PostPosted: Thu Jun 21, 2012 11:24 pm    Post subject: Westy High Top Install - Photo Documentary Reply with quote

My friend Mike (Purplepeopleeater) decided to convert his pop top Westy over to a High Top for ease of camping and added storage space. I'll be taking pictures of the process and posting them up as progress is made.

First a shot of Mike's Westy with the pop top in place.

Image may have been reduced in size. Click image to view fullscreen.


Mike purchased a North American High Top through Northamericanhightops.com, so with a trailer in tow we set off to pick it up from StreamLineAudio in Vancouver WA. With a Subaru H6 installed in his van the trip to Vancouver was quick. Very Happy

Arriving at StreamLineAudio.

Image may have been reduced in size. Click image to view fullscreen.



And now we get to see what this baby looks like!

Image may have been reduced in size. Click image to view fullscreen.



Uh Oh....What did I get myself into! LOL.

Image may have been reduced in size. Click image to view fullscreen.



Carrying the top to the trailer.

Image may have been reduced in size. Click image to view fullscreen.



After a bit of thinking we came up with this support to keep the sides from flapping around to much. The top is sitting upside down in the 4x8 trailer on a piece of rug. Once strapped in place it was very secure.

Image may have been reduced in size. Click image to view fullscreen.



Once loaded we chat a bit about the best way to install the top, what products to use, how to trim to fit etc.

Ready to roll for home....maybe we should stop off somewhere on the way home and see if it would make a good boat Very Happy

Image may have been reduced in size. Click image to view fullscreen.



The top made it home in one piece...now it's time to start having fun. The pop top is unbolted and ready to remove.

Image may have been reduced in size. Click image to view fullscreen.



Top removed and on the grass...next remove the luggage rack.

Image may have been reduced in size. Click image to view fullscreen.



You think Mike is excited to see the top sitting on the van?

Image may have been reduced in size. Click image to view fullscreen.



We lift the high top on and stand back to check it out....going to look great!

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.



Marking the high spots so they can be removed. Some minor trimming is needed to get a good fit.

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.



Top propped up so the high spots can be trimmed.

Image may have been reduced in size. Click image to view fullscreen.



Trimming the top.

Image may have been reduced in size. Click image to view fullscreen.



Checking the fit and progress....little bit at a time.

Image may have been reduced in size. Click image to view fullscreen.



More Trimming

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.



Inside...Going to be Roomy!

Image may have been reduced in size. Click image to view fullscreen.



Well its getting late so time to call it a night. Getting pretty close, some slight trimming on the right side needed still. More progress tomorrow.

Image may have been reduced in size. Click image to view fullscreen.


I'll post up progress as it happens.

Hodakaguy


Last edited by Hodakaguy on Fri Jun 22, 2012 6:27 am; edited 1 time in total
Back to top
View user's profile Send private message Gallery Classifieds Feedback
climberjohn
Samba Member


Joined: January 11, 2005
Posts: 1840
Location: Portland Orygun
climberjohn is offline

PostPosted: Fri Jun 22, 2012 12:38 am    Post subject: Reply with quote

This is a great thread, please keep the photos coming.

-CJ
_________________
'86 Westy, 2.5 Subaru power
Know your limits. Exceed them often.
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
MidwestDrifter
Samba Member


Joined: June 13, 2012
Posts: 769
Location: Kicking Around Australia
MidwestDrifter is offline

PostPosted: Fri Jun 22, 2012 5:52 am    Post subject: Reply with quote

Cool Awesome. Definitely bookmarked, I am interested to see what you guys do for finishing the interior.
_________________
2004 Dodge/Mercedes Sprinter (Custom Camper)
2000 Jetta TDI
1982 Diesel Westy W/ ABA I4 hybrid (Sold)
Epic Road Tripping since 08/05/12 | http://VagariesAbound.blogspot.com/
My Current Build | http://sprinter-source.com/forum/showthread.php?t=41215
Back to top
View user's profile Send private message Gallery Classifieds Feedback
jamesc76
Samba Member


Joined: February 02, 2010
Posts: 1
Location: Nottingham UK
jamesc76 is offline

PostPosted: Fri Jun 22, 2012 6:33 am    Post subject: Reply with quote

I have the same hight top on my van best thing I ever did! Funny to see a mould thats from the UK used in the states!
Back to top
View user's profile Send private message Classifieds Feedback
purplepeopleeater
Samba Member


Joined: July 23, 2005
Posts: 3117
Location: E. Washington
purplepeopleeater is offline

PostPosted: Fri Jun 22, 2012 6:54 am    Post subject: Reply with quote

Thanks for posting up Tom (and help) it will be nice having another shutter bug to help document the process.


Tryin to not rush things too quick here, this is about 80% head scratching and 20% work.

Glue, Seam sealer, Insulation all should be here on the 26th.

I thought about using FRP for the top to line it, but I think the weight will be too much over time for the glue, I will be using a vinyl product over the prodex insulation in either cream color or a sand/mocha color to match the interior.

Here are some links for products I used...

The top,
http://canadianhightops.ca/


The insulation,
http://www.insulation4less.com/
Image may have been reduced in size. Click image to view fullscreen.


I ordered 4ft x 100ft Its buy one get one free so couldn't pass up the deal...I should only need about 100sqft

The glue used for the top can be bought online here....
http://www.autobodytoolmart.com/

Evercoat 813
Image may have been reduced in size. Click image to view fullscreen.


The U-Pol Tiger Seal Urethane Adhesive & Sealant
Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
GBA 88West LA
Samba Member


Joined: September 04, 2008
Posts: 1279
Location: New Hampshire
GBA 88West LA is offline

PostPosted: Fri Jun 22, 2012 11:09 am    Post subject: Reply with quote

Cool looking forward to following this thanks
_________________
88 Westy GL Vanaru 07 2.5 EJ25/AA Trans/oiling plates, 1.14 3rd-.77-4th..solar powered cabin
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
DAIZEE
Samba Member


Joined: January 26, 2010
Posts: 7552
Location: Greater Toronto Area Ontario West Side
DAIZEE is offline

PostPosted: Fri Jun 22, 2012 11:58 am    Post subject: Reply with quote

I've been suggesting a documentary of step by step. Good for you. This will not only help people, it will help 'market' the idea for those who aren't sure. Here would be a thumbs up if we had one Cool
_________________
'09 2.5L Jetta 5 cylinder, 5 spd, super turbo, see thread in H2O Cooled Jetta, etc...
83.5 Vanagon L Riviera Model with 98 1.9L TD AAZ 4 speed Daily Driver 3 out of 4 seasons (sold)
84 Vanagon GL Wolfsburg Westy WBX 4 speed (sold)
Back to top
View user's profile Send private message Send e-mail Facebook Gallery Classifieds Feedback
J Charlton Premium Member
Samba Member


Joined: August 24, 2007
Posts: 1544
Location: The True North Strong and Free
J Charlton is offline

PostPosted: Fri Jun 22, 2012 1:38 pm    Post subject: installs Reply with quote

There is a yahoo forum with step by step processes laid out for the install. It is intended for and restricted to folks who have either purchased tops or are seriously considering it. The entire process has been well documented and laid out. This thread documents the process being followed by Mike as he installs his top. We are in constant communication.
_________________
NAHT hightop availability May 18 2023 -
Bend Oregon - for Oregon, California- (7 tot , 3 available), Kennewick Wa (6 tot, 3 available), Small Car Performance Fife Wa. (7 tot 5 avail ), Fairbanks Alaska (1 tot 0 avail)
Future availability TBD : Springfield Mass. Staunton Va, Florida, Colorado, Grand Junction Co., SLC probably late 2023
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
DAIZEE
Samba Member


Joined: January 26, 2010
Posts: 7552
Location: Greater Toronto Area Ontario West Side
DAIZEE is offline

PostPosted: Fri Jun 22, 2012 2:35 pm    Post subject: Reply with quote

For people who have just an ingling about the possibility/feasibility of going hightop will then appreciate this thread as it has no restrictions in the very early thought process Restrictions eliminate potential.
_________________
'09 2.5L Jetta 5 cylinder, 5 spd, super turbo, see thread in H2O Cooled Jetta, etc...
83.5 Vanagon L Riviera Model with 98 1.9L TD AAZ 4 speed Daily Driver 3 out of 4 seasons (sold)
84 Vanagon GL Wolfsburg Westy WBX 4 speed (sold)
Back to top
View user's profile Send private message Send e-mail Facebook Gallery Classifieds Feedback
JeffRobenolt
Samba Member


Joined: February 25, 2007
Posts: 1513
Location: Wisconsin
JeffRobenolt is offline

PostPosted: Fri Jun 22, 2012 4:33 pm    Post subject: Reply with quote

For me it is not if but when! I defiantly will be getting one.

Do you think it will be easier the finish the top off the van and sitting upside down?

I might need to paint mine and think it maybe to tall on the van to do that also.

Thanks for this post, much easier than a yahoo site.
_________________
--------------------------------------------------------
jfats808 wrote:
Most, some, few is not all. You can always learn something from everyone , even the fool.
Back to top
View user's profile Send private message Visit poster's website Facebook Gallery Classifieds Feedback
photogdave
Samba Member


Joined: April 05, 2004
Posts: 3032
Location: Vancouver Island, B.C.
photogdave is offline

PostPosted: Fri Jun 22, 2012 4:46 pm    Post subject: Reply with quote

What are you doing with the old top and tent?
_________________
89 Syncro GL Westfalia 2.1 WBX/WBXaustSS

My Westy Movies:
photogdave On Vimeo
photogdave On YouTube

Stop dead photo links! Post your photos to The Samba Gallery!
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
purplepeopleeater
Samba Member


Joined: July 23, 2005
Posts: 3117
Location: E. Washington
purplepeopleeater is offline

PostPosted: Fri Jun 22, 2012 4:50 pm    Post subject: Reply with quote

jrobewesty wrote:
For me it is not if but when! I defiantly will be getting one.

Do you think it will be easier the finish the top off the van and sitting upside down?

I might need to paint mine and think it maybe to tall on the van to do that also.

Thanks for this post, much easier than a yahoo site.


Yes this site is much easier and I'll be doing the bulk of the inside work with the top off, going to paint it tomorrow.

Insulation and liner will be done top off too, can you imagine working with a large chunk of material like headined and trying to negotiate it inside with the top in place? Eeek
Back to top
View user's profile Send private message Gallery Classifieds Feedback
purplepeopleeater
Samba Member


Joined: July 23, 2005
Posts: 3117
Location: E. Washington
purplepeopleeater is offline

PostPosted: Fri Jun 22, 2012 4:54 pm    Post subject: Reply with quote

photogdave wrote:
What are you doing with the old top and tent?
Sold the top ahead of time, going to be installing it sometime next week.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
JeffRobenolt
Samba Member


Joined: February 25, 2007
Posts: 1513
Location: Wisconsin
JeffRobenolt is offline

PostPosted: Fri Jun 22, 2012 6:07 pm    Post subject: Reply with quote

With a white van I figured you would just leave the top the way it is. OR does it need paint to seal it or something like that???

Thanks Jeff
_________________
--------------------------------------------------------
jfats808 wrote:
Most, some, few is not all. You can always learn something from everyone , even the fool.
Back to top
View user's profile Send private message Visit poster's website Facebook Gallery Classifieds Feedback
purplepeopleeater
Samba Member


Joined: July 23, 2005
Posts: 3117
Location: E. Washington
purplepeopleeater is offline

PostPosted: Fri Jun 22, 2012 6:10 pm    Post subject: Reply with quote

The top is fine as it is but it's more brilliant white and my van is more pastel colored, I want more finished looki... I'm planning on doing some graphics On the top.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
joetiger Premium Member
Samba Member


Joined: January 27, 2005
Posts: 5062
Location: denver
joetiger is offline

PostPosted: Sat Jun 23, 2012 10:15 am    Post subject: Reply with quote

purplepeopleeater wrote:
I'm planning on doing some graphics On the top.


Like in Cheech & Chongs Next Movie?

Image may have been reduced in size. Click image to view fullscreen.

_________________
Joe T.

'86 NAHT Vanagon GL Syncro/ supercharged ABA 2.0 "Pigpen"
'04 GTI 1.8T
'04 Golf R32

"get metaphysical with it. if it's simply a means to get to and from places, it will let you down. if it becomes your zen, it can't fail you." -dabaron

"Still, it's good to be afield."--VWagabond

Available Now! Vanagon to Louisiana--A Two-Lane Reckoning Through Past and Present

www.josephtrussell.com
Back to top
View user's profile Send private message Visit poster's website Instagram Gallery Classifieds Feedback
photogdave
Samba Member


Joined: April 05, 2004
Posts: 3032
Location: Vancouver Island, B.C.
photogdave is offline

PostPosted: Sat Jun 23, 2012 10:21 am    Post subject: Reply with quote

Maybe we should all post suggestions for the "finish" of Mike's top and the most popular vote gets the honors. Laughing

Image may have been reduced in size. Click image to view fullscreen.

_________________
89 Syncro GL Westfalia 2.1 WBX/WBXaustSS

My Westy Movies:
photogdave On Vimeo
photogdave On YouTube

Stop dead photo links! Post your photos to The Samba Gallery!
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
purplepeopleeater
Samba Member


Joined: July 23, 2005
Posts: 3117
Location: E. Washington
purplepeopleeater is offline

PostPosted: Sat Jun 23, 2012 10:30 am    Post subject: Reply with quote

I was thinking more along the lines of a black line down the side, not some acid induced painting, Smile
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Hodakaguy
Samba Member


Joined: April 25, 2012
Posts: 661
Location: Eastern WA
Hodakaguy is offline

PostPosted: Sat Jun 23, 2012 12:29 pm    Post subject: Reply with quote

purplepeopleeater wrote:
I was thinking more along the lines of a black line down the side, not some acid induced painting, Smile


I don't know... it might look good on YOUR rig lol.

Hodakaguy
Back to top
View user's profile Send private message Gallery Classifieds Feedback
insyncro
Banned


Joined: March 07, 2002
Posts: 15086
Location: New York
insyncro is offline

PostPosted: Sat Jun 23, 2012 8:25 pm    Post subject: Reply with quote

Curious to see how much your gas mileage drops with the new top.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Display posts from previous:
Reply to topic    Forum Index -> Vanagon All times are Mountain Standard Time/Pacific Daylight Savings Time
Page: 1, 2, 3, 4, 5, 6, 7, 8, 9  Next
Page 1 of 9


Jump to:
You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot vote in polls in this forum

About | Help! | Advertise | Donate | Premium Membership | Privacy/Terms of Use | Contact Us | Site Map
Copyright © 1996-2023, Everett Barnes. All Rights Reserved.
Not affiliated with or sponsored by Volkswagen of America | Forum powered by phpBB
Links to eBay or other vendor sites may be affiliate links where the site receives compensation.
