Lowered notch on stock beam. photos?

[Joefinnie]

New to this site so I’m late to the party. I have bought a 62 notch that needs fixing up. Im wanting to lower it (I know there’s loads about lowering on here).
Beetle beam is an option but can anyone show me photos of a lowered notch on a non narrowed t3 beam? I want to know how low I can go without scrubbing, or should I not bother and just fit a t1 beam? Thanks

[vwfye]

These are 175/55/15s on the front. I have driven this car from Oregon to Kansas and back as well as OR to Co and back... rides well, but if you go that low you have to remove the bump stops or the suspension will be compressed into the stops and it can be jarring

_________________
64 No'back Speedster "Pearl"
LME "Little Giant Killer 3"
1974 Ghia "PUK"

[Erik G]

I'll have to look for pics but almost every slammed notch you will find is a stock beam, the type 1 beam is a relatively new downgrade. They still ride pretty nice slammed on a stock beam

this was I think 4 splines front 3 splines rear, daily driver. It was already lowered and I lowered it more

_________________
Stop dead photo links! Post your photos to The Samba Gallery!

[FASTBACKDON]

Don't insult the type 3 with a Bug beam

You can lower a type 3 low enough with the stock beam
_________________
FUCK CANCER FUCK CANCER FUCK CANCER!!
Mom 25 months of standing up to Cancer R.I.P I miss you so much.

Buy my best friends stuff
http://www.thesamba.com/vw/classifieds/search.php?username=56TIMOTEO

(21:10:42) Jennepher: Russell is our proudest achievment. I feel like Samba created him from a little nugget of crap into a full blown adult.

[Joefinnie]

[mcmscott]

_________________
There are no stupid questions, only stupid people,

68 Ghia
67 T-1
65 Notch
02 Mexican beetle
74 Thing
15 Long travel rail
07 Nomad
05 f-250

[Erik G]

[Joefinnie]

[Joefinnie]

[Erik G]

[Bobnotch]

I know I'm not slammed in this pic, but I'm running 195-60-15's in front, and 205-65-15's in the rear. 2 spline inner drop front, and 50 year sag in the rear. I have too much crap that WILL hit to go lower around here.

I've been to Hershey PA, and out to Joplin Missouri with this car (was cleaning it up to go to Missouri when the pic was taken).

And here's my son's car.It's on 195-50-15's in front and 195-60-15's in the rear, dropped 2 splines in the rear and 3+ in the front.

He's also using dropped link pin bug oil shocks up front, and KYB gas shocks in the rear. It rides really nice too.

And my old 71 while under construction. This is 2 splines down (outer) in front, and 2 splines down in the rear, with 195-60-15's on all 4 corners.

_________________
Bob 65 Notch S with Sunroof
71 Notch ...aka Krunchy; build pics here;
http://www.thesamba.com/vw/forum/viewtopic.php?t=249390 -been busy working
64 T-34 Ghia...aka Wolfie, under construction... http://www.thesamba.com/vw/forum/viewtopic.php?t=412120

[ALLWAGONS]

They look sooooo nice with a stock lowered beam, unlike a type 1 beam that makes the look like shopping carts.
_________________
I'd be UNSTOPPABLE if not for Law Enforcement and PHYSICS.

I recycle old cars and parts, other than when I rot, that's as Green as I am going to get.

Thanks to my Tesla driving neighbors, I feel more relaxed driving my SUBURBAN and old VW's.

Everything sounds good on paper!

[mcmscott]

[theskitzofrantic]

When you lower the rear of these cars is there a way to fix the camber??

[vwfye]

swing axle, not really... IRS, a bit.
_________________
64 No'back Speedster "Pearl"
LME "Little Giant Killer 3"
1974 Ghia "PUK"

[OvalinAz]

If you want to be really low, T-1 is the way to go. also cutting off the lower beam support areas is a must with the conversion. no biggie, cut mine and welded them up flush.
_________________
Dad's 4/55 Oval
8/56 Oval
5/64 French Notchback
12/62 French 11 Window Bus
1970 Subaru 360
Wedge VW
Pandraggers C.C.

[notchboy]

Since we are pulling skeletons out of the closet.

_________________

[theskitzofrantic]

So what’s the lowest you can go without the wheels tilted in all goofey?

[oxsign]

[Mike Fisher]

Do you want to be a pandragger or just lowered some on stock suspension?

https://i.imgur.com/yaF9SVf.jpg
I'm down 2 inner in back & 1 inner up front. Running 185X60 & 205X70 on 5'5" wide Fuchs.
