 Posted: Wed Feb 11, 2004 10:37 am Post subject: Splash pan and brackets colour? |
 |
|
Is the splash pan to be bumper colour (silver beige) or to be grey / black or body colour? As for the brackets I though about powder coating them - is there a RAL colour or similar code for this?
Thanks,
Al
Admin note:
Here's a thread on rear ribbed / pressed bumper brackets and hardware:
https://www.thesamba.com/vw/forum/viewtopic.php?t=690663 |
|
| Back to top |
|
 |
crofty
Judas of the North
Joined: August 09, 2000
Posts: 19844
Location: Land of Whine and Phonies
|
| Posted: Wed Feb 11, 2004 10:38 am Post subject: |
|
|
All the pans I have seen are black, and most of the brackets too.
_________________
Your Vanagon sucks, Stop waving at me.
| HamburgerBrad wrote: |
I slept on crofty's tent once. I passed out drunk from two bottles of Everett's brother's wine. |
|
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Wed Feb 11, 2004 10:51 am Post subject: |
|
|
Im sure this varied back in the day from day to day but...On 58 and earlier models.....the bumper was painted with the brackets attached the lower color of the body. The splash pans were black and on standards and deluxes the tops were painted to match the lower color of the body. On Kombis and trucks they pans were left all black.
I believe for post 59 models the pans were black and the brackets were gray. |
|
| Back to top |
|
|
Stanagon
Samba Member
Joined: July 11, 2003
Posts: 4195
Location: Boston, MA
|
| Posted: Wed Feb 11, 2004 10:52 am Post subject: |
|
|
| I bought some used splash pans that had (looked like) original black paint on them. I cleaned 'em up and repainted them and my new (Wolfsburg West) bumper brackets with a flat black. The originals may have been more of a semi-gloss black but I had some flat black on hand so I used that. |
|
| Back to top |
|
|
campingbox
Samba Member
Joined: November 14, 2000
Posts: 10252
Location: Petaluma, CA
|
| Posted: Wed Feb 11, 2004 11:20 am Post subject: |
|
|
| I think the paint originally used for the pans was the same paint used for the engine tin, front beam, etc, etc. |
|
| Back to top |
|
|
DanM
Samba Member
Joined: June 07, 2002
Posts: 1376
Location: Falls Church, VA
|
| Posted: Wed Feb 11, 2004 11:38 am Post subject: |
|
|
| campingbox wrote: |
I believe for post 59 models the pans were black and the brackets were gray. |
i'll agree with that. my "march '60" has black pans and had o.g. gray primer brackets that needed replacement.
_________________
drive it. break it. fix it. repeat. |
|
| Back to top |
|
|
EverettB
Administrator
Joined: April 11, 2000
Posts: 71619
Location: Phoenix 602
|
| Posted: Wed Feb 11, 2004 11:53 am Post subject: |
|
|
Ribbed bumpers:
All the NOS splash pans I have seen are black.
The NOS brackets are grey.
This would make me guess that they painted the brackets but not the pans, although I've seen a bunch of splash pans with original paint overspray all over them so i'll go with campingbox's response.
I used to have some original '57 rear brackets, they were green.
_________________
How to Post Photos
Everett Barnes - [email protected] | My wanted ads
"Water is the only drink for a wise man" | "Communication prevents complaints"
Stop dead photo links! Post your photos to The Samba Gallery! |
|
| Back to top |
|
|
Bart
Samba Member
Joined: March 18, 2002
Posts: 2516
Location: Chapel Hill, TN
|
| Posted: Wed Feb 11, 2004 11:54 am Post subject: |
|
|
my '66 splash pans were og grey before I repainted them to match the bumpers.
EDIT: Although that may have been overspray.....
_________________
http://www.sundial-camper.com |
|
| Back to top |
|
|
spookymulder
Samba Proletariat
Joined: January 02, 2004
Posts: 3298
Location: I'm either at 95608, 97537 or 94708 only my CPA knows for sure
|
| Posted: Wed Feb 11, 2004 1:01 pm Post subject: |
|
|
| I have 4 pair of NOS still in the factory bag 59-67 splash pans and the are all identical, semigloss black on top and grey on the bottom. |
|
| Back to top |
|
|
DB
Samba Member
Joined: December 09, 2002
Posts: 95
|
| Posted: Wed Feb 11, 2004 4:42 pm Post subject: |
|
|
Hi Everyone,
If all this good info is correct, I would have really screwed up painting my splash pans and bumper brackets -- good thing I haven't painted them yet! Does anyone have any images from original paint buses (hopefully from a deluxe) that can confirm this information. I have a '60 deluxe in sealing wax red and beige gray and just want to get it (retentive) I mean right. Thanks for any help! I learn something new everyday on this site, and twice on Sundays.
Regards, DB  |
|
| Back to top |
|
|
obus
Samba Member
Joined: March 08, 2001
Posts: 11674
Location: just off Garden State Parkway Exit 81
|
|
| Back to top |
|
|
npbusguy
Samba Member
Joined: February 08, 2006
Posts: 1661
Location: Budapest, Hungary
|
| Posted: Thu Mar 12, 2009 6:04 am Post subject: |
|
|
| campingbox wrote: |
Im sure this varied back in the day from day to day but...On 58 and earlier models.....the bumper was painted with the brackets attached the lower color of the body. The splash pans were black and on standards and deluxes the tops were painted to match the lower color of the body. On Kombis and trucks they pans were left all black.
I believe for post 59 models the pans were black and the brackets were gray. |
It is true that the 58 and earlier bumper brackets (front and rear) were painted while attached to the bumper, so your bumper bolts would be painted too, but I don't know about 59 and later buses.
In my research, the splash pans on 57-58 era buses were painted black as seen in these photos of a very original low mile 57 standard bus.
My original splash pans on my 58 deluxe were also black before restoration and will be black when the bus is "finished".
There is a thread in the barndoor forums about splash pan color and it shows that they may have been painted the color of the lower body. Perhaps this is some kind of "Wolfsburg" feature. |
|
| Back to top |
|
|
EverettB
Administrator
Joined: April 11, 2000
Posts: 71619
Location: Phoenix 602
|
| Posted: Thu Mar 12, 2009 9:25 am Post subject: |
|
|
| obus wrote: |
so on my July 1959 Standard, i should paint the top semi gloss black and the underside gray?
Sounds like that is right? |
That doesn't sound right, all of my original 59-up splash pans are 100% black.
I do have an NOS pair with stickers, they are all the regular grey primer.
_________________
How to Post Photos
Everett Barnes - [email protected] | My wanted ads
"Water is the only drink for a wise man" | "Communication prevents complaints"
Stop dead photo links! Post your photos to The Samba Gallery! |
|
| Back to top |
|
|
obus
Samba Member
Joined: March 08, 2001
Posts: 11674
Location: just off Garden State Parkway Exit 81
|
|
| Back to top |
|
|
EverettB
Administrator
Joined: April 11, 2000
Posts: 71619
Location: Phoenix 602
|
|
| Back to top |
|
|
obus
Samba Member
Joined: March 08, 2001
Posts: 11674
Location: just off Garden State Parkway Exit 81
|
|
| Back to top |
|
|
EverettB
Administrator
Joined: April 11, 2000
Posts: 71619
Location: Phoenix 602
|
|
| Back to top |
|
|
mysamba
Samba Member
Joined: March 30, 2008
Posts: 75
Location: California
|
| Posted: Thu Mar 12, 2009 5:12 pm Post subject: |
|
|
I'm no expert,, but it would make sense to me that the NOS replacement parts from VW would be in primer (gray) and needed to be painted by the body shop if used as a replacements.
Possibly the gray on the bottom and the black on the top were a replacement at some time? and just painted on the top (Show Side) by the paint shop?
The pans installed from the factory probably were painted at the factory black top and bottom for production.
Just my guess on this.
My pans are solid rust like color with no evidence of any paint at all, top or bottom....  |
|
| Back to top |
|
|
gsmueller58
Samba Member
Joined: September 26, 2006
Posts: 18
Location: Argentina
|
| Posted: Tue Jul 28, 2009 3:01 pm Post subject: Splash Pans Color - License plate holes on bumpers |
|
|
Hi Guys,
I've been reading some posts on this issue but it's still not clear for me what the right color is. Mine is a November 62 Standard Microbus (Turkis /Bluewhite) in pretty original condition, except for the exterior, which has sometime been repainted. Should the splash pans be painted completely black or should the upper face match the body color?
Another quick question. Do the bumpers came originally with holes for the license plate? Take into account that Argentina version is like the european, no guards no overrider bow.
Thanks a lot for your help and best regards from Argentina.
Gabriel |
|
| Back to top |
|
|
Dave24
Samba Hack Purist
Joined: April 14, 2004
Posts: 7442
Location: Hablamos Ingles, So. Cal.
|
| Posted: Tue Jul 28, 2009 3:08 pm Post subject: Re: Splash Pans Color - License plate holes on bumpers |
|
|
| gsmueller58 wrote: |
Hi Guys,
I've been reading some posts on this issue but it's still not clear for me what the right color is. Mine is a November 62 Standard Microbus (Turkis /Bluewhite) in pretty original condition, except for the exterior, which has sometime been repainted. Should the splash pans be painted completely black or should the upper face match the body color?
Another quick question. Do the bumpers came originally with holes for the license plate? Take into account that Argentina version is like the european, no guards no overrider bow.
Thanks a lot for your help and best regards from Argentina.
Gabriel |
Black. Can't help you on the lic. plt. holes. |
|
