| Author |
Message |
1ghia
Samba Member
Joined: January 11, 2008
Posts: 162
Location: Houston
|
 Posted: Thu May 15, 2014 7:47 pm Post subject: |
 |
|
The blades I ordered should be here saturday or Monday. I saw that KGPR had the shafts but I posted in the classifieds as WTB so that maybe I can find someone with the left blade and both shafts, to buy all at once. I will see what I can get. If nothing comes up, I will buy the shafts from KGPR and just keep searching the classifieds for the wiper arm.
mfitzsimor- thanks for the info. I do not know the first thing about welding, so thats out. LOL New ones or used ones are what I am going to go with.
Thanks again for the help. |
|
| Back to top |
|
 |
retrowagen
Samba Member
Joined: October 11, 2004
Posts: 1857
|
| Posted: Thu May 15, 2014 3:40 pm Post subject: |
|
|
Beetle arms and blades are shorter than the Type 14's, as the Beetle windshield is a great deal less tall, and more upright.
A KG's left side wiper blade shouldn't overshoot the rubber windscreen seal - that arm either has the wrong bend to it, or is fastened one spline wrong.
The earlier style arms and blades are even harder to find. The arms are similar to the old SWF Type 2 or Porsche 356 arms and bases, but not quite identical. The blades are the same as used on certain models of 356, so NOS prices are ionospheric, maybe even exospheric!
_________________
David Ruby
President, Karmann-Ghia World Club |
|
| Back to top |
|
|
mfitzsimor
Samba Member
Joined: May 09, 2004
Posts: 171
Location: Portland, OR
|
| Posted: Thu May 15, 2014 1:33 pm Post subject: |
|
|
1ghia,
Per what others have told you, the actual shaft that the wiper arm attaches too on the right side is damaged. Either replace it with a new shaft or add metal to it carefully with a mig welder and grind/file to original shape.
Something else is wrong with your left one and you will have to remove the nut/washer/seals on the top side to figure it out. The portion of the threaded tube that the shaft rotates in that appears above the nut (and the cowl area of the car) should be the same on both sides.
The left tube sticks up far enough to enclose almost all of the shaft and that's what's preventing you from attaching an arm to it. It may also be damaged and may even be missing some of its length, but you first have to get the threaded tube adjusted correctly and you do it with a second nut on the tube that's under the hood.
I took my 69's entire wiper assembly out and apart, cleaned it, greased it, added metal to both shaft tips and after I installed it, about 3mm of the threaded tube shows above the nut.
They are now quieter and work much more efficiently than they did before.
_________________
portland, or
69 cypress green ghia coupe
82 vanagon TD
86 quantum syncro |
|
| Back to top |
|
|
c21darrel
Samba Member
Joined: January 22, 2009
Posts: 8237
Location: San Dimas
|
|
| Back to top |
|
|
1ghia
Samba Member
Joined: January 11, 2008
Posts: 162
Location: Houston
|
| Posted: Wed May 14, 2014 6:12 pm Post subject: |
|
|
just checked, and there are some for years up to 67 and then from 70+. LOL how much different are the ones for a 69?
Just checked and there are different ones for my year but not sure what the difference is. |
|
| Back to top |
|
|
c21darrel
Samba Member
Joined: January 22, 2009
Posts: 8237
Location: San Dimas
|
|
| Back to top |
|
|
1ghia
Samba Member
Joined: January 11, 2008
Posts: 162
Location: Houston
|
| Posted: Wed May 14, 2014 5:56 pm Post subject: |
|
|
| Well, the side thats bigger doesn't allow the wiper to fit over the top of it. The wiper fits the smaller one with no problem. |
|
| Back to top |
|
|
NOVA Airhead
Samba Member
Joined: July 20, 2005
Posts: 5225
Location: Richmond, VA
|
| Posted: Wed May 14, 2014 5:09 pm Post subject: |
|
|
| 1ghia wrote: |
I ordered a right wiper from jbugs (I think) and they did not have the left in stock. I was placing it on the car and thought I should place it on the driver side just so I can pass inspection and then switch it back to the correct side. Problem is, the mounting is a different size. Is every one like this or is this just a quick fix by previous owner? I uploaded pics, the smaller one is right side (passenger) and the bigger one is left side. 69 coupe
And has anyone found a place that has these wipers in stock? Both sides or at least left side? I can't find it anywhere. Thanks to this thread, my blades will be coming in this weekend from sierra madre collection |
They should be the same. The one side looks damaged.
_________________
Ghia Owner Emeritus |
|
| Back to top |
|
|
1ghia
Samba Member
Joined: January 11, 2008
Posts: 162
Location: Houston
|
| Posted: Wed May 14, 2014 4:27 pm Post subject: |
|
|
I ordered a right wiper from jbugs (I think) and they did not have the left in stock. I was placing it on the car and thought I should place it on the driver side just so I can pass inspection and then switch it back to the correct side. Problem is, the mounting is a different size. Is every one like this or is this just a quick fix by previous owner? I uploaded pics, the smaller one is right side (passenger) and the bigger one is left side. 69 coupe
And has anyone found a place that has these wipers in stock? Both sides or at least left side? I can't find it anywhere. Thanks to this thread, my blades will be coming in this weekend from sierra madre collection |
|
| Back to top |
|
|
sputnick60
Samba Moderator
Joined: July 22, 2007
Posts: 4119
Location: In Molinya Orbit
|
|
| Back to top |
|
|
boblar
Samba Member
Joined: November 28, 2013
Posts: 2
Location: Cambridge, UK
|
| Posted: Thu Apr 24, 2014 4:03 pm Post subject: |
|
|
| does anyone know if these will fit a 64? need some but not sure if they'll fit my car |
|
| Back to top |
|
|
mcdonaldneal
Samba Member
Joined: June 13, 2013
Posts: 2731
Location: Gullane, Scotland
|
|
| Back to top |
|
|
KarmannMarco
Samba Member
Joined: January 03, 2010
Posts: 263
Location: Woodland Park CO
|
| Posted: Wed Nov 14, 2012 10:09 am Post subject: |
|
|
13 inch , and they do take a 6mm arm.
I have lots of 11 inch as well but all either bayonet or dip tip style attachment. |
|
| Back to top |
|
|
Ian Godfrey
Samba Member
Joined: September 25, 2006
Posts: 1206
Location: Melbourne Australia
|
| Posted: Tue Nov 13, 2012 5:21 pm Post subject: |
|
|
karmann marco, are these 12'' or 13'' blades? (earlier or later KG),
I assume they take the 6mm wand.
they look good  |
|
| Back to top |
|
|
KarmannMarco
Samba Member
Joined: January 03, 2010
Posts: 263
Location: Woodland Park CO
|
| Posted: Tue Nov 13, 2012 1:07 pm Post subject: |
|
|
Here's the wiper blades I have for my Ghia.
They are new old stock SWF units. I'm in the vintage Italian car business and these were used on a few Lancia models. We've also sold these to a few 911 people.
|
|
| Back to top |
|
|
carl4x4
Samba Member
Joined: March 20, 2012
Posts: 679
Location: United Kingdom
|
| Posted: Mon Nov 12, 2012 2:31 pm Post subject: |
|
|
Thanks for the info, I measured it at 10.5" so you were right. I have just emailed the seller for a quote to ship to the UK.
Cheers |
|
| Back to top |
|
|
Ian Godfrey
Samba Member
Joined: September 25, 2006
Posts: 1206
Location: Melbourne Australia
|
| Posted: Mon Nov 12, 2012 3:00 am Post subject: |
|
|
Carl, I only know about late wipers, say 67 on. The pic looks like a Right side 67 - 69 which has a noticable sideways bend 1 1/2" from the hook. the length should be 10 1/2" over all (end to end). the matching Left is longer, 11 1/2" overall with just the tiniest of a bend 1 1/2" back from the hook. Most arms are stamped on the 'wand' just near the rivet on the top, L or R.
the wand is 6mm wide and 2 mm thick.
There are very similar beetle arms (shorter) and T3/912 arms (longer)
there is an nos left for sale on the Samba today |
|
| Back to top |
|
|
carl4x4
Samba Member
Joined: March 20, 2012
Posts: 679
Location: United Kingdom
|
| Posted: Sun Nov 11, 2012 3:02 pm Post subject: |
|
|
Can anyone tell if this wiper is for a Karmann Ghia? if so which side is it for? (so I know which one to buy for the other side )
|
|
| Back to top |
|
|
cseay1
Samba Member
Joined: March 22, 2012
Posts: 1341
Location: Elkwood VA
|
| Posted: Thu Oct 25, 2012 7:24 pm Post subject: |
|
|
| As far as I know no one makes a 13" beam blade. You may be able to get a longer one and cut it down. I have cut down early wiper blades on chopped top street rods, but I've never really looked closely at one of the beam blades to see if that's possible. |
|
| Back to top |
|
|
ivwshane
Samba Member
Joined: May 19, 2011
Posts: 1920
Location: Sacramento ca
|
| Posted: Thu Oct 25, 2012 6:16 pm Post subject: |
|
|
| cseay1 wrote: |
RainX does not make the Latitude in a 13" 9x3 hook. The only blade they offer in that size is the WeatherBeater which is a conventional blade part number RX30213
|
Sorry, what I was asking was: is there another manufacture that makes a similar style wiper as the latitude that will fit the ghia? |
|
| Back to top |
|
|
|
