 Posted: Mon Dec 22, 2025 8:33 pm Post subject: Torsion Arms |
 |
|
Have two questions about these torsion arms. The one pitted is it damaged beyond repair? Seems the major pitting is between the bearing and sleeve area. Second is the one with the end cap popped off. Is there a way to repair this? Are both of these issues a waste of my time? If so should I replace all four of them and who to purchase from? Thank you for any help.
|
|
| Back to top |
|
 |
Schepp
Samba Member
Joined: March 22, 2020
Posts: 806
Location: NorCal
|
| Posted: Mon Dec 22, 2025 9:02 pm Post subject: Re: Torsion Arms |
|
|
They don’t look bad to me. What’s important is the bearing areas. I don’t see any pitting or wear marks in that area. How to the bearings look? That is most important too.
I see nothing wrong those parts. The cap you should be able to tap back on. You can stake it to prevent it from falling out again.
_________________
Bandit #19
1972 Baja Rallycross Bug |
|
| Back to top |
|
|
Rustybettle68$
Samba Member
Joined: October 06, 2025
Posts: 5
|
| Posted: Mon Dec 22, 2025 9:38 pm Post subject: Re: Torsion Arms |
|
|
| Schepp wrote: |
They don’t look bad to me. What’s important is the bearing areas. I don’t see any pitting or wear marks in that area. How to the bearings look? That is most important too.
I see nothing wrong those parts. The cap you should be able to tap back on. You can stake it to prevent it from falling out again. |
Bearings don’t look to far gone. But I am replacing them with rebuild of front beam. So just wire wheel, light emery cloth, and some rust converter for the pitting? I’d only like to have to do this once for right now and hopes it will all last a couple of years |
|
| Back to top |
|
|
VW_Jimbo
Samba Member
Joined: May 22, 2016
Posts: 11501
Location: Huntington Beach, CA
|
| Posted: Mon Dec 22, 2025 11:47 pm Post subject: Re: Torsion Arms |
|
|
Those look good to me, too! Spray some Ospho on them for the rust. Then get them greased up so they cannot get wet again!
_________________
Jimbo
There is never enough time to do it right the first time, but all the time necessary the second time!
| TDCTDI wrote: |
| Basically, a whole bunch of fuckery to achieve a look. |
| 67rustavenger wrote: |
GFY's Xevin and VW_Jimbo!  |
|
|
| Back to top |
|
|
74 Thing
Samba Member
Joined: September 02, 2004
Posts: 7687
|
| Posted: Tue Dec 23, 2025 12:45 am Post subject: Re: Torsion Arms |
|
|
| I forgot if it was a sliver dollar or half dollar piece that can replace the end cap. |
|
| Back to top |
|
|
scrivyscriv
Samba Electrician
Joined: October 04, 2011
Posts: 3390
Location: Memphis
|
| Posted: Tue Dec 23, 2025 4:49 am Post subject: Re: Torsion Arms |
|
|
Id be iffy on that inner bearing surface, it doesn’t look great. Really and truly though with the amount of use VWs get, it probably won’t amount to a hill of beans,.. would just wear the inner bearing/bushing faster.
Another way to say it: If you have other options, explore those first, but if you absolutely cannot find a deal on some cleaner trailing arms, just stick those in and keep an eye out for any weird tire wear.
_________________
Robert in Memphis
Dünkelgrügen 1967 Java Green bug thread
Engine rebuild thread
If you're ever in the Memphis area, you are welcome to stop by for advice and help. |
|
| Back to top |
|
|
pondoras box
Samba Member
Joined: March 22, 2004
Posts: 1939
Location: Warren, PA
|
| Posted: Tue Dec 23, 2025 5:55 am Post subject: Re: Torsion Arms |
|
|
Where are you located, even here in the rust belt I could find a better set. But check the classifieds here they shouldn’t be too much. They made millions of these things. My opinion is get a better set, you already have them apart
_________________
Looking for anything from Hal Casey Motors out of Hamburg New York, from license plate surrounds to matchbooks.
1961 23 Window (Bobo)
1965 11 Window (Zelda). https://www.thesamba.com/vw/forum/viewtopic.php?t=563183
1965 13 Window (Lucas)
1957 Oval ragtop
1960 hardtop
1964 hardtop
1965 hardtop (Arschloch)
1973 standard bug (Dirty Gertie)
https://www.thesamba.com/vw/forum/viewtopic.php?t=804912
1988 Cabriolet VR6 conversion |
|
| Back to top |
|
|
baldessariclan
Samba Member
Joined: October 14, 2016
Posts: 2208
Location: Wichita, KS
|
| Posted: Tue Dec 23, 2025 5:56 am Post subject: Re: Torsion Arms |
|
|
| Rustybettle68$ wrote: |
Second is the one with the end cap popped off. Is there a way to repair this?
|
I had this issue on one of my old torsion arms several years ago, and ended up filing down and installing a metal cap used to plug knockout holes in home electrical boxes. More details and pics in this old thread: https://www.thesamba.com/vw/forum/viewtopic.php?p=8398890
_________________
1971 Standard Beetle — fairly stock / driver
baldessariclan -- often in error, never in doubt... |
|
| Back to top |
|
|
runamoc
Samba Member
Joined: June 19, 2006
Posts: 6468
Location: 37.5N 77.1W
|
| Posted: Tue Dec 23, 2025 9:29 am Post subject: Re: Torsion Arms |
|
|
swap arms to the other side. The arms wear more on one side of the bearing surface than the other.
_________________
Daily driver: '69 Baja owned 45 yrs - Plan B: '72 Ghia
Yard Art: 2 Sandrails
Outback: '69 Ghia - '68,'69,'70,'72 Beetle - '84 Scirocco, GTI - Pair of '02 Golfs- '80 Rabbit Diesel
VW Wiring = It's just wires
Last edited by runamoc on Tue Dec 23, 2025 11:07 am; edited 1 time in total |
|
| Back to top |
|
|
empi3
Samba Member
Joined: October 03, 2015
Posts: 386
Location: SW Wyoming
|
| Posted: Tue Dec 23, 2025 10:24 am Post subject: Re: Torsion Arms |
|
|
| runamoc wrote: |
| swap arms to the other side. The arms wear more on one side of the bearing surface than the other. |
Dang I always thought they were position specific
Steven
Reconditioned arms....there are probably other places too
https://wolfgangint.com/search?controller=search&s=torsion+arms
