PostPosted: Sat Mar 09, 2019 1:51 am    Post subject: Carb electrical issues Reply with quote

I've got a 1600 with a 30PICT-1 carburettor fitted to my '59 panelvan. It's an Australian made Solex if that makes a difference.

I was chasing a sticky throttle issue which I've sorted, but while checking that out I noticed that my bus wouldn't idle without the accelerator cable attached. It appears that the carburettor is grounding through the accelerator cable. Presumably it's not running without the accelerator cable going to ground as the idle shutoff solenoid won't then work normally. If I run a jump wire from the carburettor to the body, it will idle fine.

Is that behaviour normal or is there something going on with my carb wiring?

Image may have been reduced in size. Click image to view fullscreen.



Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
anthracitedub
Samba Member


Joined: June 20, 2007
Posts: 3241
Location: Michigan
anthracitedub is offline

PostPosted: Sat Mar 09, 2019 5:39 am    Post subject: Re: Carb electrical issues Reply with quote

Interesting.... seems the carb is completely isolated from ground. That pilot valve needs + and - to work. Might try cleaning the area where the mounting stud/nut tighten down on the flange to see if it can ground through there.

Makes me wonder about how well your engine/trans ground strap is too. At least inspect/clean that as well.

Another thing I noticed, the terminal for your pilot solenoid is right on the alternator body... I know you have the insulated connector there, but that doesnít sit well with me. If it wears through, youíll have a direct short. Maybe a thin spacer for the carb to give it a little room? Maybe itís perspective, one pic looks really close.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Krochus
Samba Member


Joined: January 01, 2017
Posts: 892
Location: NW Arkansas
Krochus is offline

PostPosted: Sat Mar 09, 2019 6:05 am    Post subject: Re: Carb electrical issues Reply with quote

You need a carb spacer to run this combo with an alternator. Your accelerator pump is probably only partially operational as well due to it hitting the alternator

Then the choke and the idle fuel cutoff solenoid both need to see 12v+ switched with the ignition
_________________
1970 Turbo Baja Bug Turbaja 2165 t3/t4 Speeduino sequential EFI LS3 coil on plug ignition

1965 Chevy c30, Microsquirt turbo aluminum 5.3/nv4500
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Dale M.
Samba Member


Joined: April 12, 2006
Posts: 20379
Location: Just a tiny bit west of Yosemite Valley
Dale M. is offline

PostPosted: Sat Mar 09, 2019 8:05 am    Post subject: Re: Carb electrical issues Reply with quote

Ditto on carb spacer and yes to 12V DC to both choke stove and solenoid, usually supplied off positive (+) terminal of ignition coil....

Dale
_________________
ďFear The Government That Wants To Take Your Guns" - Thomas Jefferson.

"Kellison Sand Piper Roadster" For Street & Show.
"Joe Pody Sandrover" Buggy with 2180 for Autocross (Sold)
============================================================
All suggestions and advice are purely my own opinion. You are free to ignore them if you wish ...
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Cusser
Samba Member


Joined: October 02, 2006
Posts: 31362
Location: Hot Arizona
Cusser is offline

PostPosted: Sat Mar 09, 2019 8:50 am    Post subject: Re: Carb electrical issues Reply with quote

All of the above. And it would be OK to run a ground wire from a carb screw up on top to engine ground; or even to body ground as long as you allow slack to allow for engine "movement".
_________________
1970 VW (owned since 1972) and 1971 VW Convertible (owned since 1976), second owner of each. The '71 now has the 1835 engine, swapped from the '70. Second owner of each. 1988 Mazda B2200 truck, 1998 Frontier, 2014 Yukon, 2004 Frontier King Cab. All manual transmission except for the Yukon. http://www.thesamba.com/vw/forum/album_page.php?pic_id=335294 http://www.thesamba.com/vw/forum/album_page.php?pic_id=335297
Back to top
View user's profile Send private message Gallery Classifieds Feedback
FeelthySanchez
Samba Member


Joined: February 03, 2011
Posts: 1349
Location: Now is that a real poncho, or a Sears poncho?
FeelthySanchez is offline

PostPosted: Sat Mar 09, 2019 9:27 am    Post subject: Re: Carb electrical issues Reply with quote

'67 bus had a tall "governor" under the carb, IIRC. No luck finding a pic of one, but it might function in a pinch.
You could also try a spacer similar to this, which is actually an adapter:

Image may have been reduced in size. Click image to view fullscreen.


Also check for a short right where I've circled in red, it appears to be in direct contact per both pics above:

Image may have been reduced in size. Click image to view fullscreen.

_________________
modok wrote:
I would like if you had enough clue to communicate what you are doing.
Ryan Tucker wrote:
Enough clue..Whats that mean?
OldIronSpine wrote:
I'm not sure how compression works.
Turbos don't produce torque, they produce HP. Instead of torque.
The real problem with NA engines is you don't hear the nice whine of the turbo as it spools up.
Before I commit, I'm going to do more research because I don't really know what piston rings are.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
mikedjames
Samba Member


Joined: July 02, 2012
Posts: 2739
Location: Hamble, Hampshire, UK
mikedjames is offline

PostPosted: Sat Mar 09, 2019 1:36 pm    Post subject: Re: Carb electrical issues Reply with quote

You realise the sticking throttle spindle will not have been helped by having an electric current flow from the carb body to the spindle and then to the throttle cable.
It will be producing arcs which melt the metal and either erode it or cause friction.. check the spindle bushings for wear.
_________________
Ancient vehicles and vessels

1974 VW T2 : Devon Eurovette camper with 1641 DP T1 engine, Progressive carb, full flow oil cooler, EDIS crank timed ignition.
Engine 1: 40k miles (rocker shaft clip fell off), Engine 2: 30k miles (rebuild, dropped valve). Engine 3: a JK Preservation Parts "new" engine, aluminium case: 26k miles: new top end.
Gearbox rebuild 2021 by Bears.

1979 Westerly GK24 24 foot racer/cruiser yacht Forethought of Gosport.
1973 wooden Pacer sailing dinghy
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
WOFTAM
Samba Member


Joined: February 03, 2018
Posts: 8
Location: Sydney, Australia
WOFTAM is offline

PostPosted: Sat Mar 09, 2019 3:59 pm    Post subject: Re: Carb electrical issues Reply with quote

Thanks for the tips.

The wire to the shutoff solenoid is well clear of the alternator body. I double checked and itís the perspective of the photo. The accelerator pump is also clear of the alternator. It operates away from the alternator.

Image may have been reduced in size. Click image to view fullscreen.


Still doesnít explain why itís grounding through the accelerator cable... I thought it would have gone to ground through the manifold and engine.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
earthquake
Samba Member


Joined: January 10, 2008
Posts: 3984
Location: SANDY VALLEY, NEVADA
earthquake is offline

PostPosted: Sat Mar 09, 2019 7:57 pm    Post subject: Re: Carb electrical issues Reply with quote

Do you have a ground strap to your transaxle? rubber mounts on trans may be isolate ground from chassis.

Casey
_________________
74 CLASS 11 LOOK-A-LIKE
69 DUNE BUGGY
79 INTERNATIONAL SCOUT II
05 SCION XB SERIES RELEASE 2[#437]
95 Chevy C3500 dually
98 Ford E150
Link to Kelly J. Nolte 3/20/53 - 11/6/08
https://time-zonelabs.blogspot.com/p/about-kelly.html
DEATH TO CHINGERS!
[From a military recruitment poster in the novel "The Stainless Steel Rat" By Harry Harrison]
Back to top
View user's profile Send private message Gallery Classifieds Feedback
WOFTAM
Samba Member


Joined: February 03, 2018
Posts: 8
Location: Sydney, Australia
WOFTAM is offline

PostPosted: Sun Mar 10, 2019 12:27 am    Post subject: Re: Carb electrical issues Reply with quote

earthquake wrote:
Do you have a ground strap to your transaxle? rubber mounts on trans may be isolate ground from chassis.

Casey


Yes, itís got the braided strap on the transaxle. Iíve had that off and cleaned the contact surfaces just in case that was an issuue.

The engine itself appears to be grounded. If I run a jump wire from the carb to another part of the engine, it idles fine. Itís as if the carb is not electrically connected to the engine.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Q-Dog
Samba Member


Joined: April 05, 2010
Posts: 8699
Location: Sunset, Louisiana
Q-Dog is offline

PostPosted: Sun Mar 10, 2019 5:46 am    Post subject: Re: Carb electrical issues Reply with quote

My guess is the paint on the manifold may be preventing a good ground.
_________________
Brian

'69 Dune Buggy
'69 Beetle Convertible
'70 Beetle
Back to top
View user's profile Send private message Gallery Classifieds Feedback
