Author |
Message |
djkeev Samba Moderator
Joined: September 30, 2007 Posts: 32625 Location: Reading Pennsylvania
|
|
Back to top |
|
|
leecat Samba Member
Joined: September 13, 2012 Posts: 773 Location: Regina
|
Posted: Mon Nov 19, 2018 10:13 am Post subject: Re: Spring Style Hose Clamps |
|
|
Yup, totally agree - everyone on here passionately hates screw clamps, but to me screw clamps = good and tight. I figure there are literally 500 things that are going to go wrong on my van before a brand-new screw clamp on a brand-new hose fails, so I use 'em everywhere. |
|
Back to top |
|
|
kamzcab86 Samba Moderator
Joined: July 26, 2008 Posts: 7922 Location: Arizona
|
Posted: Mon Nov 19, 2018 10:18 am Post subject: Re: Spring Style Hose Clamps |
|
|
My cars reside in the dry southwest... spring clamps are far less apt to suffer from corrosion down here. If any clamp is difficult to "unspring" with the special tool or pliers (i.e., it's become stiff), it gets replaced to prevent complete failure while in use.
I'm the opposite: I dislike screw clamps, but use them where/when necessary, and I absolutely abhor pinch clamps.
To each their own.🍻 _________________ ~Kamz
1986 Cabriolet: www.Cabby-Info.com
1990 Vanagon Westfalia: Old Blue's Blog
2016 Golf GTI S
"Real knowledge is to know the extent of one's ignorance." - 孔子 |
|
Back to top |
|
|
vwhammer Samba Member
Joined: May 20, 2006 Posts: 998 Location: Boulder CO.
|
Posted: Mon Nov 19, 2018 10:20 am Post subject: Re: Spring Style Hose Clamps |
|
|
I think I am going to give some of these a try that McMaster-Carr, and I am sure other places, sells.
https://www.mcmaster.com/5462k51
They have several sizes and they are stainless steel. |
|
Back to top |
|
|
joetiger Samba Member
Joined: January 27, 2005 Posts: 5078 Location: denver
|
Posted: Mon Nov 19, 2018 10:28 am Post subject: Re: Spring Style Hose Clamps |
|
|
I recently had the motor out of the syncro and replaced a few hoses and cleaned up/replaced a few pipes in the cooling system. I re-used a bunch of the spring clamps, and two of them let go as soon as the system pressurized. They appeared to have lost their tension after so many years of service. I replaced them with regular screw clamps.
Important to note that a good set of spring clamp pliers is a godsend when dealing with those buggers. _________________ Joe T.
'86 NAHT Vanagon GL Syncro/ supercharged ABA 2.0 "Pigpen"
'04 GTI 1.8T
'04 Golf R32
"get metaphysical with it. if it's simply a means to get to and from places, it will let you down. if it becomes your zen, it can't fail you." -dabaron
"Still, it's good to be afield."--VWagabond
Available Now! Vanagon to Louisiana--A Two-Lane Reckoning Through Past and Present
www.josephtrussell.com |
|
Back to top |
|
|
Jeffrey Lee Samba Member
Joined: February 04, 2014 Posts: 1488 Location: Wisconsin
|
Posted: Mon Nov 19, 2018 11:22 am Post subject: Re: Spring Style Hose Clamps |
|
|
These clamps are little more spendy, but provide the constant-tension necessary for some applications, and unlike the OE spring clamps, will accommodate a range of diameters and can be re-tightened. They're also completely sleeved, so they won't chew up your hoses like a conventional worm-gear clamp. Available in stainless steel for longer life, too. _________________ Camp Westfalia
Camping Tips • Newsletter • Cool Campervan Apparel
www.CampWestfalia.com |
|
Back to top |
|
|
11BC2 Samba Member
Joined: August 27, 2017 Posts: 495 Location: Cool, California
|
Posted: Mon Nov 19, 2018 11:25 am Post subject: Re: Spring Style Hose Clamps |
|
|
Depends on the style of screw clamp. Most folks go for the cheapest type that chew up the rubber hose.
From what I’ve seen, the hose will fail/need replacing before a constant tension clamp fails. And why reuse a hose clamp?? |
|
Back to top |
|
|
IdahoDoug Samba Member
Joined: June 12, 2010 Posts: 10250 Location: N. Idaho
|
Posted: Mon Nov 19, 2018 7:25 pm Post subject: Re: Spring Style Hose Clamps |
|
|
Spring clamps are the spawn of the devil. If the hose swells slightly at the end (like, oh 99.999999% do), then even fully opening it may not get it off. Naturally it will be the one buried up high where you cant get any options. A quality screw clamp is the cure for these evil contrivances. _________________ 1987 2WD Wolfsburg Vanagon Weekender "Mango", two fully locked 80 Series LandCruisers. 2017 Subaru Outback boxer. 1990 Audi 90 Quattro 20V with rear locking differential, 1990 burgundy parts Vanagon. 1984 Porsche 944, 1988 Toyota Supra 5 speed targa, 2002 BMW 325iX, 1982 Toyota Sunrader |
|
Back to top |
|
|
DanHoug Samba Member
Joined: December 05, 2016 Posts: 4790 Location: Bemidji, MN
|
Posted: Mon Nov 19, 2018 7:39 pm Post subject: Re: Spring Style Hose Clamps |
|
|
personally, i like the "constant tension, constant compression" spring clamps. but when i redid my 2.1, i used Wurth Zebras throughout because i couldn't source high quality spring clamps quickly. they have a raised flange outer edge and smooth gear band that doesn't cut rubber.
a story... i toured a major AM transmitter manufacturer's plant years ago and they were showing off a 1 million kilowatt water cooled transmitter destined for the United Arab Emirates. they had intalled hardware store variety 'cheese cutter' clamps on their silicone coolant hoses and i mentioned to the engineer giving the tour they may want to replace those. he looked at me with one of those "Who the F@ck are you?" looks and i could tell nothing registered. to this day, i envision this very expensive transmitter installed in the hot UAE with a million kW of power going thru it and a conductive coolant leak.... i have a hunch they've put in a service call on this. _________________ -dan
60% of what you find on the internet is wrong, including this post.
'87 Westy & '89 Westy both 2.1 4spd
Past projects can be found at--
www.thefixitworkshop.com |
|
Back to top |
|
|
syncrodoka Samba Member
Joined: December 27, 2005 Posts: 12006 Location: Santa Cruz, CA
|
Posted: Mon Nov 19, 2018 7:44 pm Post subject: Re: Spring Style Hose Clamps |
|
|
So you are saying that a rusty, decades old rotten part shouldn't be trusted? |
|
Back to top |
|
|
alaskadan Samba Member
Joined: January 09, 2013 Posts: 1858 Location: anchor pt. alaska
|
Posted: Mon Nov 19, 2018 10:25 pm Post subject: Re: Spring Style Hose Clamps |
|
|
I have both on my van. I used good condition spring clamps I got from a couple of parts vans if I had them. The other camps are decent marine grade screw clamps like the aforementioned McMaster clamps. The only ones that never seeped a little during the heat cycles and winter freezing were the spring clamps. Some of the screw ones did, nothing major. But, after a couple years of service on our roads, half highway half dirt, I mangled a couple of those screw clamps getting them off. |
|
Back to top |
|
|
markswagen Samba Member
Joined: January 28, 2018 Posts: 1038 Location: san diego
|
Posted: Tue Nov 20, 2018 7:57 am Post subject: Re: Spring Style Hose Clamps |
|
|
I prefer the spring type clamps over hose clams.
On fuel lines I use stainless single ear oetiker clamps.
If you have the correct tool the spring clamps are fine, and not the death clamps some make them out to be. _________________ markswagen {mobile mechanic} san diego area all early VW's cared for.
619 201 0310 |
|
Back to top |
|
|
syncrodoka Samba Member
Joined: December 27, 2005 Posts: 12006 Location: Santa Cruz, CA
|
Posted: Tue Nov 20, 2018 9:15 am Post subject: Re: Spring Style Hose Clamps |
|
|
Silicone spray makes sliding spring clamps out of place on the hose easy. If the hose is swollen and won't let go of the clamp then the hose probably needs replacement.
Old seized worm clamps are much worse to remove than neglected spring clamps. |
|
Back to top |
|
|
Busfixer Samba Member
Joined: March 13, 2016 Posts: 29 Location: Midland, Texas
|
Posted: Sat Apr 24, 2021 12:12 pm Post subject: Re: Spring Style Hose Clamps |
|
|
I like spring clamps too.
Here’s a spring clamp tip for installation/removal: put the spring clamp on the fitting before installing the hose. Once you wiggle and twist the hose to reach the spring clamp (which is already past the sealing ridge), squeeze and open the spring clamp with vice grips while wiggling the hose through it. Then properly position the clamp as needed.
A very backwards way to install and remove a hose but seems to work! I’m sure I didn’t invent this method but haven’t heard it mentioned. Hope this helps! Cheers, Busfixer |
|
Back to top |
|
|
dart330 Samba Member
Joined: July 19, 2004 Posts: 454 Location: Houston, TX
|
Posted: Tue Jan 18, 2022 9:01 am Post subject: Re: Spring Style Hose Clamps |
|
|
Do any of the vendors sell a full replacement spring clamp kit? I have been searching but haven't found one.
I need to replace a coolant pipe and would like to update the clamps while I have the system open. Tired of chasing coolant leaks when it gets cold and the screw clamps need re-tightening.
I did find this document on the Old Blues Blog that lists the sizes.
http://oldbluesblog.com/files/VanagonSpringClamps.pdf _________________ Driving a 90 Carat since 2014
Previous Buses: 59 Westy, 60 Westy, 74 Bus, 82 Westy, 85 Westy, 87 Syncro
Checkout my Syncro Video: https://www.youtube.com/watch?v=0JSWhLS7jLY |
|
Back to top |
|
|
dobryan Samba Member
Joined: March 24, 2006 Posts: 16504 Location: Brookeville, MD
|
Posted: Tue Jan 18, 2022 9:15 am Post subject: Re: Spring Style Hose Clamps |
|
|
Busfixer wrote: |
I like spring clamps too.
Here’s a spring clamp tip for installation/removal: put the spring clamp on the fitting before installing the hose. Once you wiggle and twist the hose to reach the spring clamp (which is already past the sealing ridge), squeeze and open the spring clamp with vice grips while wiggling the hose through it. Then properly position the clamp as needed.
A very backwards way to install and remove a hose but seems to work! I’m sure I didn’t invent this method but haven’t heard it mentioned. Hope this helps! Cheers, Busfixer |
That is a great technique! Usually the issue is getting the clamp past the bulge caused by the ridge and you've removed that issue. I like. _________________ Dave O
'87 Westy w/ 2002 Subaru EJ25 and Peloquin TBD
"To travel hopefully is a better thing than to arrive." Robert Louis Stevenson
MD>Canada>AK>WA>OR>CA>AZ>UT>WY>SD
https://www.thesamba.com/vw/forum/viewtopic.php?t=620646
Building a bus for travel in Europe (euroBus)
https://www.thesamba.com/vw/forum/viewtopic.php?t=695371
The Western Syncro build
https://www.thesamba.com/vw/forum/viewtopic.php?t=746794 |
|
Back to top |
|
|
riceye Samba Member
Joined: March 09, 2006 Posts: 1661 Location: Caledonia, WI
|
Posted: Tue Jan 18, 2022 11:09 am Post subject: Re: Spring Style Hose Clamps |
|
|
dart330 wrote: |
Do any of the vendors sell a full replacement spring clamp kit? I have been searching but haven't found one.
I need to replace a coolant pipe and would like to update the clamps while I have the system open. Tired of chasing coolant leaks when it gets cold and the screw clamps need re-tightening.
I did find this document on the Old Blues Blog that lists the sizes.
http://oldbluesblog.com/files/VanagonSpringClamps.pdf |
When I replaced all the rubber hoses and installed stainless pipes last summer, I ordered up all of the clamps from Belmetric. _________________ '87 Westy Weekender - daily driver on salt-free roads
There's gonna be some changes made.
“I find that things usually go well right up until the moment they don't.” - Ahwahnee
"Quality isn't method. It's the goal toward which the method is aimed." - Socrates, later quoted by R.M. Pirsig |
|
Back to top |
|
|
DanHoug Samba Member
Joined: December 05, 2016 Posts: 4790 Location: Bemidji, MN
|
Posted: Tue Jan 18, 2022 11:30 am Post subject: Re: Spring Style Hose Clamps |
|
|
i just purchased a Blue Point HCP-20 spring clamp pliers off eBay to deal with these. they lock down, the jaw tips pivot so the clamp can be grabbed from any angle, and they fit the VW clamps well.
we've all been ting'd by the ear slipping off of the channel lock and whacking a finger at the speed of sound. i've gotten too old to accept the pain. _________________ -dan
60% of what you find on the internet is wrong, including this post.
'87 Westy & '89 Westy both 2.1 4spd
Past projects can be found at--
www.thefixitworkshop.com |
|
Back to top |
|
|
dart330 Samba Member
Joined: July 19, 2004 Posts: 454 Location: Houston, TX
|
|
Back to top |
|
|
riceye Samba Member
Joined: March 09, 2006 Posts: 1661 Location: Caledonia, WI
|
Posted: Tue Jan 18, 2022 11:41 am Post subject: Re: Spring Style Hose Clamps |
|
|
DanHoug wrote: |
i just purchased a Blue Point HCP-20 spring clamp pliers off eBay to deal with these. they lock down, the jaw tips pivot so the clamp can be grabbed from any angle, and they fit the VW clamps well.
we've all been ting'd by the ear slipping off of the channel lock and whacking a finger at the speed of sound. i've gotten too old to accept the pain. |
I love Snap On, but often am limited by the price. This set probably does not have the durability (or guarantee!), but having the different heads and the remote cable was worth the $50.
Astro Pneumatic hose clamp tool
_________________ '87 Westy Weekender - daily driver on salt-free roads
There's gonna be some changes made.
“I find that things usually go well right up until the moment they don't.” - Ahwahnee
"Quality isn't method. It's the goal toward which the method is aimed." - Socrates, later quoted by R.M. Pirsig |
|
