PostPosted: Fri Sep 30, 2005 5:34 am    Post subject: Barndoor Shift Rod Problems Reply with quote

The shift rod on Chewie's 52 is bent. It's the small diameter bit of the long shift rod that fits into the joiner piece at the front of the bus apparently.

A couple of questions:

Can I remove the shift rod on a barndoor out the front?

Are there any bushes supporting the long shift rod on a barndoor? Can you buy replacements if there are? There aren't any listed in the WW catalogue.

Is the long rod on a barndoor different to later buses? If so, which year did it change?

Has anyone straightened that part of a shift rod before successfully??

Thanks
_________________
EverettB wrote:

I'd be curious to know the length of his tip.


http://scottys-stuff.blogspot.com/
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Clara Premium Member
Samba Member


Joined: June 14, 2003
Posts: 11017

Clara is offline

PostPosted: Fri Sep 30, 2005 8:12 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Scotty wrote:
The shift rod on Chewie's 52 is bent. It's the small diameter bit of the long shift rod that fits into the joiner piece at the front of the bus apparently.

A couple of questions:

Can I remove the shift rod on a barndoor out the front?

Are there any bushes supporting the long shift rod on a barndoor? Can you buy replacements if there are? There aren't any listed in the WW catalogue.

Is the long rod on a barndoor different to later buses? If so, which year did it change?

Has anyone straightened that part of a shift rod before successfully??

Thanks

the early shift rod was changed at vin 307 726 when they introduced a tube the long shift rod slides through, with rubber caps at the ends to keep the dirt out, and 2 plastic bushes attached to the rod, with the holes for the plastic bushes to snap into.

Earlier than that, there was no tube around the shift rod, nor holes in the rod for bushes to snap into. No plastic bushes were used. There were 2 metal bushes used, which snap in place where the rod slides through the frame. To replace these bushes, you must remove the long shift rod, which means you must remove the transmission.
They are shown in the 58 edition of the Parts List (not online)

The early tubeless style bus is prone to funky shifting on muddy roads due to grime getting between the rod and the bushes.

You can use a rod from a bus up to chassis 835 087, from a bus that used the two screw front coupler. One from a 307 xxx to 835 xxx bus (p/n 214 711 171) will have the two holes, that's all. This version of the part superceded the earlier version.
The pre 307 xxx rod is p/n 211 711 171.

I have never straightened one of those rods, but that doesn't mean it can't be done. I never had a bent one.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Scotty
Samba Member


Joined: July 02, 2003
Posts: 1435
Location: Northampton - Uk
Scotty is offline

PostPosted: Fri Sep 30, 2005 11:57 am    Post subject: Reply with quote

Thanks for your help clara. I was hoping I could get the rod out without major hassle, I guess not.
_________________
EverettB wrote:

I'd be curious to know the length of his tip.


http://scottys-stuff.blogspot.com/
Back to top
View user's profile Send private message Gallery Classifieds Feedback
streetwagens
Samba Member


Joined: May 19, 2005
Posts: 473
Location: Wales, GB
streetwagens is offline

PostPosted: Fri Dec 06, 2013 11:14 am    Post subject: Reply with quote

Further to this, does anyone have any dimensions for a bd shift rod? I'm missing one for the 54 truck and need to make one pretty soon Wink
_________________
To catch a fish, you must first think like a fish....
Back to top
View user's profile Send private message Gallery Classifieds Feedback
52panelvan
Samba Member


Joined: June 07, 2006
Posts: 343

52panelvan is offline

PostPosted: Fri Dec 06, 2013 11:46 am    Post subject: Reply with quote

Scotty wrote:
Thanks for your help clara. I was hoping I could get the rod out without major hassle, I guess not.


you could run it through with a very thin disk near the front under the rear floor and then weld it back together while underneath. With it disconnected both ends you can spin it to weld it up...not ideal but it would work ok if your not keen on pulling the transmission

Would some metal file work to the joiner end not work too?

How does that bit get bent, im interested? Smile
_________________
Swedish Panelvan
March 51, 20-11536 Kempes

Austrian Kohlruss Deluxe
January 54, 20-072397
The Kohlruss Barndoor Restoration - https://www.facebook.com/groups/641684399225180/
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Panelvan
Samba Member


Joined: April 04, 2004
Posts: 83

Panelvan is offline

PostPosted: Sat Dec 07, 2013 5:40 am    Post subject: Reply with quote

Hi

Scotty no more solution for you ,try telepathy !!!!i think Mark gave you the best solution

Dai if you need others....
The long BD shift rod is 158 cm , main diameter is 22 mm and 15 mm for the gearbox coupler area and 15 mm for the short shift rod coupler

The long split 64 shift rod is 165 cm, main diameter 18 mm and 15 mm for gearbox coupler and 20 mm for the short shift rod coupler

You can use a complete(long+short) late split shift rod on a barndoor but you have to narrow the smal shift rod (about 15 cm) and modified the gear shift lever area


Small shift rod end
Image may have been reduced in size. Click image to view fullscreen.


Long shift rod end (coupler with the small)
Image may have been reduced in size. Click image to view fullscreen.




Split shift rod longer than Barndoor
Image may have been reduced in size. Click image to view fullscreen.


Small recess for barndoor VS split
Image may have been reduced in size. Click image to view fullscreen.

_________________
http://rascal.skynetblogs.be/
Back to top
View user's profile Send private message Gallery Classifieds Feedback
streetwagens
Samba Member


Joined: May 19, 2005
Posts: 473
Location: Wales, GB
streetwagens is offline

PostPosted: Mon Dec 09, 2013 7:44 am    Post subject: Reply with quote

Perfect, thanks for the help Pascal! Very Happy

One more question, are the holes for the grub screws 180 degrees out? I think they are but just want to confirm before finishing the one I'm making off! I havent got a front shift rod to offer up to it at the moment either! Laughing
_________________
To catch a fish, you must first think like a fish....
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Terry Gaudet Premium Member
Samba Member


Joined: March 11, 2004
Posts: 303
Location: New Brunswick, Canada
Terry Gaudet is offline

PostPosted: Mon Mar 12, 2018 3:21 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Hey Steetwagens, I am also looking for the answer to the same question. I will be building a long shift rod using the original and parts from another one. I need to confirm the total length, from end to end and also if the grub screw notches are 180 degrees apart.

One more question, if I am installing a tunnel type transmission in place of the split case style, does this change the shift rod length?
_________________
Terry Gaudet

1950 Beetle Standard
1952 Beetle Zwitter
1952 Barndoor
1955 Kombi
1955 Canadian Custom
1956 Canadian Custom
1956 Kombi
1959 Double Cab
1960 Euro Sunroof
1962 Porsche 356 S90 vert
1967 Beetle
1967 Beetle Convertible
Back to top
View user's profile Send private message Gallery Classifieds Feedback
joshbuchan
Samba Member


Joined: April 12, 2007
Posts: 708
Location: victoria bc canada
joshbuchan is offline

PostPosted: Sun Mar 18, 2018 6:07 pm    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

We been making new shift rods out of 3/4 chromoly.... cut out old ends and, spin in lathe and weld in nice new straight tube. Scarface shifts like butter!
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Terry Gaudet Premium Member
Samba Member


Joined: March 11, 2004
Posts: 303
Location: New Brunswick, Canada
Terry Gaudet is offline

PostPosted: Fri Mar 23, 2018 10:47 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Hey Josh,

That was my next option. So how do you line up the notches? Do you simply put trans in neutral and shifter in middle straight position and go tack in the ends?
_________________
Terry Gaudet

1950 Beetle Standard
1952 Beetle Zwitter
1952 Barndoor
1955 Kombi
1955 Canadian Custom
1956 Canadian Custom
1956 Kombi
1959 Double Cab
1960 Euro Sunroof
1962 Porsche 356 S90 vert
1967 Beetle
1967 Beetle Convertible
Back to top
View user's profile Send private message Gallery Classifieds Feedback
joshbuchan
Samba Member


Joined: April 12, 2007
Posts: 708
Location: victoria bc canada
joshbuchan is offline

PostPosted: Fri Mar 23, 2018 6:13 pm    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

No we made a jig off of the originals before cutting up.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Terry Gaudet Premium Member
Samba Member


Joined: March 11, 2004
Posts: 303
Location: New Brunswick, Canada
Terry Gaudet is offline

PostPosted: Mon Apr 02, 2018 4:56 pm    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Ok thanks Josh.
_________________
Terry Gaudet

1950 Beetle Standard
1952 Beetle Zwitter
1952 Barndoor
1955 Kombi
1955 Canadian Custom
1956 Canadian Custom
1956 Kombi
1959 Double Cab
1960 Euro Sunroof
1962 Porsche 356 S90 vert
1967 Beetle
1967 Beetle Convertible
Back to top
View user's profile Send private message Gallery Classifieds Feedback
marius71
Samba Member


Joined: July 22, 2012
Posts: 16
Location: Switzerland
marius71 is offline

PostPosted: Tue May 01, 2018 2:53 pm    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Another question to the same topic:

If I have this coupler postion in neutral, I guess I have a problem.
Any known issues on this?
Help very appreciated...
Thanks.

Image may have been reduced in size. Click image to view fullscreen.

_________________
--------- VW ---------
52 BD Type 221
and some others
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
marius71
Samba Member


Joined: July 22, 2012
Posts: 16
Location: Switzerland
marius71 is offline

PostPosted: Wed May 02, 2018 4:09 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

To be more specific, I can't switch to 2rd and 4th because it touches the rim and the stick touches the bench.
There isn't anything where I can change the shift rod length, is it?
Everything looks stock. I still have the rear coupling with open rubber section.
Anyone any comment? Thanks a lot.
_________________
--------- VW ---------
52 BD Type 221
and some others
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Lazaa
Samba Member


Joined: January 03, 2011
Posts: 208
Location: Voiron, France
Lazaa is offline

PostPosted: Wed May 02, 2018 4:43 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Any chance it is a reproduction cab floor ?.... Rolling Eyes
If so I'd bet the hole for the gear lever is not at the correct position.
_________________
Check out www.AirMapp.com to localize VW enthusiats all over the world, events, professionnals, camping spots... or just to read the blog !
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
marius71
Samba Member


Joined: July 22, 2012
Posts: 16
Location: Switzerland
marius71 is offline

PostPosted: Wed May 02, 2018 11:19 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Indeed. It is a later floor.
Unfortunately I don't have any reference measures or funky green panels of a BD to check this.

This is the position of the front shift rod in 2nd gear....


Image may have been reduced in size. Click image to view fullscreen.

_________________
--------- VW ---------
52 BD Type 221
and some others
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
marius71
Samba Member


Joined: July 22, 2012
Posts: 16
Location: Switzerland
marius71 is offline

PostPosted: Wed May 02, 2018 11:39 am    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

I even have these weird american units on my tape Very Happy

Could that measure be ok or is it far from correct?
I assume that the vertical sheet metal position is correct in relation to the chassis.
Thanks for help.

Image may have been reduced in size. Click image to view fullscreen.

_________________
--------- VW ---------
52 BD Type 221
and some others
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
newa
Samba Member


Joined: June 27, 2008
Posts: 13
Location: Portsmouth, UK
newa is offline

PostPosted: Wed May 02, 2018 12:01 pm    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Looks too far back.

Mine is around 55mm to the back of the big hole and 110mm to the front

This is RHD, assume it no difference for LHD

Image may have been reduced in size. Click image to view fullscreen.


Alex
_________________
Buying Barndoor parts & panels, RHD 54 Kombi in resto.
Back to top
View user's profile Send private message Gallery Classifieds Feedback
marius71
Samba Member


Joined: July 22, 2012
Posts: 16
Location: Switzerland
marius71 is offline

PostPosted: Wed May 02, 2018 12:19 pm    Post subject: Re: Barndoor Shift Rod Problems Reply with quote

Hey Alex

Thousand thanks, that helps me a lot Very Happy

... and these guys got a bank-roll for their welding Evil or Very Mad
_________________
--------- VW ---------
52 BD Type 221
and some others
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Display posts from previous:
Reply to topic    Forum Index -> Split Bus - Barndoor All times are Mountain Standard Time/Pacific Daylight Savings Time
Page 1 of 1


Jump to:
You cannot post new topics in this forum
You cannot reply to topics in this forum
You cannot edit your posts in this forum
You cannot delete your posts in this forum
You cannot vote in polls in this forum

About | Help! | Advertise | Donate | Premium Membership | Privacy/Terms of Use | Contact Us | Site Map
Copyright © 1996-2018, Everett Barnes. All Rights Reserved.
Not affiliated with or sponsored by Volkswagen of America | Forum powered by phpBB
