 Posted: Wed Mar 10, 2010 5:23 pm Post subject: Shoddy JCS Rebuild |
 |
|
Long story short I have the engine out of the bus due to head/valve issues. Anyway, the shoddy work got me to questioning the rest of the internals.
Checked end play. 0.012.  Started to clean things up nice and notice this. I assume this is bad. I mean bad. Please cheer me up if I'm wrong but I think this thing just got a whole lot more complicated.
Yes, that is me rotating the #1 bearing by hand. I may be a noob when it comes to engine internals but I'm pretty sure it isn't supposed to do that.
_________________
1971 Karmann Ghia - 1600 DP
1984 Westfalia - 1.9 WBX
Last edited by sped372 on Thu Mar 11, 2010 7:09 am; edited 1 time in total |
|
| Back to top |
|
 |
miniman82
Samba Swamp Donkey
Joined: March 22, 2005
Posts: 9515
Location: Southern Maryland
|
|
| Back to top |
|
|
Lawrence_0485
Samba Member
Joined: March 25, 2007
Posts: 465
Location: Arkansas
|
| Posted: Wed Mar 10, 2010 5:37 pm Post subject: |
|
|
how many miles on this mill? And no it's not supost to be able to turn like that. Has this case been Line board?
_________________
[email protected] |
|
| Back to top |
|
|
gt1953
Samba Member
Joined: May 08, 2002
Posts: 13953
Location: White Mountains Arizona
|
| Posted: Wed Mar 10, 2010 6:28 pm Post subject: |
|
|
Looks like the case is stamped 080 if so it has been bored out about as far as you want to go on a case..
the bearing movement is not good at all.
_________________
Volkswagen: We tune what we drive.
Numbers Matching VW's are getting harder to find. Source out the most Stock vehicle and keep that way. You will be glad you did.
72 type 1
72 Squareback
({59 Euro bug, 62, 63, 67, 68, 69, 73 type ones 68 & 69 type two, 68 Ghia all sold}) |
|
| Back to top |
|
|
sped372
Samba Member
Joined: March 30, 2006
Posts: 653
Location: Waunakee, WI
|
| Posted: Wed Mar 10, 2010 6:48 pm Post subject: |
|
|
Crap, that's what I figured. There's about 12k on this rebuilt longblock purchased from aircooled.net a couple years back. Heads and case have J C S stamped on them so I assume it might have come from these guys roundabout?
http://www.jcsvwparts.com/
Anyway the heads were junk. Valve seats pushed in over burrs. I never could get the adjustments to settle down which is why I pulled the engine to begin with. Appears the seats kept slowly sinking causing my valve lash to tighten. The guides and seats were also machined non-concentrically. I'll try to get some pics up of the shoddy work.
Amazing thing is that the engine was actually running really well. I usually averaged 23mpg in the Westy and it drove fine. Like I said I pulled the engine to diagnose the heads and a continual dribble of oil from the main seal (which totally makes sense now).
So now what. Shortblock? I have new heads already. I suppose I could build up from scratch. This totally shoots an early camping season.
_________________
1971 Karmann Ghia - 1600 DP
1984 Westfalia - 1.9 WBX |
|
| Back to top |
|
|
sped372
Samba Member
Joined: March 30, 2006
Posts: 653
Location: Waunakee, WI
|
| Posted: Wed Mar 10, 2010 7:33 pm Post subject: |
|
|
Here are some shots.
The offending SOB.
Head with seats still in.
What exactly are my valve seats seated against? Shouldn't be able to see this much of a gap should you? Even with my limited experience it just looks bad.
Seat Removed
Oh, well I guess it makes sense that the valve adjustments never quit tightening since there were some nice burrs underneath the seats that I presume kept compressing.
Valve Guide
A bit hard to tell from the photo but the ID and OD are not concentric.
Lash Adjusters.
Seriously, check these things out. There's no way this occurred in 12k miles.
The New GEX?
Looks like they even had trouble stamping their own name.
So yes. Everyone has said it before. You get what you pay for. This engine bought us a couple years but now I want to do it right. Do I dare re-use any of the parts from this one, can measuring them truly prove whether they are of any value? I have developed so much skepticism about this thing that I don't know how much if any hope I should have of salvaging anything from it.
_________________
1971 Karmann Ghia - 1600 DP
1984 Westfalia - 1.9 WBX |
|
| Back to top |
|
|
gooser
Samba Member
Joined: February 21, 2008
Posts: 766
Location: danville virginia
|
| Posted: Wed Mar 10, 2010 7:58 pm Post subject: |
|
|
| these professional engine builders know 20 times as much stuff as i'll ever know but they operate under a different financing structure than i do so i hope i'll do a much better job with my rebuild. aircooled sold you that? |
|
| Back to top |
|
|
sped372
Samba Member
Joined: March 30, 2006
Posts: 653
Location: Waunakee, WI
|
| Posted: Thu Mar 11, 2010 7:10 am Post subject: |
|
|
| gooser wrote: |
| aircooled sold you that? |
I was disappointed. Went through them cause I'd heard good feedback but the longblock was just drop shipped.
_________________
1971 Karmann Ghia - 1600 DP
1984 Westfalia - 1.9 WBX |
|
| Back to top |
|
|
teuton
Samba Member
Joined: April 02, 2003
Posts: 334
Location: Abilene Texas
|
| Posted: Thu Mar 11, 2010 2:34 pm Post subject: |
|
|
Good photography work. Sorry about your engine.
_________________
1965 VW Beetle |
|
| Back to top |
|
|
skills@eurocarsplus
Samba Peckerhead
Joined: January 01, 2007
Posts: 17885
Location: sticksville, ct.
|
| Posted: Thu Mar 11, 2010 8:59 pm Post subject: |
|
|
stuff like this really pisses me off. it's the 'fuck you, pay me' mentality that leaves the consumer holding the bag. i was in the same situation with a T3 years ago (engine was drop shipped.....from GEX) after the 3rd one exploded, the company who sold me the POS built a real nice engine for me. anyway, perhaps ACN may help you out. have you spoken with them?
_________________
| gprudenciop wrote: |
my reason for switching to subaru is my german car was turning chinese so i said fuck it and went japanese....... |
| Jake Raby wrote: |
| Thanks for the correction. I used to be a nice guy, then I ruined it by exposing myself to the public. |
| Brian wrote: |
| Also the fact that people are agreeing with Skills, it's a turn of events for samba history |
|
|
| Back to top |
|
|
[email protected]
Samba Member
Joined: August 03, 2002
Posts: 12785
Location: Salt Lake City, Utah
|
| Posted: Thu Mar 11, 2010 9:33 pm Post subject: |
|
|
we've never sold JCS parts/engines.
_________________
It's just advice, do whatever you want with it!
Please do NOT send me Private Messages through the Samba PM System (I will not see them). Send me an e-mail to john at aircooled dot net
"Like" our Facebook page at
http://www.facebook.com/vwpartsaircoolednet
and get a 5% off code for use on one order for VW Parts ON OUR PARTS STORE WEBSITE, vwparts.aircooled.net |
|
| Back to top |
|
|
gooser
Samba Member
Joined: February 21, 2008
Posts: 766
Location: danville virginia
|
| Posted: Thu Mar 11, 2010 10:24 pm Post subject: |
|
|
thank you john, i feel better now. |
|
| Back to top |
|
|
sped372
Samba Member
Joined: March 30, 2006
Posts: 653
Location: Waunakee, WI
|
| Posted: Fri Mar 12, 2010 6:49 am Post subject: |
|
|
As I mentioned in an email to your customer service... this is where I'm confused as well. I'm not trying to start an argument but I did order this engine through your website. If I'm not mistaken the name AVP somehow came up in the mix at the time. I know that for sure the engine was drop shipped and did not come directly from you but the transaction originated with you. I don't know how things all played out, could you have used AVP who in turn used JCS? Maybe this one was an anomaly?
Please, please, understand this is not meant to start a flame war. I am simply trying to get to the bottom of all this and figure out what I need to do going forward.
_________________
1971 Karmann Ghia - 1600 DP
1984 Westfalia - 1.9 WBX |
|
| Back to top |
|
|
[email protected]
Samba Member
Joined: August 15, 2002
Posts: 4394
Location: Brew City
|
| Posted: Fri Mar 12, 2010 1:59 pm Post subject: |
|
|
| Sorry to say but your engine is pretty much a lost cause. Definitely toss the case and heads and adjusting screws. Crank, rods and flywheel might still be good enough to use or reman. Pistons and cylinders are rarely good but possible. I would also be hard pressed to believe that engine could be associated with Aircooled.net |
|
| Back to top |
|
|
nsracing
Samba Member
Joined: November 16, 2003
Posts: 9745
Location: NOVA
|
| Posted: Fri Mar 12, 2010 2:03 pm Post subject: |
|
|
Why don't you just start fresh w/ a really good core? Build a larger one even.... a 1776cc.
I am surprised it lasted 2 years. |
|
| Back to top |
|
|
sped372
Samba Member
Joined: March 30, 2006
Posts: 653
Location: Waunakee, WI
|
| Posted: Fri Mar 12, 2010 7:54 pm Post subject: |
|
|
So, for the record, here's the receipt. Just wanted to back up my claim.
_________________
1971 Karmann Ghia - 1600 DP
1984 Westfalia - 1.9 WBX |
|
| Back to top |
|
|
connella08
Samba Member
Joined: February 28, 2009
Posts: 833
Location: south central mass
|
| Posted: Fri Mar 12, 2010 8:29 pm Post subject: |
|
|
wow $1200 for that P. O. S.?
they saw you coming from a thousand miles away... |
|
| Back to top |
|
|
modok
Samba Member
Joined: October 30, 2009
Posts: 27726
Location: Colorado Springs
|
| Posted: Fri Mar 12, 2010 11:57 pm Post subject: |
|
|
So you took the guides out of the heads why?
May I ask the PN on those heads?
I give whoever did them an "A" for effort, but it's the results that matter, that's where they blew it. Looks like they tried though.
Sorry about that. |
|
| Back to top |
|
|
djkeev
Samba Moderator
Joined: September 30, 2007
Posts: 32989
Location: Reading Pennsylvania
|
|
| Back to top |
|
|
Stripped66
Samba Member
Joined: May 31, 2005
Posts: 3513
Location: Charleston, SC
|
| Posted: Sat Mar 13, 2010 8:27 am Post subject: |
|
|
Maybe the "rebuilder" who John contracted to do the work started shipping engines rebuilt by other outfits?
Several parts that John sells are drop-shipped straight from the manufacturer. Once John provides that other company the details of the order, the other company has to fulfill the order as specified (which may or may not happen). It doesn't absolve John's responsibility of his *sub-contractor* shipping out a POS (though I must say, I'm impressed that engine lasted 12K miles in a bus), or even a *rebuilt* engine the rebuilder didn't actually rebuild, but that's a risk the vendor faces when the product is shipped on their behalf from another company.
_________________
| 66brm wrote: |
| Bodacious wrote: |
| Why not just make a custom set of wires with a Y splice in them. Then you could just run one distributor. |
I don't think electrickery works that way |
|
|
