PostPosted: Wed Jun 22, 2011 12:14 pm    Post subject: Porsche 996-05 gearbox and Audi 1,8T in TriStar Reply with quote

We have now install bigger engine in our TriStar.
But it would not be soo funny to do that with original gearbox.
Not the best qualite and not easy to change gear fast either.

But the is not many gearboxes that "fit " into an T3
Renault have one but very rare to find.
Old Porsche 915 gearboxes are there many but they are to old now.

Porsche G50 that Eric have in his TriStar is nice but little to tall.
Soo we drive to an guy we know near us that have Porsche shop
and told him what we have for planes.

Then he show us this Gearbox 96/01 from an Porsche 996 -05.
All dimentions are smaller then original and it have 6 gears and have cable linkage too the gearlevel.

Can it be better. Yes it could because this was not cheap
But itīs only money.

But now to the best. The engine we have install is from Audi 1,8 Turbo -03 And it allmost fit on the gearbox.

Only some small change have to be done.
Audi and Porsche have many parts that is same and when porsche build new engine to this 996 they built Porsche boxer to test this new engine on. And in Boxer they use gearbox from Audi soo thats why this Audi engine allmost fit on Porsche gearbox.

Half of all bolt hole was in right place.
Soo we only have to cut some aluminium peices from an Audi gearbox and cut them into the Porsche gearbox and weld it together.

Easy? Not really it tog 2day to do it.
Lot of job to fit all 5 pieces on right place.

The startengine is mouth on the gearbox on Audi and on Porsche it on the engine.
Soo we have no place to mounth the start engine.

we tok the piece from Audi gearbox and weld it into the Porsche gearbox to soo now we have an start engine to.

Here is some pictures that show how we did.
Best regards Patrik and Erhard

We did the install in an old singelcab first to test out everything.

This is the Porsche gearbox.
Image may have been reduced in size. Click image to view fullscreen.


This is how it look inside.
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Porsche to left and Audi gearbox on right side.
Image may have been reduced in size. Click image to view fullscreen.


Audi gearbox that we cut the 5 pieces we need.
Image may have been reduced in size. Click image to view fullscreen.


This is the plate to hold eveything on right place when we weld the 5 pieces on the Porsche gearbox.
Image may have been reduced in size. Click image to view fullscreen.


Here are the 5 piecec that we cut from the Audi gearbox.
Image may have been reduced in size. Click image to view fullscreen.


The holder to startengine.
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Here are all parts mount to be welded now.
Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik


Last edited by sweden on Sun Jul 03, 2011 10:30 am; edited 2 times in total
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Wed Jun 22, 2011 12:26 pm    Post subject: The clutch Reply with quote

Porsche to left and Audi to right.
Look allmost same.

But the center is not same.
Image may have been reduced in size. Click image to view fullscreen.


Porsche to left and Audi to Right.

Image may have been reduced in size. Click image to view fullscreen.


We cut the center from Porsche and rivet it together with Audi.
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
Jake de Villiers
Samba Member


Joined: October 24, 2007
Posts: 5449
Location: Crescent Beach, BC
Jake de Villiers is offline

PostPosted: Wed Jun 22, 2011 12:46 pm    Post subject: Reply with quote

Nice work Patrik! Wink
_________________
'84 Vanagon GL 1.9 WBX
'86 Westy Weekender Poptop/2.5 Subaru/5 Speed Posi/Audi Front Brakes/16 x 7 Mercedes Wheels - answers to 'Dixie'
@jakedevilliersmusic1
http://sites.google.com/site/subyjake/mydixiedarlin%27
www.crescentbeachguitar.com
www.thebassspa.com
Back to top
View user's profile Send private message Send e-mail Visit poster's website Instagram Gallery Classifieds Feedback
D Clymer
Samba Member


Joined: December 22, 2005
Posts: 2911
Location: Issaquah, WA
D Clymer is offline

PostPosted: Wed Jun 22, 2011 1:05 pm    Post subject: Reply with quote

I've been following your build thread on VWVortex. You've done a really nice job with the whole truck restoration, but I'm most impressed with the way you interfaced the VW inline 4 with the Porsche 996 transmission. It's amazing how similar the bellhousing pattern is. I also like the stock looking gear lever that is actually shifting a cable linkage.

How is the ground clearance below your rear engine crossmember?

Keep up the good work!

David
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Wed Jun 22, 2011 1:58 pm    Post subject: Reply with quote

D Clymer wrote:
I've been following your build thread on VWVortex. You've done a really nice job with the whole truck restoration, but I'm most impressed with the way you interfaced the VW inline 4 with the Porsche 996 transmission. It's amazing how similar the bellhousing pattern is. I also like the stock looking gear lever that is actually shifting a cable linkage.

How is the ground clearance below your rear engine crossmember?

Keep up the good work!

David


Hi David!

Thanks.

This was something we notice first when we had all parts an could see how similar they were.
It was "only" some mount hole that was missing.
Soo it easy to see how close Porsche, Audi VW work.

One of our goals is that everything shall look original out.
That why we keep the original gearlevel.

Wait when you see pictures on the big 3" exhaust it really look like an original muffler to T3 but little bigger.
I have not take pictures on it yet.
But i shall do that.

The ground clearance is bigger now then with the original engine.
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
CHARLIE-DONT-SURF
Samba Member


Joined: November 16, 2007
Posts: 313
Location: Cow County, UK
CHARLIE-DONT-SURF is offline

PostPosted: Wed Jun 22, 2011 3:14 pm    Post subject: Reply with quote

Hi Patrik

After seeing your Tristar 'in the flesh' i think you are very modest and the pics do not do it justice

regards

Elvis
Back to top
View user's profile Send private message Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Thu Jun 23, 2011 1:00 am    Post subject: Reply with quote

CHARLIE-DONT-SURF wrote:
Hi Patrik

After seeing your Tristar 'in the flesh' i think you are very modest and the pics do not do it justice

regards

Elvis


Hi Elvis!

Tanks for that.
I hope to come to Uk this year.
Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Thu Jun 23, 2011 1:03 am    Post subject: Welding of gearbox Reply with quote

Here is all pieces welded.
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Thu Jun 23, 2011 1:10 am    Post subject: Gearbox Reply with quote

Here we test it on the Audi engine.

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Time to put back all parts.
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Finished
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Gearbox and engine.
Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
insyncro
Banned


Joined: March 07, 2002
Posts: 15087
Location: New York
insyncro is offline

PostPosted: Thu Jun 23, 2011 6:18 am    Post subject: Reply with quote

Impressive.

dylan
Back to top
View user's profile Send private message Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Thu Jun 23, 2011 6:27 am    Post subject: Reply with quote

insyncro wrote:
Impressive.

dylan


Thanks Dylan

Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Thu Jun 23, 2011 6:50 am    Post subject: Now all parts is on way in one testcar Reply with quote

We did all the work on an old car to test everything before we mounth in our own TriStar

Original gearlevel and the parts under the car is from Ford to conect the 2 cable to gearbox.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:04 am    Post subject: very late update Reply with quote

Everything was tested in the blue singelcab.

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:13 am    Post subject: All parts shall be overhaueld before they are install it in Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:17 am    Post subject: Driveshaft is from Audi Turbo Reply with quote

Driveshaft is from Audi Turbo and CV joints from Audi Turbo on both sides and they fit right on the Porsche gearbox.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


[/img]http://www.vw-tristar.com/projekt%20559.JPG[img]

Best regards Patrik[/img]
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:20 am    Post subject: Now all parts is in our TriStar Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:23 am    Post subject: Audi 1,8T engine end Porsche 996 gearbox in TriStar Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:26 am    Post subject: Audi 1,8 T engine Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:32 am    Post subject: Projekt closed Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
sweden
Samba Member


Joined: May 30, 2006
Posts: 205
Location: sweden
sweden is offline

PostPosted: Sat Nov 23, 2013 11:34 am    Post subject: Last pictures Reply with quote

Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Image may have been reduced in size. Click image to view fullscreen.


Best regards Patrik

www.vw-tristar.com
Back to top
View user's profile Send private message Send e-mail Visit poster's website Gallery Classifieds Feedback
Display posts from previous:
Reply to topic    Forum Index -> Vanagon All times are Mountain Standard Time/Pacific Daylight Savings Time
Page: 1, 2  Next
Page 1 of 2


Jump to:
You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot vote in polls in this forum

About | Help! | Advertise | Donate | Premium Membership | Privacy/Terms of Use | Contact Us | Site Map
Copyright © 1996-2020, Everett Barnes. All Rights Reserved.
Not affiliated with or sponsored by Volkswagen of America | Forum powered by phpBB
