| Author |
Message |
SL12572
Samba Member
Joined: April 13, 2011
Posts: 270
Location: Washington
|
 Posted: Tue May 10, 2011 7:19 pm Post subject: Molded rubber instead of carpeting? |
 |
|
Does anyone know if someone makes a custom molded rubber matting, instead of carpet for the front of the Vanagon? Preferrably insulated.
Thanks! |
|
| Back to top |
|
 |
blake28
Samba Member
Joined: September 29, 2005
Posts: 141
Location: Iowa City, IA
|
| Posted: Tue May 10, 2011 7:27 pm Post subject: |
|
|
van cafe and go westy sell some mats that cover most of the front floor.
I read a thread on here about a guy commenting how he scored a rubber front floor at a u-pull-it yard. Not sure what that consisted of, but it sounded like it was a carpet replacement.
_________________
84 Westy
85 GL |
|
| Back to top |
|
|
syncrodoka
Samba Member
Joined: December 27, 2005
Posts: 12436
Location: Santa Cruz, CA
|
| Posted: Tue May 10, 2011 7:49 pm Post subject: |
|
|
Trucks, commercial vehicles and the late L models came with full rubber molded interiors for the front , center aisle and the main cargo area. They are hard to come by so the german rubber floor mats are a decent option http://www.van-cafe.com/home/van/page_484_128/german_vanagon_rubber_floor_mats.html
I have the rubberized interior in my truck and it is nice because I can take a hose to the interior if needed to clean it but I still have the german mats to reduce wear on them. |
|
| Back to top |
|
|
dhaavers
Samba Member
Joined: March 19, 2010
Posts: 8549
Location: NE MN (tinyurl.com/dhaaverslocation)
|
|
| Back to top |
|
|
ragnarhairybreeks
Samba Member
Joined: October 26, 2009
Posts: 1945
Location: Sidney B.C. Canada
|
| Posted: Tue May 10, 2011 9:13 pm Post subject: |
|
|
| blake28 wrote: |
van cafe and go westy sell some mats that cover most of the front floor.
I read a thread on here about a guy commenting how he scored a rubber front floor at a u-pull-it yard. Not sure what that consisted of, but it sounded like it was a carpet replacement. |
yeah, that was probably me. Was a very lucky find, but wasn't one for sale in the classifieds a while back?
The rubber replaces the carpet, but I left the composition floor pads in place. I suspect in the original install the rubber went right on the steel floor.
alistair
_________________
'86 7 passenger syncro, converted to westy pop top, project still in progress
'82 westy, diesel converted to gas in '94, now gone...
https://shufti.blog/
Old address still works...
http://shufti.wordpress.com |
|
| Back to top |
|
|
2doorsdown
Samba Member
Joined: December 08, 2010
Posts: 120
|
| Posted: Tue May 10, 2011 10:23 pm Post subject: |
|
|
| Wow that is a cleeeean floor! I have the rubber floor mats in my syncro and yes they are directly on the steel..no composition pads underneath. Your pic makes me feel as houygh I should clean them up even though they aren't dirty:) |
|
| Back to top |
|
|
ALIKA T3
Samba Member
Joined: July 30, 2009
Posts: 7329
Location: Honolulu,Hawaii and France
|
|
| Back to top |
|
|
insyncro
Banned
Joined: March 07, 2002
Posts: 15086
Location: New York
|
| Posted: Wed May 11, 2011 5:03 am Post subject: |
|
|
| ALIKA T3 wrote: |
Alistair:in this picture,you have the sound proof mat underneath?
If yes,do you know if there are 2 versions of the rubber mat?As I never seen a rubber mat been able to fit on top of them.
I tried myself to be sure....  |
The rubber mating comes in two versions....one the fits automatic and the other standard vans as the shifter areas are different.
The stock insulation used in the carpeted vans has to be eliminated for the rubber mats to fit properly.
http://www.thermotec.com/
I use adhesive backed thermotec without issue under them.
dylan
Last edited by insyncro on Mon May 16, 2011 5:27 am; edited 1 time in total |
|
| Back to top |
|
|
ragnarhairybreeks
Samba Member
Joined: October 26, 2009
Posts: 1945
Location: Sidney B.C. Canada
|
| Posted: Wed May 11, 2011 5:29 am Post subject: |
|
|
| ALIKA T3 wrote: |
Alistair:in this picture,you have the sound proof mat underneath?
If yes,do you know if there are 2 versions of the rubber mat?As I never seen a rubber mat been able to fit on top of them.
I tried myself to be sure.... |
Yes, I have the stock "chipped" rubber composition pads under the black rubber mat. It fits pretty well except at the sides, just adjacent to the door openings (sides of foot well I guess you could say). The holes in the rubber mat are about 1/2 - 3/4" to high to match with the plastic bosses on the body.
Its not a problem really, you really don't notice the mismatch and the rubber mat stays in place fine.
alistair
PS pic was taken just after cleaning floor and treating with meguiers vinyl cleaner/conditioner. It did get dirtier
_________________
'86 7 passenger syncro, converted to westy pop top, project still in progress
'82 westy, diesel converted to gas in '94, now gone...
https://shufti.blog/
Old address still works...
http://shufti.wordpress.com |
|
| Back to top |
|
|
syncrodoka
Samba Member
Joined: December 27, 2005
Posts: 12436
Location: Santa Cruz, CA
|
| Posted: Wed May 11, 2011 5:40 am Post subject: |
|
|
| I put in the molded insulation panels from a GL under my stock rubber mat. They helped the noise greatly but the fitting of the rubber isn't nearly as good as before. The noise reduction was worth it though. |
|
| Back to top |
|
|
Zeitgeist 13
Samba Member
Joined: March 05, 2009
Posts: 12177
Location: Port Manteau
|
| Posted: Wed May 11, 2011 6:47 am Post subject: |
|
|
| dhaavers wrote: |
I don't expect you'll find an all-in-one insulated mat, but some sambanistas have added a layer of insulation under carpet/flooring
to prevent "hot foot syndrome"...(I know this is on my to do list before the next major summer road trip...)
<photo credit: tencentlife> |
I'd like to replicate this setup. I'm sure this is a really stoopid question, but what's the trick to pulling the plastic panel above the hump in this pic? I've looked at this thing for years, and occasionally tugged at it, and never really quite figured out the secret squirrel handshake needed to pull the infernal thing without bits flying off into unseen crevices. Any tips?
Casey
btw: if anyone plans to reproduce the factory rubber carpeting, please place me on the list for a group buy.
_________________
Casey--
'89 Bluestar ALH
'01 Weekender --> full camper
NEAT, no ICE. |
|
| Back to top |
|
|
SL12572
Samba Member
Joined: April 13, 2011
Posts: 270
Location: Washington
|
| Posted: Wed May 11, 2011 8:20 am Post subject: |
|
|
ragnarhairybreeks:
Looks super nice! exactly what I'm looking for...
Insyncro:
Do you have the same setup as ragnarhairybreeks? If so, how much do you want for a set? Are they all black? It's for a Syncro.
Thanks,
Scott |
|
| Back to top |
|
|
syncrodoka
Samba Member
Joined: December 27, 2005
Posts: 12436
Location: Santa Cruz, CA
|
| Posted: Wed May 11, 2011 8:29 am Post subject: |
|
|
| They are only available in black as far as I know. |
|
| Back to top |
|
|
I am Wildcat
Samba Member
Joined: February 03, 2011
Posts: 318
Location: SF Bay Area
|
| Posted: Wed May 11, 2011 8:52 am Post subject: |
|
|
| ragnarhairybreeks wrote: |
I suspect in the original install the rubber went right on the steel floor.
alistair |
Alistair - You are right on. My Syncro was originally a Transporter van from the Finnish market and I've got this same rubber flooring. From the factory it was installed directly over the steel floor. I love it. Easy to clean and looks good to me.
I used to have Stinger Roadkill Floor Liner installed in between the padding and the carpet in my old MINI and once I can track down that material for a good price, I plan on putting it underneath my rubber flooring. The sound reduction material I had installed in the MINI was done by a pro audio shop and the entire floor of the car had four layers. 1)Top level Roadkill material (like Dynamat or Fatmat), 2)original carpet padding, 3)Roadkill carpet foam pad and 4) original carpet. It made a huge difference. It wouldn't be as difficult to do in the Vanagon since you have a lot more space to work with and it's easier to pull apart than the MINI. I had it professionally installed in the MINI because the front door panels and windows are VERY difficult to remove and I wanted to make sure all the door panels were covered with Roadkill material too.
_________________
No more van. Wildcat has a new home.
1997 Land Rover Defender 90
2005 MB SL55 AMG
2014 Tesla Model S P85+ |
|
| Back to top |
|
|
syncrodoka
Samba Member
Joined: December 27, 2005
Posts: 12436
Location: Santa Cruz, CA
|
| Posted: Wed May 11, 2011 9:06 am Post subject: |
|
|
| Quote: |
| My Syncro was originally a Transporter van from the Finnish market and I've got this same rubber flooring. |
They are all known as transporters over there. You have a panel van which is a commercial vehicle and it should have the minimalist rubber mat. I prefer it in my truck along with the rubber mats to help it to last. |
|
| Back to top |
|
|
dhaavers
Samba Member
Joined: March 19, 2010
Posts: 8549
Location: NE MN (tinyurl.com/dhaaverslocation)
|
| Posted: Thu May 12, 2011 8:59 pm Post subject: |
|
|
| Zeitgeist 13 wrote: |
| stoopid question...what's the trick to pulling the plastic panel above the hump in this pic? |
Just grip near the top on both sides & pull it straight back...it'll come!
Yeah, it took me a while before I got it the first time...
_________________
86 White Wolfsburg Westy Weekender
"The WonderVan"
<EDITED TO PROTECT INNOCENT PIXELS> |
|
| Back to top |
|
|
Zeitgeist 13
Samba Member
Joined: March 05, 2009
Posts: 12177
Location: Port Manteau
|
| Posted: Thu May 12, 2011 9:26 pm Post subject: |
|
|
| dhaavers wrote: |
| Zeitgeist 13 wrote: |
| stoopid question...what's the trick to pulling the plastic panel above the hump in this pic? |
Just grip near the top on both sides & pull it straight back...it'll come!
Yeah, it took me a while before I got it the first time...
|
Ok sir, thanks to your cajoling I marched out and tugged and nudged like a determined trooper. It felt like it was going to disintegrate in my hands, but ultimately I outmaneuvered the wily beast and it popped off in one piece. What I found is there is about 67 cents in spare change sitting in the open vent ledge. I have no idea how change can be inserted up there, but there it is indeed. I shall now insulate the holy $h!t out of the hump, and defray the total cost with my found bounty.
Interwebs hero, please take a bow...
_________________
Casey--
'89 Bluestar ALH
'01 Weekender --> full camper
NEAT, no ICE. |
|
| Back to top |
|
|
dhaavers
Samba Member
Joined: March 19, 2010
Posts: 8549
Location: NE MN (tinyurl.com/dhaaverslocation)
|
| Posted: Thu May 12, 2011 9:41 pm Post subject: |
|
|
| Zeitgeist 13 wrote: |
| What I found is there is about 67 cents in spare change... |
...split it?
_________________
86 White Wolfsburg Westy Weekender
"The WonderVan"
<EDITED TO PROTECT INNOCENT PIXELS> |
|
| Back to top |
|
|
Zeitgeist 13
Samba Member
Joined: March 05, 2009
Posts: 12177
Location: Port Manteau
|
| Posted: Thu May 12, 2011 9:53 pm Post subject: |
|
|
Thank goodness the interwebs are free, or I'd be paying royalties to every Tom, Dick and Haavers out there.
_________________
Casey--
'89 Bluestar ALH
'01 Weekender --> full camper
NEAT, no ICE. |
|
| Back to top |
|
|
keithwwalker
Samba Member
Joined: May 30, 2005
Posts: 886
|
| Posted: Fri May 13, 2011 12:05 am Post subject: |
|
|
Doka's and Vanagon panel vans (no windows in back) have rubber flooring.
I have a spare in my garage because my rubber floor has a tear in it.
The rear doka floor also had a separate rubber mat and a smaller mat at the door. These are also hard to get and not readily usable by the vans.. |
|
| Back to top |
|
|
|
