Number 9 Fuse Keeps Popping
Forum Index -> Bay Window Bus Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
LewisTheBus
Samba Member


Joined: June 10, 2017
Posts: 17

LewisTheBus is offline

PostPosted: Sat Aug 25, 2018 9:51 am    Post subject: Number 9 Fuse Keeps Popping Reply with quote

I finally was able to get my bus moving and driving after ages of it sitting in garage. After a few short trips I had stopped and pulled the hand brake when
suddenly the number 9 fuse popped. I was no longer able to start the car, as it seems its integral to the ignition switch. I have checked all connections and
removed anything I have added since I once had it running to no avail. The fuses I replace continue to pop. Any suggestions?
_________________
1977 2.0L FI Westy "Lewis"
Back to top
View user's profile Send private message Classifieds Feedback
SGKent Premium Member
Samba Member


Joined: October 30, 2007
Posts: 28820
Location: Nor Cal
SGKent is offline

PostPosted: Sat Aug 25, 2018 10:02 am    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

what does the owners's manual say is on that fuse?

https://www.thesamba.com/vw/archives/manuals/77bus/77II-40.jpg
_________________
*You can do it right the first time, or do it over, the choice is yours. It is a free country. As to brakes, steering, tires, axles etc. - you may only get one chance at doing those right.

* VW Buses and VW cars share many of the same systems but if you haven't owned a bus and maintained it for awhile, you really don't know how different it is.

Bus Engine Cooling Issues? https://kentcomputer.com/77VW/BusEngineCooling.pdf
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
busdaddy
Samba Member


Joined: February 12, 2004
Posts: 40282
Location: Surrey B.C. Canada, Land of the giant flying moose!
busdaddy is offline

PostPosted: Sat Aug 25, 2018 10:11 am    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

LewisTheBus wrote:
.......pulled the hand brake when suddenly the number 9 fuse popped....

There's a clue there, maybe look up under the dash and see what gets pinched?
_________________
Rust NEVER sleeps and stock never goes out of style.

Wanted, OG paint 1971 Niagara blue decklid.

Stop dead photo links! Post your photos to The Samba Gallery!
Back to top
View user's profile Send private message Gallery Classifieds Feedback
LewisTheBus
Samba Member


Joined: June 10, 2017
Posts: 17

LewisTheBus is offline

PostPosted: Sat Aug 25, 2018 10:23 am    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

The owner's manual states it as "accessory" which is where my conundrum started and was also the reason I had wired some other things onto that circuit, but even when removed it doesn't change. My gauge cluster is not currently secured properly and I heard the fuel gauge can short out on the car, could that be the culprit?it still seems odd that the "accessory" fuse controls ignition
_________________
1977 2.0L FI Westy "Lewis"
Back to top
View user's profile Send private message Classifieds Feedback
telford dorr
Samba Member


Joined: March 11, 2009
Posts: 2434
Location: San Diego (Encinitas)
telford dorr is offline

PostPosted: Sat Aug 25, 2018 11:05 am    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

The starting and ignition circuits are unfused, which means that the engine should start with all fuses removed. This means something is bogus in your wiring, and definitely non-stock. As such, you'll just have to track it down the hard way - inspect and trace everything. Download the schematic from Technical and get it printed (8.5 x 14) and laminated at Kinkos.

To make it easier, build one of these:
Image may have been reduced in size. Click image to view fullscreen.

You'll need a headlight bulb (the Bus has two), a generic bulb socket, some wire and a couple of clips (from your nearby FLAPS). Remove the blown fuse, and clip this across the fuse contacts. The bulb will light up brightly until you find the short, at which point it should dim or go out completely. Disconnect and insulate the wires at the #15 (+) terminal of the coil to keep from cooking it while you conduct your search for the short.

Good luck.
_________________
'71 panel, now with FI

'Experience' is the ability to recognize a mistake when you're making it again - Franklin P. Jones

To steal ideas from one person is plagiarism; to steal from many is research - Steven Wright

In theory, theory works in practice; in practice, it doesn't - William T. Harbaugh

All models are wrong; some are useful - George Box

More VW electrical at http://flowcon.us/td/ (available 9am to 9pm PST)
Back to top
View user's profile Send private message Gallery Classifieds Feedback
LewisTheBus
Samba Member


Joined: June 10, 2017
Posts: 17

LewisTheBus is offline

PostPosted: Sat Aug 25, 2018 2:02 pm    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

Solved! Just a poor connection at the ignition switch, thanks for the help guys.
_________________
1977 2.0L FI Westy "Lewis"
Back to top
View user's profile Send private message Classifieds Feedback
telford dorr
Samba Member


Joined: March 11, 2009
Posts: 2434
Location: San Diego (Encinitas)
telford dorr is offline

PostPosted: Sat Aug 25, 2018 3:11 pm    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

Doesn't explain why fuse 9 blew...
_________________
'71 panel, now with FI

'Experience' is the ability to recognize a mistake when you're making it again - Franklin P. Jones

To steal ideas from one person is plagiarism; to steal from many is research - Steven Wright

In theory, theory works in practice; in practice, it doesn't - William T. Harbaugh

All models are wrong; some are useful - George Box

More VW electrical at http://flowcon.us/td/ (available 9am to 9pm PST)
Back to top
View user's profile Send private message Gallery Classifieds Feedback
mark d
Samba Member


Joined: February 06, 2013
Posts: 167
Location: Costa Rica
mark d is offline

PostPosted: Sat Aug 25, 2018 4:41 pm    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

hey telford, that's a great trick. thks for passing on
_________________
1972ish westfalia

"what good are tractors without violins ?" jose figueres
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
LewisTheBus
Samba Member


Joined: June 10, 2017
Posts: 17

LewisTheBus is offline

PostPosted: Sun Aug 26, 2018 12:15 pm    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

the only thing connected to the #9 fuse is a double connector with 2 red wires, one going to the headlight switch and one going to the ignition switch, when I fixed the connection the fuse stopped popping, do you think this is only temporary?
_________________
1977 2.0L FI Westy "Lewis"
Back to top
View user's profile Send private message Classifieds Feedback
vwwestyman
Samba Member


Joined: April 24, 2004
Posts: 3580
Location: Manhattan, Kansas, USA
vwwestyman is offline

PostPosted: Mon Aug 27, 2018 5:29 am    Post subject: Re: Number 9 Fuse Keeps Popping Reply with quote

Sounds like the previous owner did something funky! Maybe an attempt at a theft prevention device.
_________________
Dave Cook
Stuartzickefoose wrote:
I'm gonna punch vwwestyman then shake his hand when I meet him.

notchboy wrote:
Ill just punch you in the face. Wink

1978 Champagne Edition Westy, repowered to '97 Jetta TDI
1973 Wild Westerner
My Thing
www.thefosterdads.com
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
