Pictures of tire, wheel, and suspension thread for FAQ's

[mabbo]

4" beam with dropped spindles
2" adjustable spring plates
135r15 Michelin ZX front tyres
165r15 Michelin XZX rear tyres
Stock wheels with period trims / beauty rings.
_________________
Retro Restoration
West Midlands, UK
www.retro-resto.co.uk

See more of our work here:
www.instagram.com/retrorestoration
www.facebook.com/retrorestos

[sparkle_0]

1969

Front
2.5" Spindles
15x4.5 type 3 steels (+46? Offset)
165 65r15

Rear
+5/-5
Stock 15x4
165 80r15

Want to go slightly wider in the rear and fill guards. May either widen a spare pair or purchase a set of 5.5s (however it seems they have more positive offset than stock?) Any ideas on what fits with long axles?

[krahulec]

1967 Agate Metallic Grey

Suspension:
CoolRydes Customs (CRC) True Performance T-1 Front Mendeola Suspension Kit Stock Width w Red Coilover Springs, and 2.5” drop spindles
CoolRydes Customs (CRC) True Track Rear Suspension Kit – Narrowed 1.25 per side
CoolRydes Customs (CRC) CoolStop 11” Cross-Drilled 5x130MM Disc Brakes w Wilwood 4 Piston Red Calipers
Double U-Joint Steering Shaft

Wheels
Schott RAIL Cover-Loc Wheels
bolt pattern - 5 on 130, studs 14x1.5
Fronts - 17”x7”, +40mm offset
Rears - 17”x8”, +40mm offset
Tires
Firestone Firehawk Indy 500
Front 205/40R17
Rear 215/45R17

[FRANKR]

6" narrowed beam, 2 1/2 drop spindles, rear adjustable 3" drop plates. disc brakes all around.

[TastyTuner]

FRANKR

Beetle looks great! Perfect stance
_________________
TastyGarage

[shanered]

[Junkbone]

Just wanted to post up my 63. I have a 5 inch shockless beam from Sam at Valley autowerks, 2.5 drop spindles on drums. The fronts are 5.5 smoothies from JBugs with Conti 145/65R15. The rear is just a combination of inner and outer splines to get me where I wanted. Honestly I went up and down so many times I stopped counting and just worried more about degrees. The rears are 7 wide smoothies from US wheel. They have 4.25 backspacing and are pretty tight on the inside and may need to massage the body mount to clear when hitting bumps. I was hoping they would fill the fender a bit better. Stock swing plates with no notching. Tires are Ironman 205/60R15 and like I said they just clear the body mount.

[slayer61]

I like it.
_________________

[muravr]

Hi there, news for my MY63 with adjustable front beam

Front with original 4” smoothies and Retro Classic 001 155/80

Rear with John Brown Wheels widened smoothies 5,5” and Retro Classic 001 165/80

[OtisGore]

215/65/15 in the rear
165/60/15 in the front
...wrapped around 5.5J BRM repros

_________________
'67 Euro Sedan - almost completed
www.instagram.com/odysseygarage
www.odysseygarage.com
Odyssey Garage - "The Odyssey Continues"

[Apostle_]

Beautiful!

[slayer61]

[OtisGore]
