| Author |
Message |
ryansdad03
Samba Member
Joined: October 13, 2011
Posts: 78
Location: riverside
|
 Posted: Sun Feb 02, 2025 9:52 pm Post subject: Starter purchase |
 |
|
I am in in need of a new starter for my car. Is there a huge advantage to buying a $250 Bosch starter versus a lesser expensive starter?
_________________
————————I'm your huckleberry———————— |
|
| Back to top |
|
 |
67rustavenger
Samba Member
Joined: February 24, 2015
Posts: 10813
Location: Oregon
|
| Posted: Sun Feb 02, 2025 10:38 pm Post subject: Re: Starter purchase |
|
|
| ryansdad03 wrote: |
| I am in in need of a new starter for my car. Is there a huge advantage to buying a $250 Bosch starter versus a lesser expensive starter? |
Buy an AutoZone self supporting autostick trans starter and never look back.
They come with a lifetime warrantee. So you'll never have to buy another one if it fails. The are under $200 without a core exchange cost.
_________________
I have learned over the years.
Cheap parts are gonna disappoint you.
Buy Once, Cry Once!
There's never enough time to do it right the first time. But there's always enough time to do it thrice.
GFY's Xevin and VW_Jimbo! |
|
| Back to top |
|
|
zerotofifty
Samba Member
Joined: December 27, 2003
Posts: 3507
|
| Posted: Sun Feb 02, 2025 10:57 pm Post subject: Re: Starter purchase |
|
|
| 67rustavenger wrote: |
| ryansdad03 wrote: |
| I am in in need of a new starter for my car. Is there a huge advantage to buying a $250 Bosch starter versus a lesser expensive starter? |
Buy an AutoZone self supporting autostick trans starter and never look back.
They come with a lifetime warrantee. So you'll never have to buy another one if it fails. The are under $200 without a core exchange cost. |
Aint the auto stick only in 12 volt flavor?
and no, an expensive Bosch new starter is not needed.
you need to ask, 12 volt or 6 volt, and of course which flywheel you have. Some folks like me have a 6 volt flywheel and 6 volt starter, but run it on 12 volts power.
there are some rare instances of a 12 volt starter converted to work on a 6 volt flywheel.
the two types of flywheels have different gear pattern, so you need the correct starter motor gear to mesh with the flywheel you got. VW changed that gear pattern at the time they changed from 6 to 12 volts in 1967*
* however VW did make a rarish 12 volt system on some early car i believe that used the 6 volt gear pattern. Porsche 356 also could come with this set up or folks converted on their own.
I am a bit fuzzy on these details, smarter folks may correct me.
but you need to select the voltage and the gear pattern of the starter.
some also run the 6 volt system starter with a 12 volt solenoid when running on 12 volts, as this reduces the wear on the gears during meshing when running 12 volts on a 6 volt starter.
later bigger engines had a bigger clutch and most all those flywheels are 12 volt gear pattern, although there was a Bus (Micobus) big clutch flywheel that was also 6 volt gear pattern. folks that keep the 6 volt system, but build a bigger engine that needs the bigger clutch will use this Bus flywheel.
But oft you can find some just fine used starters for little money, no need to break the bank on this. |
|
| Back to top |
|
|
OldSchoolVW's
Samba Member
Joined: July 03, 2020
Posts: 1324
Location: San Diego
|
| Posted: Sun Feb 02, 2025 11:13 pm Post subject: Re: Starter purchase |
|
|
6v or 12v?
If 6v, you might want to have yours rebuilt or consider this one from NAPA (lifetime warranty ... $95).
https://www.napaonline.com/en/p/RAY2444237
If you decide on the 6v remanufactured one from NAPA, keep your old one. 6v components are getting harder to find and a rebuildable core is worth keeping, especially if it is an original Bosch unit.
_________________
Tom
"Following distance is proportional to IQ."
"If you don't do it this year, you'll be one year older when you do." Warren Miller
"Research is what I'm doing when I don't know what I'm doing." Wernher von Braun
'63 Beetle Sedan
'69 Beetle Sunroof
'70 Beetle Sedan
'73 Type 3 Fastback
Last edited by OldSchoolVW's on Mon Feb 03, 2025 8:23 am; edited 1 time in total |
|
| Back to top |
|
|
scrivyscriv
Samba Electrician
Joined: October 04, 2011
Posts: 3320
Location: Memphis
|
| Posted: Mon Feb 03, 2025 12:39 am Post subject: Re: Starter purchase |
|
|
Local generator/starter/motor/armature rebuilding shops -whatever flavor they advertise - can do a good rebuild on your stock starter. If you're not pressed for time, consider bringing yours by a shop and ask them about it.
_________________
Robert in Memphis
Dünkelgrügen 1967 Java Green bug thread
Engine rebuild thread
If you're ever in the Memphis area, you are welcome to stop by for advice and help. |
|
| Back to top |
|
|
pantone149
Samba Member
Joined: August 19, 2004
Posts: 1031
Location: Mt. Shasta
|
| Posted: Fri Feb 07, 2025 1:49 pm Post subject: Re: Starter purchase |
|
|
| What scrivyscriv says. That way you are 100% certain everything goes back together as expected. No mis-aligned anything. |
|
| Back to top |
|
|
ZEKE65
Samba Member
Joined: December 16, 2018
Posts: 341
Location: Right Coast, Florida
|
| Posted: Wed May 21, 2025 3:32 am Post subject: Re: Starter purchase |
|
|
Just bought a new Bosch starter SR15N from Amazon for my beetle. The one they sent does not have the notches to work with the d headed bolt, so you need two people to tighten the bolt. Not sure if all new Bosch are this way, but J Bugs says theirs are also. New Chinese engineering. Sent it back and bought a rebuilt from O'Rieleys.
_________________
1965 VW Sedan, 1968 C10 Step BB, 99 C5
Last edited by ZEKE65 on Sat May 24, 2025 6:05 am; edited 1 time in total |
|
| Back to top |
|
|
Cusser
Samba Member
Joined: October 02, 2006
Posts: 32842
Location: Hot Arizona
|
| Posted: Wed May 21, 2025 6:44 am Post subject: Re: Starter purchase |
|
|
| ZEKE65 wrote: |
| Just bought a new Bosch starter from Amazon for my beetle. The one they sent does not have the notches to work with the d headed bolt, so you need two people to tighten the bolt. Not sure if all new Bosch are this way, but J Bugs says theirs are also. |
Was this a 6-volt or 12 volt starter?
| ZEKE65 wrote: |
| Sent it back and bought a rebuilt from O'Rieleys. |
O'Reilly's is even better than O'Rieleys !!!
_________________
1970 VW (owned since 1972) and 1971 VW Convertible (owned since 1976), second owner of each. The '71 now has the 1835 engine, swapped from the '70. Second owner of each. 1988 Mazda B2200 truck, 1998 Frontier, 2014 Yukon, 2004 Frontier King Cab. All manual transmission except for the Yukon. http://www.thesamba.com/vw/forum/album_page.php?pic_id=335294 http://www.thesamba.com/vw/forum/album_page.php?pic_id=335297 |
|
| Back to top |
|
|
matthew henricks
Samba Member
Joined: January 02, 2002
Posts: 1315
Location: So. Cal
|
|
| Back to top |
|
|
chrisflstf
Samba Member
Joined: February 10, 2004
Posts: 3977
Location: San Diego
|
| Posted: Wed May 21, 2025 9:19 am Post subject: Re: Starter purchase |
|
|
Rockauto has automatic starters for $43, plus 10 for core charge
Fyi... auto starters have high failure rate for solenoids. They arent same as manuals and nobody makes replacements. |
|
| Back to top |
|
|
zerotofifty
Samba Member
Joined: December 27, 2003
Posts: 3507
|
| Posted: Wed May 21, 2025 2:29 pm Post subject: Re: Starter purchase |
|
|
| Cusser wrote: |
| ZEKE65 wrote: |
| Just bought a new Bosch starter from Amazon for my beetle. The one they sent does not have the notches to work with the d headed bolt, so you need two people to tighten the bolt. Not sure if all new Bosch are this way, but J Bugs says theirs are also. |
Was this a 6-volt or 12 volt starter?
| ZEKE65 wrote: |
| Sent it back and bought a rebuilt from O'Rieleys. |
O'Reilly's is even better than O'Rieleys !!! |
Oh Really??????
_________________
Sorry About That Chief.
Give Peace a Chance.
Words to live by. |
|
| Back to top |
|
|
ZEKE65
Samba Member
Joined: December 16, 2018
Posts: 341
Location: Right Coast, Florida
|
| Posted: Wed May 21, 2025 4:15 pm Post subject: Re: Starter purchase |
|
|
12 volt, believe that my problem was the solenoid, and the three different starters that I looked at all had a different type solenoid on them. Could not find a source just for the solenoid.
_________________
1965 VW Sedan, 1968 C10 Step BB, 99 C5 |
|
| Back to top |
|
|
tasb
The Distributor Distributor
Joined: April 27, 2002
Posts: 6665
Location: Pentwater, Michigan
|
| Posted: Wed May 21, 2025 8:47 pm Post subject: Re: Starter purchase |
|
|
Have you tried doing a classifieds search here on TheSamba?
_________________
Roads Scholar
1957 Kombi low mileage 36 hp governor equipped M 178 Slow Drag Winner 2014, 2015, 2018
1965 hardtop Deluxe Microbus owned since 1990 M 620 factory 12 v 1500cc
1961 (October)Single Cab- Road Trip Workhorse
Member# 2059 |
|
| Back to top |
|
|
Wayne S. Johnson
Samba Member
Joined: April 12, 2006
Posts: 1295
Location: GILROY, CA
|
|
| Back to top |
|
|
aquifer
Samba Member
Joined: August 30, 2021
Posts: 265
Location: Nebraska
|
| Posted: Fri May 23, 2025 10:23 am Post subject: Re: Starter purchase |
|
|
| scrivyscriv wrote: |
| Local generator/starter/motor/armature rebuilding shops -whatever flavor they advertise - can do a good rebuild on your stock starter. If you're not pressed for time, consider bringing yours by a shop and ask them about it. |
This. If your starter is original to the car, you get the benefit of retaining it. There is some satisfaction to that, I've found.
_________________
Parts needed:
Front & rear NOS or used OEM door panels for a '67 in the original Gazelle color (dark tan/light brown). |
|
| Back to top |
|
|
|
