Tristar Eric
Samba Member


Joined: July 25, 2004
Posts: 1262
Location: Portland, Or
Tristar Eric is offline
PostPosted: Fri Oct 16, 2015 8:55 pm    Post subject: Reply with quote
A while ago, I made hubs that have 5x130 pattern and take the 993TT brakes. They use stock vanagon bearings.
The problem with the kit was the expense. Maybe it's worth revisiting?

Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.

_________________
Vanagon/Transporter flares here: www.terrawagen.com
[email protected]
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
ALIKA T3
Samba Member


Joined: July 30, 2009
Posts: 7280
Location: Honolulu,Hawaii and France
ALIKA T3 is offline
PostPosted: Fri Oct 16, 2015 9:32 pm    Post subject: Reply with quote
>Beauty Cool
_________________
Silicone Steering Boots and 930 Cv boots for sale in the classifieds.
Syncro transmission upgrade parts in the Classifieds.
Subaru EJ22+UN1 5 speed transmission
http://www.thesamba.com/vw/forum/viewtopic.php?t=416343
Syncro http://www.thesamba.com/vw/forum/viewtopic.php?t=4...num+gadget
Back to top
View user's profile Send private message Gallery Classifieds Feedback
240Gordy
Samba Member


Joined: May 15, 2008
Posts: 2354
Location: Vancouver, BC
240Gordy is offline
PostPosted: Sat Oct 17, 2015 2:26 am    Post subject: Reply with quote
And deng chow ping did some porsche set up as well but those are the only custom hubs. Very nice but likely will make the typical vanagon owner feint at the cost.
_________________
Tencentlife said,
"So, now that you know what you're doing, go to town."
2010 GOLF TRENDLINE 2.5
1985 GL now with more! a 2.1L
H&R SPORT(RED) Springs FRONT , SLAM SPECIALTIES RE6 AIRBAGS REAR
Back to top
View user's profile Send private message Gallery Classifieds Feedback
silverbulletuk
Samba Member


Joined: February 02, 2010
Posts: 206
Location: NW Surrey, UK
silverbulletuk is offline
PostPosted: Mon Oct 19, 2015 6:12 am    Post subject: Reply with quote
Re: rear drum-in-disc, I understand that Oettinger used BMW 7-series (E28) and possibly Benz parts. IIRC the front used early M3 (E30) calipers and an early Sprinter disc.
_________________
1986 syncro twin-slider rhd, 3.2S Oettinger wbx6
1990 SA Microbus - Supercharged wbx going in with UN-1 trans.
www.025motorsport.com
Back to top
View user's profile Send private message Gallery Classifieds Feedback
greggearhead
Samba Member


Joined: June 20, 2004
Posts: 579
Location: Colorado Springs, CO
greggearhead is offline
PostPosted: Mon Oct 19, 2015 6:26 am    Post subject: Reply with quote
Tristar Eric wrote:
A while ago, I made hubs that have 5x130 pattern and take the 993TT brakes. They use stock vanagon bearings.
The problem with the kit was the expense. Maybe it's worth revisiting?

Image may have been reduced in size. Click image to view fullscreen.

Image may have been reduced in size. Click image to view fullscreen.



I would say, yes - worth revisiting.

240 Gordy, you are probably right, but I don't think the typical Vanagon owner is going to want or need large Porsche brakes. This is more for the 'performance' van crowd that has a lot more power and wants more brake to match, and a Porsche bolt pattern at the same time. I've got $350 in just adapters to run Porsche wheels. That's a lot of money for just running different wheels - that cost helps offset the total dollar investment in a setup with a custom or modified hub somewhat.
_________________
1972 Porsche 911E Hot Rod (3.4 Turbo)
1973 VW 412
1979 Audi Fox GTI
2002 Eurovan

Period Lights, VW & Porsche wheels and Recaro/Scheel Seats for sale

https://www.facebook.com/greggearhead

http://greggearhead.com/soco-swap---september-vw-swap-meet.html
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
ALIKA T3
Samba Member


Joined: July 30, 2009
Posts: 7280
Location: Honolulu,Hawaii and France
ALIKA T3 is offline
PostPosted: Mon Aug 08, 2016 7:27 pm    Post subject: Re: Porsche Hub/Rotor on a Vanagon Spindle? Reply with quote
Hi Guys!

I've been cruising bored on computer lately with a half broken neck, so my gears are spinning in the head Laughing

I looked into using the Bus 64-79 front hub, but it's not possible unless there's some meat to machine the bore of the inner bearing.

The inner bearings on T25 are 41x68, 113517185C
The inner bearings on buses are 31.75x59, 211405625

We cannot find a bearing that would work being 41x59, or close to, while machining the bore in the hub for the O.D of such bearing.

The outer bearing is not a problem, since the bearing part number for buses and early T25 spindles is 211405645D, 19x45, knowing it could be interchanged with the later spindle bearing 251405645B 22x45.

One thing to consider too is the distance betwwen outer bearing race and inner bearing race.....

While it's interesting, the Porsche 944 and many other cars are using that same bus inner bearing while having a hub, like a Jaguar XJ6 for instance.
Less options for the inner Vanagon T25 bearing though (113517185C) Confused

Back to machining rotors I guess uh?

For people with early spindle fitment problems with kits on the market, you just need an old rotor to machine into a hub from a later vanagon, that should do it.

Here is the list of cars that can take such inner bus bearing

1974 BMW 2002tii
1969-1973 BMW 2800
1969-1971 BMW 2800CS
1971-1974 BMW 3.0CS
1974 BMW 3.0CSi
1971-1974 BMW 3.0S
1976 BMW 3.0Si
1977-1979 BMW 320i
1979-1981 BMW 528i
1975-1978 BMW 530i
1977 BMW 630CSi
1978 BMW 633CSi
1972-1974 BMW Bavaria
1989-1991 Hyundai Sonata
1990-1992 Infiniti M30
1970-1971 Jaguar XJ
1972-1977 Jaguar XJ6
1994-1997 Mazda B2300
1998-1999 Mazda B2500
1994-1999 Mazda B3000
1994-1999 Mazda B4000
1976-1978 Mazda Cosmo
1991-1994 Mazda Navajo
1963-1965 Mercedes-Benz 190C
1984-1989 Mercedes-Benz 190D
1963-1965 Mercedes-Benz 190DC
1984-1993 Mercedes-Benz 190E
1966-1968 Mercedes-Benz 200
1966-1967 Mercedes-Benz 200D
1968-1973 Mercedes-Benz 220
1968-1973 Mercedes-Benz 220D
1960-1965 Mercedes-Benz 220S
1960-1965 Mercedes-Benz 220SE
1966-1976 Mercedes-Benz 230
1966-1967 Mercedes-Benz 230S
1963-1966 Mercedes-Benz 230SL
1974-1976 Mercedes-Benz 240D
1968-1972 Mercedes-Benz 250
1971-1972 Mercedes-Benz 250C
1966-1967 Mercedes-Benz 250S
1966-1967 Mercedes-Benz 250SE
1967 Mercedes-Benz 250SL
1987-1989 Mercedes-Benz 260E
1973-1976 Mercedes-Benz 280
1973-1976 Mercedes-Benz 280C
1968-1971 Mercedes-Benz 280S
1968-1973 Mercedes-Benz 280SE
1968-1973 Mercedes-Benz 280SEL
1968-1971 Mercedes-Benz 280SL
1985 Mercedes-Benz 300CD
1988-1993 Mercedes-Benz 300CE
1975-1993 Mercedes-Benz 300D
1986-1993 Mercedes-Benz 300E
1985 Mercedes-Benz 300SD
1986-1987 Mercedes-Benz 300SDL
1988-1989 Mercedes-Benz 300SE
1965-1989 Mercedes-Benz 300SEL
1985-1987 Mercedes-Benz 300TD
1988-1993 Mercedes-Benz 300TE
1981-1985 Mercedes-Benz 380SL
1981 Mercedes-Benz 380SLC
1973-1980 Mercedes-Benz 450SL
1973-1980 Mercedes-Benz 450SLC
1984-1985 Mercedes-Benz 500SEC
1984-1985 Mercedes-Benz 500SEL
1986-1991 Mercedes-Benz 560SEC
1986-1991 Mercedes-Benz 560SEL
1986-1989 Mercedes-Benz 560SL
1995 Mercedes-Benz E300
1994-1995 Mercedes-Benz E320
1994-1995 Mercedes-Benz E420
1988 Mitsubishi Galant
1989-1990 Mitsubishi Sigma
1983-1989 Mitsubishi Starion
1977-1988 Nissan 200SX
1970-1973 Nissan 240Z
1974 Nissan 260Z
1975-1978 Nissan 280Z
1979-1983 Nissan 280ZX
1984-1989 Nissan 300ZX
1978-1981 Nissan 510
1974-1976 Nissan 610
1974-1977 Nissan 710
1977-1981 Nissan 810
1975-1978 Nissan B210
1982-1984 Nissan Maxima
1964-1965 Porsche 356C
1964-1965 Porsche 356SC
1965-1989 Porsche 911
1966-1976 Porsche 912
1970-1972 Porsche 914
1977-1988 Porsche 924
1978-1979 Porsche 930
1983-1986 Porsche 944
1975-1985 Toyota Celica
1975-1982 Toyota Corona
1978-1988 Toyota Cressida
1975-1976 Toyota Mark II
1984-1989 Toyota Van
1985-1993 Volkswagen Cabriolet
1972-1974 Volkswagen Campmobile
1985-1992 Volkswagen Golf
1980-1992 Volkswagen Jetta
1975-1984 Volkswagen Rabbit
1980-1984 Volkswagen Rabbit Convertible
1980-1983 Volkswagen Rabbit Pickup
1975-1988 Volkswagen Scirocco
1964-1979 Volkswagen Transporter
1968-1974 Volvo 142
1967-1974 Volvo 144
1968-1974 Volvo 145
1969-1975 Volvo 164
1975-1980 Volvo 242
1975-1980 Volvo 244
1975-1980 Volvo 245
1976-1980 Volvo 262
1976-1980 Volvo 264
1976-1980 Volvo 265
