 Posted: Mon May 07, 2018 10:59 am Post subject: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
 |
|
There is a lot of postings and information on the Solex PDSIT 32-34 carbs and their different characteristics (jets, screws, etc...). I would like to start a posting that provides a table on the Solex parts number (tag and stamping on bottom of float bowl). To date I have found most of the information scattered throughout various postings and pics.
Please provide feedback and input to complete the table accurately. I will update upon consensus.
TYPE 2
1972 Type 2, 1.7L, Manual Trans., Engine Code CB 000 001, M157
Left Side Tag#: 021 129 027 L Float Bowl Stamp#: VW337-1 & 2104
Right Side Tag#: 021 129 028 L Float Bowl Stamp#: VW338-1 & 1195,1153?
Left Side Tag#: ### ### ### X Float Bowl Stamp#: VW337-2 & 2137
Right Side Tag#: ### ### ### X Float Bowl Stamp#: VW338-2 & 2138
1973 Type 2, 1.7L, Manual Trans., Engine Code CB 062 001, M157
Left Side Tag#: 021 129 027 P Float Bowl Stamp#: VW383-1 & ####
Right Side Tag#: 021 129 028 P Float Bowl Stamp#: VW384-1 & 3004
1973 Type 2, 1.7L, Auto Trans., Engine Code CD 000 001, M157, M249
Left Side Tag#: 021 129 027 M Float Bowl Stamp#: VW339-1 & ####
Right Side Tag#: 021 129 028 M Float Bowl Stamp#: VW340-1 & ####
1973 Type 2, 1.8L, Manual Trans., Engine Code CD, M157
Left Side Tag#: 021 129 031 Q Float Bowl Stamp#: VW454-1 & 4002
Right Side Tag#: 021 129 032 Q Float Bowl Stamp#: VW455-1 & 4003, 3324?
1973 Type 2, 1.8L, Auto Trans., Engine Code CD, M157, M249
Left Side Tag#: 021 129 031 Float Bowl Stamp#: VW456-1 & ####
Right Side Tag#: 021 129 032 Float Bowl Stamp#: VW457-1 & ####
1974 Type 2, 1.8L, Manual Trans., Engine Code XX ### ###, M157
Left Side Tag#: 021 129 031 N Float Bowl Stamp#: VW445-1 & ####
Right Side Tag#: 021 129 032 N Float Bowl Stamp#: VW446-1, & #####
1974 Type 2, 1.8L, Auto Trans., Engine Code XX ### ###, M157, M249
Left Side Tag#: 021 129 031 P Float Bowl Stamp#: VW447-1 & ####
Right Side Tag#: 021 129 032 P Float Bowl Stamp#: VW448-1 & ####
TYPE 3
1971 Type 3, L, Auto Trans., Engine Code XX ### ###, M###, M###
Left Side Tag#: ### ### ### Float Bowl Stamp#: VW316-1 & 1062
Right Side Tag#: ### ### ### P Float Bowl Stamp#: VW317-1 & 1060
YYYY Type 3, 1.7L, Manual Trans., Engine Code XX ### ###, M###, M###
Left Side Tag#: 021 129 027 N Float Bowl Stamp#: VW381-1 & ####
Right Side Tag#: 021 129 028 N Float Bowl Stamp#: VW382-1 & ####
TYPE 4
YYYY Type 4, L, Manual Trans., Engine Code XX ### ###, M###, M###
Left Side Tag#: 021 129 027 A Float Bowl Stamp#: VW###-# & ####
Right Side Tag#: 021 129 028 A Float Bowl Stamp#: VW###-# & ####
Last edited by 72vwtype2 on Wed May 09, 2018 8:59 am; edited 3 times in total |
|
| Back to top |
|
 |
Alan Brase
Samba Member
Joined: March 28, 2004
Posts: 4570
Location: Cedar Falls, Iowa
|
| Posted: Mon May 07, 2018 7:38 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
If I remember correctly, 1972 carbs have o-rings on the air horns. 73-4 have a flat section donut gasket.
Al
_________________
Al Brase
Projects: 67 sunroof bug, 67 Porsche 912 Targa, 70 Westy
Dec 1955 Single Cab pickup WANT 15" BUS RIMS dated 8/55, thru 12/55
To New owners: 1969 doublecab, 1971 Dormobile
Vanagons:
80 P27 Westy JUL 1979, 3rd oldest known US
83 1.6TD Vanagon, 87 Wolfie Westy daily driver, swap meet home |
|
| Back to top |
|
|
aeromech
Samba Member
Joined: January 24, 2006
Posts: 17759
Location: San Diego, California
|
| Posted: Tue May 08, 2018 6:46 am Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
Great, keep going
_________________
Lead Mechanic: San Diego Air and Space Museum
Licensed Airframe and Powerplant Mechanic
Licensed Pilot (Single engine Land)
Boeing 727,737-200-300-400,757,767
Airbus A319,320,321
DC9/MD80
BAe146
Fokker F28/F100
VW type 1 1962,63,65,69,72
VW Type 2 1971 (3 ea.) 1978, 1969
VW Jetta
VW Passat
Capable of leaping tall buildings in a single bound |
|
| Back to top |
|
|
Tcash
Samba Member
Joined: July 20, 2011
Posts: 12843
Location: San Jose, California, USA
|
| Posted: Wed Jul 04, 2018 9:31 am Post subject: Re: 1972 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
34 PDSIT -2-3 Carburetors kit 1972 T2
note: metal air cleaner with short brackets
Last edited by Tcash on Wed Jul 04, 2018 10:05 am; edited 1 time in total |
|
| Back to top |
|
|
Tcash
Samba Member
Joined: July 20, 2011
Posts: 12843
Location: San Jose, California, USA
|
| Posted: Wed Jul 04, 2018 9:42 am Post subject: 1973-74 Solex 32-34 PDSIT |
|
|
1973-74 32-34 PDSIT complete set
Note: Plastic air cleaner with Tall brackets
1973-74 32-34 PDSIT
1973-74 Solex 32-34 PDSIT
Note: CB engine is 1972
|
|
| Back to top |
|
|
VWLady
Crazy VW Lady
Joined: March 13, 2004
Posts: 3868
Location: Twin Cities, MN
|
| Posted: Tue Jun 21, 2022 10:17 am Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
Can someone help me identify what I have here? I believe them to be Pieces and parts of a 32-34 PDSIT-2/3 Carb set. I'm trying to identify correctly and sell.
Value suggestions are welcome too.
|
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 53217
Location: Surrey B.C. Canada, but thinking of Ukraine
|
| Posted: Tue Jun 21, 2022 11:16 am Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
That's a 1973 model set up, reasonably complete too aside from the EGR tube(s) and anything aircleaner. If it's still in there don't lose the cup and spring out of the RH end of the throttle crossbar.
Value?, I'm not sure, If I needed them and was at a swap I'd offer you $50, they'll still need a few hundred $ trip to Tim's for rebuilds. Others may disagree.
_________________
Rust NEVER sleeps and stock never goes out of style.
Please don't PM technical questions, ask your problem in public so everyone can play along. If you think it's too stupid post it here
Stop dead photo links! Post your photos to The Samba Gallery!
Слава Україні! |
|
| Back to top |
|
|
Alan Brase
Samba Member
Joined: March 28, 2004
Posts: 4570
Location: Cedar Falls, Iowa
|
| Posted: Tue Jun 21, 2022 2:57 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
| busdaddy wrote: |
That's a 1973 model set up, reasonably complete too aside from the EGR tube(s) and anything aircleaner. If it's still in there don't lose the cup and spring out of the RH end of the throttle crossbar.
Value?, I'm not sure, If I needed them and was at a swap I'd offer you $50, they'll still need a few hundred $ trip to Tim's for rebuilds. Others may disagree. |
yeah, I pretty much agree. Actually it was a VERY good setup when it was new and same basic thing used clear thru last air cooled Vanagons in ROW. I'm tempted to put such a setup in my 1980 Vanagon together with a small HP cam and bigger valves, then put in the biggest Venturis I can find. I think 28mm. I that setup should pass 20% more air, which 120% of 67hp is about 80hp. And possibly easier than FI.
Of course, on the Vanagon, T25, VW used a VERY low profile air cleaner.
I would NEVER consider using aftermarket air cleaners, BTW.
These carbs DID wear out the throttle shafts pretty badly. but new shafts and butterflys and bushings are available.
_________________
Al Brase
Projects: 67 sunroof bug, 67 Porsche 912 Targa, 70 Westy
Dec 1955 Single Cab pickup WANT 15" BUS RIMS dated 8/55, thru 12/55
To New owners: 1969 doublecab, 1971 Dormobile
Vanagons:
80 P27 Westy JUL 1979, 3rd oldest known US
83 1.6TD Vanagon, 87 Wolfie Westy daily driver, swap meet home |
|
| Back to top |
|
|
volkybus
Samba Member
Joined: November 03, 2013
Posts: 486
Location: CASTLETON VT USA
|
| Posted: Tue Jun 21, 2022 3:40 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
| Well I had several buses from that era that had the stock solex duel carbs a72,73 & a 74..all ended up troubleson & had to be replaced. Once I put another set rebuilt on and they were fine for a couple years till the bus was sold . The 73 ended up with a 1600 type 1 engine and the ,74 I changed to 34 weabers. Ten years later when my 76 Westy caught fire and destroyed the wiring harness , I dug them out of the junk 74 which Sat 10 years in a swamp in Vt ,cleaned them up and they have been on my Westy for about 4 or five years. Great carbs ...I use the van from Apr to end of Nov every year..no chokes but pump it a bit & off I go..In fact I'm on a 500+ road trip right now..I get about 20+- mpg they say I need bigger carbs w the 2 liter engine so u know..I drive slow no more than 55 so to me dependability is the most important thing as t my age....Biil and my old solixes are avaiblr |
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 53217
Location: Surrey B.C. Canada, but thinking of Ukraine
|
| Posted: Tue Jun 21, 2022 4:19 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
Tim ( volkzbitz.com ) fixes the throttle shafts, some of his are going on ~5 years with lots of miles and I haven't heard anyone complain yet.
They are an exceptional carb when rebuilt properly, very well behaved in all climates and seasons.
But there's still going to be haters, I'm sure one will be along shortly.
_________________
Rust NEVER sleeps and stock never goes out of style.
Please don't PM technical questions, ask your problem in public so everyone can play along. If you think it's too stupid post it here
Stop dead photo links! Post your photos to The Samba Gallery!
Слава Україні! |
|
| Back to top |
|
|
timpetzold
Samba Member
Joined: July 13, 2022
Posts: 2
Location: Norfolk
|
| Posted: Wed Jul 13, 2022 9:09 am Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
I have a VW camper T2 Bay which has twin Solex 32 - 34 PDSIT - 3 carburettors. I need the valve-like part as marked in the attached picture because mine is full of stuff which we can't clean out - can you help, please? It's the 2.5cm long protruding piece, not the flat nut next to it. I don't know what it's called, nor what it actually does!!!
|
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 53217
Location: Surrey B.C. Canada, but thinking of Ukraine
|
| Posted: Wed Jul 13, 2022 10:36 am Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
Welcome!
I'm not sure of the exact name, it's a thermostatic accelerator pump compensator.
It's only found on auto transmission carbs in 73/74 so it'll be pretty rare, I've never seen one for sale loose, the odd one shows up on core carbs.
Have you tried soaking it in various things like alcohol (methyl hydrate), carb cleaner and even vinegar if it's corroded?, how about an ultrasonic cleaner bath?, those things get anything loose.
_________________
Rust NEVER sleeps and stock never goes out of style.
Please don't PM technical questions, ask your problem in public so everyone can play along. If you think it's too stupid post it here
Stop dead photo links! Post your photos to The Samba Gallery!
Слава Україні! |
|
| Back to top |
|
|
timpetzold
Samba Member
Joined: July 13, 2022
Posts: 2
Location: Norfolk
|
| Posted: Wed Jul 13, 2022 10:45 am Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
| Thanks for that - I'll start trying out your suggestions right away. |
|
| Back to top |
|
|
germansupplyscott
Samba Member
Joined: May 22, 2004
Posts: 7286
Location: toronto
|
| Posted: Wed Jul 13, 2022 1:26 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
| busdaddy wrote: |
It's only found on auto transmission carbs in 73/74 so it'll be pretty rare, I've never seen one for sale loose, the odd one shows up on core carbs. |
A similar, if not identical part is also used on European spec carbs from 2.0l engines. I believe they all have it regardless of transmission. So maybe searching in Europe can be helpful.
_________________
SL |
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 53217
Location: Surrey B.C. Canada, but thinking of Ukraine
|
| Posted: Wed Jul 13, 2022 3:14 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
| germansupplyscott wrote: |
| busdaddy wrote: |
It's only found on auto transmission carbs in 73/74 so it'll be pretty rare, I've never seen one for sale loose, the odd one shows up on core carbs. |
A similar, if not identical part is also used on European spec carbs from 2.0l engines. I believe they all have it regardless of transmission. So maybe searching in Europe can be helpful. |
Ahhhh, yes, the rest of the world likely used them longer, not everyone got FI in late 74.
There was a thread here quite a few years ago from a member in Australia with those, but I can't find it to see what exactly it does in the bowl, and if there's a work around to possibly delete it.
_________________
Rust NEVER sleeps and stock never goes out of style.
Please don't PM technical questions, ask your problem in public so everyone can play along. If you think it's too stupid post it here
Stop dead photo links! Post your photos to The Samba Gallery!
Слава Україні! |
|
| Back to top |
|
|
P24p1
Samba Member
Joined: August 20, 2020
Posts: 365
Location: Canada, Quebec
|
| Posted: Wed Jul 13, 2022 6:27 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
What is this dashpot looking thing on what I'm guessing is the EGR tube?
Also, does anyone know if the mixture tube is interchangeable between '72 and '73-'74?
_________________
1973 Westfalia named Angie (Sold '23)
What rust?
Rev it - don't lug it! |
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 53217
Location: Surrey B.C. Canada, but thinking of Ukraine
|
| Posted: Wed Jul 13, 2022 7:57 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
The "thing" is the EGR valve.
The CIS tube will interchange (sort of), it'll have a bonus tube pointing to the back for the smog pump, and the outer ends may be angled a little higher to match the taller late manifolds (not sure on that one, the base is still the same).
_________________
Rust NEVER sleeps and stock never goes out of style.
Please don't PM technical questions, ask your problem in public so everyone can play along. If you think it's too stupid post it here
Stop dead photo links! Post your photos to The Samba Gallery!
Слава Україні! |
|
| Back to top |
|
|
bavarian1
Samba Member
Joined: December 11, 2005
Posts: 57
Location: SoCal
|
| Posted: Mon Dec 15, 2025 9:05 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
Question for the pros, rebuilt my PDSIT's but the throttle plates are very worn, I have a new set similar to these, which appear to be an updated version with a hot idle valve casting in the side? I have not found any info on that valve, parts etc. Pics I have seen on vans its just left open with no valve?
[/img]
_________________
'58 Beetle - L245 Bronze
'73 Vert SB - Dove Grey
'74 Sedan SB - Tropical Green
'72 Bay Panel - Pastel White |
|
| Back to top |
|
|
busdaddy
Samba Member
Joined: February 12, 2004
Posts: 53217
Location: Surrey B.C. Canada, but thinking of Ukraine
|
| Posted: Mon Dec 15, 2025 9:15 pm Post subject: Re: 1972 - 1974 Solex PDSIT 32-34 (Identification by Parts#) |
|
|
Check to see if they are drilled, most are blank casting holes.
