PostPosted: Wed Aug 14, 2019 11:40 am    Post subject: Eberspacher BN4 install drawings Reply with quote

I plan to install a BN4 in my bus. While collecting info on this I did not find some dimensions.

All dimensions with a letter and ? are just a guess. If anyone has any missing measurements I will add them to the drawing.

https://dl.dropboxusercontent.com/s/5jn9mpa3kpdcr2z/InstallPatterens.pdf?dl=0
Image may have been reduced in size. Click image to view fullscreen.

_________________
My 64 Kombi restoration
My camper interior build


Last edited by sgellis on Fri Nov 01, 2019 9:58 am; edited 2 times in total
Back to top
View user's profile Send private message Gallery Classifieds Feedback
easy e
Samba Member


Joined: May 28, 2008
Posts: 3610
Location: Five Cities, CA
easy e is offline

PostPosted: Wed Aug 14, 2019 12:10 pm    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

Did you already look through the Heater and Air Conditioning Manuals and Instructions?
_________________
aka: Evan
Spreadsheet for Bus RPM, based on gearing & tire size (Excel format)
Searchable, click-navigable 1958 Bus Parts List
Back to top
View user's profile Send private message Instagram Gallery Classifieds Feedback
sgellis
Samba Member


Joined: July 06, 2016
Posts: 1373
Location: SW Nova Scotia, Canada
sgellis is offline

PostPosted: Wed Aug 14, 2019 12:33 pm    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

easy e wrote:
Did you already look through the Heater and Air Conditioning Manuals and Instructions?


Yes. They refer to templates for drilling holes.
_________________
My 64 Kombi restoration
My camper interior build
Back to top
View user's profile Send private message Gallery Classifieds Feedback
nlorntson Premium Member
Crazy VW Lady


Joined: March 13, 2004
Posts: 3442
Location: Twin Cities, MN
nlorntson is online now

PostPosted: Thu Aug 15, 2019 7:50 am    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

How about here:

http://oacdp.com/ebersp.html#q3
Back to top
View user's profile Send private message Visit poster's website Gallery Classifieds Feedback
sgellis
Samba Member


Joined: July 06, 2016
Posts: 1373
Location: SW Nova Scotia, Canada
sgellis is offline

PostPosted: Thu Aug 15, 2019 9:12 am    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

nlorntson wrote:
How about here:

http://oacdp.com/ebersp.html#q3


Install info is for a Bay window. Did find the air intake hole pattern… hopefully it was the same as a split.
_________________
My 64 Kombi restoration
My camper interior build
Back to top
View user's profile Send private message Gallery Classifieds Feedback
gr8vw4sale Premium Member
Samba Member


Joined: September 09, 2007
Posts: 33

gr8vw4sale is offline

PostPosted: Thu Aug 15, 2019 2:53 pm    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

Here are the dimensions for a barndoor Eberspacher 8460. They should essentially be the mirror image for a BN4 (Barndoor right side, Post-barndoor left side).

https://www.thesamba.com/vw/archives/lit/eberspacher_barndoor/6_7.jpg
https://www.thesamba.com/vw/archives/lit/eberspacher_barndoor/8_9.jpg
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
sgellis
Samba Member


Joined: July 06, 2016
Posts: 1373
Location: SW Nova Scotia, Canada
sgellis is offline

PostPosted: Thu Aug 15, 2019 4:01 pm    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

gr8vw4sale wrote:
Here are the dimensions for a barndoor Eberspacher 8460. They should essentially be the mirror image for a BN4 (Barndoor right side, Post-barndoor left side).

https://www.thesamba.com/vw/archives/lit/eberspacher_barndoor/6_7.jpg
https://www.thesamba.com/vw/archives/lit/eberspacher_barndoor/8_9.jpg


Most of that is quite different. I think the heater mounting holes may be the same though. I adjusted the drawing a bit but left them as still unknown.

Edit: actually I compared them to my heater and they are very different.
_________________
My 64 Kombi restoration
My camper interior build
Back to top
View user's profile Send private message Gallery Classifieds Feedback
sgellis
Samba Member


Joined: July 06, 2016
Posts: 1373
Location: SW Nova Scotia, Canada
sgellis is offline

PostPosted: Fri Sep 27, 2019 8:22 am    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

Hoping someone can help with the unknown dimensions.

Thanks.
_________________
My 64 Kombi restoration
My camper interior build
Back to top
View user's profile Send private message Gallery Classifieds Feedback
Riff Raff
Shivering Sambian


Joined: October 25, 2004
Posts: 2892
Location: Alberta
Riff Raff is offline

PostPosted: Fri Sep 27, 2019 9:53 pm    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

Pretty sure it was a BN4 I pulled out of the 306 kombi.
Have not commenced any rust repair yet, so all gas heater holes are still intact.

I can likely fill in some of your numbers tomorrow
_________________
The greatest obstacle to discovery is not ignorance, but the illusion of knowledge
- Daniel Boorstin
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
Riff Raff
Shivering Sambian


Joined: October 25, 2004
Posts: 2892
Location: Alberta
Riff Raff is offline

PostPosted: Sat Sep 28, 2019 11:50 am    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

I have uploaded a number of pics with measurements in the gallery.
https://www.thesamba.com/vw/forum/album_search.php...t_dir=DESC
I'm not sure what model my Ebespacher is, but there are pics of both the tags.
The hole closest the engine looks to be the same as on your drawing, but the hole in the drivers side battery tray is way off from the drawing.
Regardless, hope the pics can fill in some gaps for you and if you need other dimensions, let me know and I'll see what I can do
_________________
The greatest obstacle to discovery is not ignorance, but the illusion of knowledge
- Daniel Boorstin
Back to top
View user's profile Send private message Send e-mail Gallery Classifieds Feedback
sgellis
Samba Member


Joined: July 06, 2016
Posts: 1373
Location: SW Nova Scotia, Canada
sgellis is offline

PostPosted: Sat Sep 28, 2019 3:02 pm    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

Riff Raff wrote:
I have uploaded a number of pics with measurements in the gallery.


Thanks

The air intake hole looks very different than what I have seen. Other holes look close. I will have a better look in a day or two.
_________________
My 64 Kombi restoration
My camper interior build
Back to top
View user's profile Send private message Gallery Classifieds Feedback
crofty
Judas of the North


Joined: August 09, 2000
Posts: 19168
Location: Land of Whine and Phonies
crofty is offline

PostPosted: Tue Oct 01, 2019 7:15 am    Post subject: Re: Eberspacher BN4 install drawings Reply with quote

Riff Raff wrote:
I have uploaded a number of pics with measurements in the gallery.
https://www.thesamba.com/vw/forum/album_search.php...t_dir=DESC
I'm not sure what model my Ebespacher is, but there are pics of both the tags.
The hole closest the engine looks to be the same as on your drawing, but the hole in the drivers side battery tray is way off from the drawing.
Regardless, hope the pics can fill in some gaps for you and if you need other dimensions, let me know and I'll see what I can do


That heater is a 8478 and predates the BN4. similar but not the same.
_________________
When in doubt, logo it out!!

HamburgerBrad wrote:

I slept on crofty's tent once. I passed out drunk from two bottles of Everett's brother's wine.
