Transmission input shaft seal
Forum Index -> Beetle - 1958-1967 Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
ebrekhus
Samba Member


Joined: August 18, 2011
Posts: 16
Location: Colorado
ebrekhus is offline

PostPosted: Sat Apr 04, 2020 2:03 pm    Post subject: Transmission input shaft seal Reply with quote

Replacing the transmission input shaft seal on my 1963 bug. Anyone know a good tool to install it correctly?
Image may have been reduced in size. Click image to view fullscreen.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Cusser
Samba Member


Joined: October 02, 2006
Posts: 25162
Location: Hot Arizona
Cusser is offline

PostPosted: Sat Apr 04, 2020 2:19 pm    Post subject: Re: Transmission input shaft seal Reply with quote

ebrekhus wrote:
Replacing the transmission input shaft seal on my 1963 bug. Anyone know a good tool to install it correctly?
Image may have been reduced in size. Click image to view fullscreen.


A little Permatex aviation sealant on the outside of the new seal, and a little engine oil on the inside of the new seal and the transmission shaft itself, and a few taps with a 6-inch length of 1-inch schedule 40 PVC pipe got it installed evenly and completely

See https://www.thesamba.com/vw/forum/viewtopic.php?t=...;start=100 (page 6 of the thread)
_________________
1970 VW (owned since 1972) and 1971 VW Convertible (owned since 1976), second owner of each. The '71 now has the 1835 engine, swapped from the '70. Second owner of each. 1988 Mazda B2200 truck, 1998 Frontier, 2005 Yukon, 2004 Frontier King Cab. All manual transmission except for the Yukon. http://www.thesamba.com/vw/forum/album_page.php?pic_id=335294 http://www.thesamba.com/vw/forum/album_page.php?pic_id=335297
Back to top
View user's profile Send private message Gallery Classifieds Feedback
glutamodo Premium Member
The Android


Joined: July 13, 2004
Posts: 25486
Location: Douglas, WY
glutamodo is offline

PostPosted: Sun Apr 05, 2020 3:20 pm    Post subject: Re: Transmission input shaft seal Reply with quote

I had (still have) a section of steel pipe I use as a driver.
_________________
Andy T.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
bad91teg
Samba Member


Joined: February 13, 2007
Posts: 270
Location: florida
bad91teg is offline

PostPosted: Sun Apr 05, 2020 3:55 pm    Post subject: Re: Transmission input shaft seal Reply with quote

Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.
harbor freight jack handle fits exact
Back to top
View user's profile Send private message Gallery Classifieds Feedback
glutamodo Premium Member
The Android


Joined: July 13, 2004
Posts: 25486
Location: Douglas, WY
glutamodo is offline

PostPosted: Mon Apr 06, 2020 12:30 am    Post subject: Re: Transmission input shaft seal Reply with quote

I found the jack handle method to be just a bit too far away, it works, but I like to be able to see the seal when I'm tapping on it.
_________________
Andy T.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
