Syncro shifter question about R & G
Forum Index -> Vanagon Share: Facebook Twitter
Reply to topic
Print View
Quick sort: Show newest posts on top | Show oldest posts on top View previous topic :: View next topic
Author Message
gertiebob
Samba Member


Joined: February 23, 2015
Posts: 176
Location: Seattle
gertiebob is offline

PostPosted: Sun Apr 21, 2024 11:19 am    Post subject: Syncro shifter question about R & G Reply with quote

This has me stymied. My Syncro shifts fine into all gears. However, in R and G, there is a “rubbing” noise as the van moves. Also there is a feeling like the shifter tabs are too tight against the “back” of the R/G lockout plate while in R and G.

So, shifts into R or G fine, stays in gear fine but it just feels (and sounds) wrong. Adjusting away from this makes other gears problematic.

All newish shift linkage parts end to end. Well greased and clean.

Thanks for help.

PS: I do know how to adjust at the spline, etc. I believe all is correctly assembled. …but something is off and I suppose it’s me.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
MarkWard
Samba Member


Joined: February 09, 2005
Posts: 18652
Location: Retired South Florida
MarkWard is offline

PostPosted: Sun Apr 21, 2024 11:48 am    Post subject: Re: Syncro shifter question about R & G Reply with quote

Can you temporarily drop the shift rod off the transmission, manually select G or R at the ball lever and see if the noise is present? You can temporarily tie wrap the shift lever up to keep it from dragging. This will isolate the shift mechanism completely. A noise while moving is not a common symptom of a shift linkage adjustment.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
gertiebob
Samba Member


Joined: February 23, 2015
Posts: 176
Location: Seattle
gertiebob is offline

PostPosted: Sun Apr 21, 2024 1:05 pm    Post subject: Re: Syncro shifter question about R & G Reply with quote

Never thought of that. I’d need to find an empty parking lot.

However, I will say that if I move the shifter knob to the right while moving, help shifter hop over the lockout while staying in granny, noise disappears.

PS: noise is kind of a shhhhhhhh. Changing with speed while in G and R.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
MarkWard
Samba Member


Joined: February 09, 2005
Posts: 18652
Location: Retired South Florida
MarkWard is offline

PostPosted: Sun Apr 21, 2024 3:08 pm    Post subject: Re: Syncro shifter question about R & G Reply with quote

From memory Granny and Reverse share the same hub. You maybe applying pressure up front, but it is translating into that hub quieting the assembly. Also, G and R are in a different section of the transaxle. My hope it’s external.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
gertiebob
Samba Member


Joined: February 23, 2015
Posts: 176
Location: Seattle
gertiebob is offline

PostPosted: Sun Apr 21, 2024 5:19 pm    Post subject: Re: Syncro shifter question about R & G Reply with quote

Thanks for thoughts Mark. Here’s another clue. Simply pushing down on the shifter knob while G is engaged and car moving quiets the noise.

I would like one day to see a Syncro transmission disassembled to get a better idea how it works. I understand principles and most terms but not how it all works in function.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
4Gears4Tires
Samba Member


Joined: October 08, 2018
Posts: 4084
Location: MD
4Gears4Tires is offline

PostPosted: Sun Apr 21, 2024 5:27 pm    Post subject: Re: Syncro shifter question about R & G Reply with quote

I was having an issue with shifting into R and G and I resolved it by creating a 22mm block of wood and aligning my shifter properly.
_________________
'87 Syncro Ferric Oxyhydroxide Superleggera Edition
'85 Westy Sciuridae Domus Edition
Back to top
View user's profile Send private message Gallery Classifieds Feedback
gertiebob
Samba Member


Joined: February 23, 2015
Posts: 176
Location: Seattle
gertiebob is offline

PostPosted: Sun Apr 21, 2024 5:51 pm    Post subject: Re: Syncro shifter question about R & G Reply with quote

Mine is currently so aligned. I use the block! Gears engage perfectly. No misalignment, grinding or other issues. Just the shhhhhhh noise and only in R and G.
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
dougnlina Premium Member
Samba Member


Joined: January 19, 2016
Posts: 293
Location: San Francisco, CA
dougnlina is offline

PostPosted: Mon Apr 22, 2024 6:39 am    Post subject: Re: Syncro shifter question about R & G Reply with quote

gertiebob wrote:
Mine is currently so aligned. I use the block! Gears engage perfectly. No misalignment, grinding or other issues. Just the shhhhhhh noise and only in R and G.


Sounds like it is one click too tight against the R-G Gate in the shifter box, putting force on the stickshift while in gear will make such noises. +1 they will go away when you disconnect the shifter
_________________
"Grover" a '87 Syncro Poptop 1.8T
"Olive" a '60 Ragtop Beetle (retired)
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
MarkWard
Samba Member


Joined: February 09, 2005
Posts: 18652
Location: Retired South Florida
MarkWard is offline

PostPosted: Mon Apr 22, 2024 7:47 am    Post subject: Re: Syncro shifter question about R & G Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


This picture seems to help some members. The factory manual is hung up on measuring to the right of the shift tab. The clearance that gets you a better shift is how the l/s tab compares to the above picture. This is a 4 speed in neutral, but it’s the same for a syncro. I can visually hit this point on the splines, but I used to attach a bungee cord to the shift lever and the passenger door pull. I’d slip a quarter between the l/s tab and the shifter box. Tighten the clamp and be done.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
