| Author |
Message |
Dwc1984
Samba Member
Joined: February 15, 2017
Posts: 51
Location: Monroe, mi
|
 Posted: Sun May 14, 2017 3:14 pm Post subject: Ignition |
 |
|
| Just wondering what everyone is running for an ignition system? Stock with points or an electronic system thanks in advance |
|
| Back to top |
|
 |
sawed off
Samba Member
Joined: September 15, 2016
Posts: 428
Location: Idaho
|
| Posted: Sun May 14, 2017 4:23 pm Post subject: Re: Ignition |
|
|
| Heard a lot of pros and cons for both. Seems many carry spare dist. for road side failure since its so easy to swap dist. on these things rather than repair on roadside. |
|
| Back to top |
|
|
Krochus
Samba Member
Joined: January 01, 2017
Posts: 892
Location: NW Arkansas
|
| Posted: Sun May 14, 2017 4:45 pm Post subject: Re: Ignition |
|
|
| I run a VW10 and have been completely satisfied with it over the past few thousand miles. It's a departure from Bosch based distrubitors in that it's a Nippon Denso adaptation to VW use. |
|
| Back to top |
|
|
Dwc1984
Samba Member
Joined: February 15, 2017
Posts: 51
Location: Monroe, mi
|
| Posted: Sun May 14, 2017 7:19 pm Post subject: Re: Ignition |
|
|
| Would a msd setup be 2 crazy for a stock vw motor? |
|
| Back to top |
|
|
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79415
Location: Sneaking up behind you
|
| Posted: Sun May 14, 2017 7:28 pm Post subject: Re: Ignition |
|
|
| Krochus wrote: |
| I run a VW10 and have been completely satisfied with it over the past few thousand miles. It's a departure from Bosch based distrubitors in that it's a Nippon Denso adaptation to VW use. |
A VW10 is a Richporter copy of the 009. You're lucky since many have reported many problems.
Everyone's ignition will be different depending on the engine.
We have a dedicated topic on points vs electronic if you're interested.
https://www.thesamba.com/vw/forum/viewtopic.php?t=281144
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
Glenn
Mr. 010
Joined: December 25, 2001
Posts: 79415
Location: Sneaking up behind you
|
| Posted: Sun May 14, 2017 7:28 pm Post subject: Re: Ignition |
|
|
| Dwc1984 wrote: |
| Would a msd setup be 2 crazy for a stock vw motor? |
Yes....
For a stock engine with a stock carb, you're best bet is the stock distributor.
_________________
Glenn
74 Beetle Specs | 74 Beetle Restoration | 2180cc Engine
"You may not get what you pay for, but you always pay for what you get"
Member #1009
#BlueSquare
עַם יִשְׂרָאֵל חַי |
|
| Back to top |
|
|
Krochus
Samba Member
Joined: January 01, 2017
Posts: 892
Location: NW Arkansas
|
| Posted: Sun May 14, 2017 7:35 pm Post subject: Re: Ignition |
|
|
| Glenn wrote: |
| Krochus wrote: |
| I run a VW10 and have been completely satisfied with it over the past few thousand miles. It's a departure from Bosch based distrubitors in that it's a Nippon Denso adaptation to VW use. |
A VW10 is a Richporter copy of the 009. You're lucky since many have reported many problems.
Everyone's ignition will be different depending on the engine.
We have a dedicated topic on points vs electronic if you're interested.
https://www.thesamba.com/vw/forum/viewtopic.php?t=281144 |
I have both units. The VW10 is a completely different distrubitor platform. Like I said it's based on mid 80's Japanese units. It is in no way related to or shares any parts compatibility with a Bosch or an electronically converted Bosch. It's literally as different from a Bosch as a GM HEI is. For the $120 you pay for it with a lifetime warranty (if purchased through a major parts chain) there's basically zero risk to owing one. If you are nervous save the old spark scattering 009 for a emergency roadside repair to get home.
|
|
| Back to top |
|
|
Dwc1984
Samba Member
Joined: February 15, 2017
Posts: 51
Location: Monroe, mi
|
| Posted: Mon May 15, 2017 2:37 am Post subject: Re: Ignition |
|
|
| It does have a Weber carb on it |
|
| Back to top |
|
|
modok
Samba Member
Joined: October 30, 2009
Posts: 27652
Location: Colorado Springs
|
| Posted: Mon May 15, 2017 3:17 am Post subject: Re: Ignition |
|
|
You can run just about anything, if you want. all kinds. I've got a old bosche 009, altered curve, goes to msd timing computer, then TFI module, then old canister coil, japan 1975! Never will die.
IMO the timing computer works better with inductive pickup like the vw 10 "denso" type mentioned above, actually, but it works OK with points, just ok, not great. All the MSD stuff says it works with points, still says that, but they are mostly ignoring it these days. They are leaving out some of the critical parts that make that work. WHo uses points? 5% of their custoemrs, so they get the shaft.
Canister coils....a lot of crap out there, chinese, and crap distributors too. Your better off stick with the old ones than a new copy.
New, try CB magnaspark. it's new, but it's new tech, should work. Rather than trying to duplicate the old stuff. Your never going to, back then it MATTERED, now it does not.
Most of my cars came WITH distributors, that worked fine, so why buy new ones?
But I hear there is short supply these days, from some folks.
Lot of folks run CDI, I did for awhile, didn't prefer it. It's hard on parts. You need good wires and solid rotor.
Most CDi boxes.... it'll eat the stock ones, quick.
MSD is not what it used to be. Don't drop too much money on them, nor petronix. Don't like the direction those companies are going......forging ahead with NEW tech, but hadn't yet perfected the old pruducts:roll: Like a kid with ADD |
|
| Back to top |
|
|
madmike
Samba Member
Joined: July 11, 2005
Posts: 5300
Location: Atlanta,Michigan
|
| Posted: Mon May 15, 2017 3:32 am Post subject: Re: Ignition |
|
|
Hey Dwc, Going to Yipsi?
I'll be in the swap area , I have a complete MSD set up in my 'stash'  ,Madmike
_________________
'Black Ice'Drag Buggy 'Turbo'
Rail Buggy 1915 turbo
76 Drag/Street bug 2180cc 'Turbo' 11:85 @113 mph"If I go any faster I'll burn up the Hamster" ,gets 28 mpg. also 10/09/22 11.90 @115 mph
"If I'm ever on Life Support,UNPLUG Me, Then Plug me back In see if that Works" |
|
| Back to top |
|
|
Dale M.
Samba Member
Joined: April 12, 2006
Posts: 20798
Location: Just a tiny bit west of Yosemite Valley
|
| Posted: Mon May 15, 2017 8:54 am Post subject: Re: Ignition |
|
|
009 Body with Compufire module, and Bosch blue coil... Good to 7000 RPM.... Been running this way for 15 years....
dale
_________________
“Fear The Government That Wants To Take Your Guns"
"Kellison Sand Piper Roadster" For Street & Show.
"Joe Pody Sandrover" Buggy with 2180 for Autocross (Sold)
============================================================
All suggestions and advice are purely my own opinion. You are free to ignore them if you wish ...
Last edited by Dale M. on Mon May 15, 2017 2:01 pm; edited 1 time in total |
|
| Back to top |
|
|
Lingwendil
Samba Member
Joined: February 25, 2009
Posts: 3999
Location: Antioch, California, a block from the hood
|
| Posted: Mon May 15, 2017 11:36 am Post subject: Re: Ignition |
|
|
After getting fed up with various points replacement module setups, I am a die-hard fan of points. I use a cast-iron (more accurate than aluminum) VJU4BR8 SVDA, with points, a Bosch blue coil (for now, my MSD was leaking oil more than I cared for) and a Ford TFI module. I use an Eichlin brand rotor from Napa auto parts, since it is only 50 ohms, rather than 5000 ohms, and due to quality issues with Bosch. Taylor spiro-pro wires from CB Performance, and NGK BP6HS plugs. I recently picked up a vintage Tiger 500 CDI system to try out.
It works absolutely wonderful with a stock setup on a 1776, and the vacuum can is adjustable (to an extent) to work with many dual carb setups rather well.
_________________
73 super beetle thread http://www.thesamba.com/vw/forum/viewtopic.php?t=649622 Back on the Road!
Modify your Kadrons for SVDA http://www.thesamba.com/vw/forum/viewtopic.php?p=8115884#8115884
Cast iron VJU4BR8 SVDA reference thread- https://www.thesamba.com/vw/forum/viewtopic.php?t=...mp;start=0
Need replacement filters for original Kadron aircleaners? WIX #42087 is a perfect fit, as is Napa Gold #2087! |
|
| Back to top |
|
|
mark tucker
Samba Member
Joined: April 08, 2009
Posts: 23950
Location: SHALIMAR ,FLORIDA
|
| Posted: Mon May 15, 2017 12:19 pm Post subject: Re: Ignition |
|
|
I just run the good ole 09 with pet electronic thingy inside of it and platinum sparking bolts. Im not sure about the people that carry a extra dist with them....do they carry a extra everything too?? who drives it? do they toe it behind them or push it? I think buss ticket might be cheeper or.... a good shop that knows how to properly fix the car so it's reliable. on a nother note my car is my daily driver and has been for....15 years...although it is now a fair weather car...it has a wiper blade that has a slight shread comming offit...dam crap we get for wipers these days, it's only about 6 months old...Ill have to dig out the old ones and put them back on. when i get a round tuit.  |
|
| Back to top |
|
|
mondshine
Samba Member
Joined: October 27, 2006
Posts: 2812
Location: The World's Motor Capital
|
| Posted: Mon May 15, 2017 1:02 pm Post subject: Re: Ignition |
|
|
| Lingwendil wrote: |
After getting fed up with various points replacement module setups, I am a die-hard fan of points. I use a cast-iron (more accurate than aluminum) VJU4BR8 SVDA, with points.
It works absolutely wonderful with a stock setup on a 1776, and the vacuum can is adjustable (to an extent) to work with many dual carb setups rather well. |
I was in love with my 019 until I tried the VJU4BR8; it's basically an 019 with adjustable vacuum advance.
As Marlene Dietrich sang about falling in love again..."I can't help it"
|
|
| Back to top |
|
|
tasb
The Distributor Distributor
Joined: April 27, 2002
Posts: 6722
Location: Pentwater, Michigan
|
| Posted: Mon May 15, 2017 2:00 pm Post subject: Re: Ignition |
|
|
Ah, an innovative use for the ubiquitous 36 hp vacuum advance distributor, I like it!
_________________
Roads Scholar
1957 Kombi low mileage 36 hp governor equipped M 178 Slow Drag Winner 2014, 2015, 2018
1965 hardtop Deluxe Microbus owned since 1990 M 620 factory 12 v 1500cc
1961 (October)Single Cab- Road Trip Workhorse
Member# 2059 |
|
| Back to top |
|
|
j-dub
Samba Member
Joined: November 09, 2003
Posts: 870
Location: Phoenix, AZ
|
| Posted: Mon May 15, 2017 7:01 pm Post subject: Re: Ignition |
|
|
Are we having a VJU4BR8 fest?
_________________
1957 Oval rag
"POLICE STATION TOILET STOLEN ... Cops have nothing to go on." |
|
| Back to top |
|
|
74 Thing
Samba Member
Joined: September 02, 2004
Posts: 7630
|
| Posted: Mon May 15, 2017 9:52 pm Post subject: Re: Ignition |
|
|
That is one beautiful looking oval. Any more photos?
How do you like that Jacobs ignition you have in the engine bay? I was running a Jacobs unit with their coil, but I kept burning up the contacts in the stock size Bosch distributor cap and wearing out the gap fast in the spark plugs so I removed it.
Previoulsy I ran the Tiger CDI box for years, but that finally gave up.
I have an old Bosch Blue coil that I am running now with an aluminum SVDA that I tweaked the stops and the spring perches so that the timing comes in faster and is limited. It works good on my dual dells with the anti pulse valve.
I have one of the cast iron 36hp SVDAs all rebuilt on the bench, but I have not installed it yet. |
|
| Back to top |
|
|
Lingwendil
Samba Member
Joined: February 25, 2009
Posts: 3999
Location: Antioch, California, a block from the hood
|
| Posted: Mon May 15, 2017 11:51 pm Post subject: Re: Ignition |
|
|
| tasb wrote: |
| Ah, an innovative use for the ubiquitous 36 hp vacuum advance distributor, I like it! |
A tip for anyone looking for one, the 0231 115 040 is the same thing, just with a different set of numbers, and a slightly different points plate, that lets you use the later style non-dogleg points. The great thing about the 040 is that the restoration guys turn their nose up at them, so they are cheap! My two VJU4BR8 are actually 040's, and they were each only 35 shipped, and just needed a clean-up, coat of paint, and re-lube. Both came with new-ish points, and the original condensor on one still works just fine!
For anybody who cares, the Eichlin points and rotor from Napa auto parts fit and work well, and the points are nicer than the current Bosch sets-
Rotor (50 ohm, Bosch is 5000 ohm)-
https://www.napaonline.com/en/p/ECHEP278
Points-
https://www.napaonline.com/en/p/ECHCS301
The generic cap you find around (I think it's made by BWD, the one from CIP1 and my local O'Reilly auto parts are identical, down to the mold flashing lines) works, but I like the ones from Wolfsburg west the best. If anybody has a link to a cheap Bremi I'd like to try one. The newer Bosch ones don't impress me at all.
They are a fun little sleeper distributor, that's for sure!
_________________
73 super beetle thread http://www.thesamba.com/vw/forum/viewtopic.php?t=649622 Back on the Road!
Modify your Kadrons for SVDA http://www.thesamba.com/vw/forum/viewtopic.php?p=8115884#8115884
Cast iron VJU4BR8 SVDA reference thread- https://www.thesamba.com/vw/forum/viewtopic.php?t=...mp;start=0
Need replacement filters for original Kadron aircleaners? WIX #42087 is a perfect fit, as is Napa Gold #2087! |
|
| Back to top |
|
|
YDBD
Samba Member
Joined: February 25, 2017
Posts: 924
Location: Bavaria, Germany
|
| Posted: Tue May 16, 2017 1:32 am Post subject: Re: Ignition |
|
|
009, points, Bosch Blue Coil..since '72...
_________________
'56 pan Dune Buggy since '69
don't live in the past...but when I did:
'67 bug
'64 baja
'60 dune buggy
'73 Personenkraftwagen Type 182 "Thing" |
|
| Back to top |
|
|
madmike
Samba Member
Joined: July 11, 2005
Posts: 5300
Location: Atlanta,Michigan
|
| Posted: Tue May 16, 2017 7:07 am Post subject: Re: Ignition |
|
|
FYI, I have an old 010 too
_________________
'Black Ice'Drag Buggy 'Turbo'
Rail Buggy 1915 turbo
76 Drag/Street bug 2180cc 'Turbo' 11:85 @113 mph"If I go any faster I'll burn up the Hamster" ,gets 28 mpg. also 10/09/22 11.90 @115 mph
"If I'm ever on Life Support,UNPLUG Me, Then Plug me back In see if that Works" |
|
| Back to top |
|
|
|
