57 Kab Reconstruction/Restoration

[WrennMetallWerks]

Cruising through more replacement panels this week.

Tackling all the lower portion first.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Pressing rite along … got some more exterior panels melted in.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Sorting out the interior repairs and moving onto exterior skins

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Driver side lower inner and outer panels in the books.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Making some good progress

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Weld …. Grind …. Repeat..

Getting the skins welded on.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Lots of interior areas that needed attention but now we are off to a good start on the exterior skins. Using the laser level to assure alignment as we go.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

The bottom of the convertible only inner rocker support need to be replaced along with pesky rust spot here and there.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Once the doors are hung and alignment is looking good we Locked them in place with a couple tabs. Now it’s time to tackle the inner rocker panels as well as the outer rocker skins, and lower fender panels

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[TRS63]

Fantastic work as always !

Antoine
_________________
Antoine
My 62 ragtop daily driver:
https://www.thesamba.com/vw/forum/viewtopic.php?t=728873
My 914 restoration&lightweight project :
https://www.thesamba.com/vw/forum/viewtopic.php?p=9698432#9698432
Resurrecting a 60 ghia : https://www.thesamba.com/vw/forum/viewtopic.php?t=713906
My 52 Standard Zwitter :
https://www.thesamba.com/vw/forum/viewtopic.php?p=10086685#10086685

[Loren]

Looking great!

[WrennMetallWerks]

Time to hang the doors again and see how the look and fell after the hinges being sorted out.

We will also be leaving them on as we install the adjacent panels so we can make the appropriate gaps as we go.

They look and feel great so we are off to a good start.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

So what I discovered when I first stared rebuilding hinges whether it be bug , bus , or ghia is that 9 times out of 10 just doing the pin is not enough. The slop between the male and female counterparts almost always needs to be built back up and taken back down again to make a tight fit. I use this copper rod when welding so that the center stays nice and circular.

I do not have a mill but have found doing this by hand with the micrometer is very achievable. When it’s all said and done the two halves are very snug.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Building multiple Ghia’s at one time I got to stay

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

Rebuilding with Washburns pins

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

^^^ Hey Dave^^^

Thanks for following along….

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[DaveB9]

There were some horrors lurking in there for sure. Great to see the progress, it all looks fantastic as usual.

[WrennMetallWerks]

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]

The Layout Table doesn’t lie.

Only 0.1 degree difference front to back.

It will stay pinned down like this while we weld the cap on , when we flip it over to do the pan halves we will pin it down again while welding them in.

_________________
⚒ Believe In The Power Of Positive Thinking ⚒
Purpose Over Pleasure 🕊
“Hard Werk ⚒ God First “

[WrennMetallWerks]
