Joined: December 01, 2005
Posts: 4852
Location: Kaneohe
|
| Posted: Mon Nov 09, 2015 6:29 pm Post subject: |
|
|
| Tcash wrote: |
Spray wd-40 under the clamp, so it wicks down the distributor shaft. On that shaft is a rubber seal that dries out and gets stuck.
Good luck
Tcash |
Some of the replacement distributor shaft o-rings are a bit oversize from OG and require some muscle to get the shaft in the hole. That might be a contributing factor. Loosening the nut and prying the clamp wider will probably solve the problem. Don't take the nut off and lose the special screw.
Probably time for a new fan belt. Buy two and keep a spare.
Aloha
tp |
|
| Back to top |
|
|
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79840
Location: Sneaking up behind you
|
| Posted: Mon Nov 09, 2015 6:51 pm Post subject: |
|
|
| crownline wrote: |
| See if you can use a screwdriver in-between the bolt to gently pry apart clamp. |
You'll bend the clamp.
Get a strap wrench.
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
Tom Powell
Samba Member
Joined: December 01, 2005
Posts: 4852
Location: Kaneohe
|
| Posted: Mon Nov 09, 2015 7:13 pm Post subject: |
|
|
| Glenn wrote: |
| crownline wrote: |
| See if you can use a screwdriver in-between the bolt to gently pry apart clamp. |
You'll bend the clamp.
Get a strap wrench.
|
That tool was useless for holding a Vanagon water pump pulley to remove the bolts from the pulley. It took a real strap wrench from NAPA for that job.
http://www.napaonline.com/Catalog/CatalogItemDetai...0210903481
The pulley strap wrench is expensive and the one pictured by Glenn may be adequate for the distributor.
Aloha
tp |
|
| Back to top |
|
|
Wildthings
Samba Member
Joined: March 13, 2005
Posts: 52510
|
| Posted: Mon Nov 09, 2015 7:23 pm Post subject: |
|
|
| Spray it up as mentioned. If the engine has been clean with no oil film for a long time and experienced some corrosion because of this, the distributor can seize very tightly into the case. You can made a wooded punch with which to apply force the the "bilge" of the distributor and maybe jar the dizzy body a bit to break the corrosion loose. Very light sideways taps against the vacuum can may help as well, but don't get carried away here, do use wood between your hammer and the can and go easy. |
|
| Back to top |
|
|
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79840
Location: Sneaking up behind you
|
| Posted: Mon Nov 09, 2015 7:23 pm Post subject: |
|
|
| Tom Powell wrote: |
| Glenn wrote: |
| crownline wrote: |
| See if you can use a screwdriver in-between the bolt to gently pry apart clamp. |
You'll bend the clamp.
Get a strap wrench.
|
That tool was useless for holding a Vanagon water pump pulley to remove the bolts from the pulley. It took a real strap wrench from NAPA for that job.
http://www.napaonline.com/Catalog/CatalogItemDetai...0210903481
The pulley strap wrench is expensive and the one pictured by Glenn may be adequate for the distributor.
Aloha
tp |
The picture was of illustration, i wasn't recommending that specific wrench.
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
60's Burnout
Samba Member
Joined: December 10, 2006
Posts: 424
Location: SF Bay Area
|
| Posted: Mon Nov 09, 2015 8:59 pm Post subject: |
|
|
| A tangential strike with a big f*cking hammer usually works. |
|
| Back to top |
|
|
Tcash
Samba Member
Joined: July 20, 2011
Posts: 12843
Location: San Jose, California, USA
|
| Posted: Mon Nov 09, 2015 9:00 pm Post subject: |
|
|
When all else fails
Just kidding
Tcash |
|
| Back to top |
|
|
Tom Powell
Samba Member
Joined: December 01, 2005
Posts: 4852
Location: Kaneohe
|
|
| Back to top |
|
|
Dana Champion
Samba Member
Joined: July 06, 2012
Posts: 633
Location: Ventura County, CA
|
| Posted: Mon Nov 09, 2015 11:16 pm Post subject: |
|
|
I've had pretty good success with one of these.
|
|
| Back to top |
|
|
05gh
Samba Member
Joined: September 01, 2011
Posts: 187
Location: The Netherlands
|
| Posted: Tue Nov 10, 2015 2:03 am Post subject: |
|
|
Thanks for the advice I got this hamer out off mine cave.
I sprayed WD-40 and let is sit for one night, and it came loose, thanks. |
|
